JESD204 Serial Interface and JEDEC Standard Data Converters

The JESD204 and the JESD204B revision data converter serial interface standard was created through the JEDEC committee to standardize and reduce the number of data inputs/outputs between high-speed data converters and other devices, such as FPGAs (field-programmable gate arrays). Fewer interconnects simplifies layout and allows smaller form factor realization without impacting overall system performance. These attributes are important to address the system size and cost constraints of a range of high speed ADC applications, including wireless infrastructure (GSM, EDGE, W-CDMA, LTE, CDMA2000, WiMAX, TD-SCDMA) transceiver architectures, software-defined radios, portable instrumentation, medical ultrasound equipment, and Mil/Aero applications such as radar and secure communications. Analog Devices is an original participating member of the JEDEC JESD204 standards committee and we have concurrently developed compliant data converter technology and tools, and a comprehensive product roadmap to fully enable our customers to take advantage of this significant interfacing breakthrough.

JESD204-Compatible Data Conversion Products

AD9152: Dual, 16-Bit, 2.25 GSPS, TxDAC+ Digital-to-Analog Converter
AD9154: Quad, 16-Bit, 2.4 GSPS, TxDAC+® Digital-to-Analog Converter
AD9135: Dual, 11-Bit, high dynamic, 2.8 GSPS, TxDAC+® Digital-to-Analog Converter
AD9136: Dual, 16-Bit, 2.8 GSPS, TxDAC+® Digital-to-Analog Converter
HMC7044: Low Noise, 3.2GHz, JESD204B Clock Generator with 14 LVPECL/CML/LVDS Outputs
AD6674:  385 MHz BW IF Diversity Receiver
AD6676: Wideband IF Receiver Subsystem
AD9528: JESD204B Clock Generator with 14 LVDS/HSTL Outputs
AD9144: Quad, 16-Bit, 2.8 GSPS, TxDAC+® Digital-to-Analog Converter
AD9625: 12-Bit, 2.0/2.5 GSPS, 1.3 V/2.5 V Analog-to-Digital Converter
AD9680: 14-Bit, 1000 MSPS JESD204B, Dual Analog-to-Digital Converter
AD9656: Quad, 16-Bit, 125 MSPS JESD204B 1.8 V Analog-to-Digital Converter
AD9250: 14-Bit, 170 MSPS/250 MSPS, JESD204B, Dual Analog-to-Digital Converter
AD6673: 80 MHz Bandwidth, Dual IF Receiver
AD9683: 14-Bit, 170 MSPS/250 MSPS, JESD204B, Analog-to-Digital Converter
AD6677: 80 MHz Bandwidth, IF Receiver
AD9671: Octal Ultrasound AFE with Digital Demodulator, JESD204B
AD9644: 14-Bit, 80 MSPS/155 MSPS, 1.8V Dual, Serial Output A/D Converter
AD9641: 14-Bit, 80 MSPS/155 MSPS, 1.8 V Serial Output Analog-to-Digital Converter (ADC)
AD9639: Quad 12-Bit, 170/210 MSPS, Serial Output 1.8 V A/D Converter
