Features and Benefits
- SNR = 79.9 dBFS at 16 MHz (VREF = 1.4 V)
- SNR = 78.1 dBFS at 64 MHz (VREF = 1.4 V)
- SFDR = 86 dBc to Nyquist (VREF = 1.4 V)
- JESD204B Subclass 1 coded serial digital outputs
- Flexible analog input range: 2.0 V p-p to 2.8 V p-p
- 1.8 V supply operation
- Low power: 197 mW per channel at 125 MSPS (two lanes)
- DNL = ±0.6 LSB (VREF = 1.4 V)
- INL = ±4.5 LSB (VREF = 1.4 V)
- 650 MHz analog input bandwidth, full power
- Serial port control
- Full chip and individual channel power-down modes
- Built-in and custom digital test pattern generation
- Multichip sync and clock divider
- Standby mode
The AD9656 is a quad, 16-bit, 125 MSPS analog-to-digital converter (ADC) with an on-chip sample and hold circuit designed for low cost, low power, small size, and ease of use. The device operates at a conversion rate of up to 125 MSPS and is optimized for outstanding dynamic performance and low power in applications where a small package size is critical.
The ADC requires a single 1.8 V power supply and LVPECL-/CMOS-/LVDS-compatible sample rate clock for full performance operation. An external reference or driver components are not required for many applications.
Individual channel power-down is supported and typically consumes less than 14 mW when all channels are disabled. The ADC contains several features designed to maximize flexibility and minimize system cost, such as a programmable output clock, data alignment, and digital test pattern generation. The available digital test patterns include built-in deterministic and pseudo-random patterns, along with custom user-defined test patterns entered via the serial port interface (SPI).
The AD9656 is available in an RoHS compliant, nonmagnetic, 56-lead LFCSP. It is specified over the −40°C to +85°C industrial temperature range.
- It has a small footprint. Four ADCs are contained in a small, 8 mm × 8 mm package.
- An on-chip phase-locked loop (PLL) allows users to provide a single ADC sampling clock; the PLL multiplies the ADC sampling clock to produce the corresponding JESD204B data rate clock.
- The configurable JESD204B output block supports up to 8.0 Gbps per lane.
- JESD204B output block supports one, two, and four lane configurations.
- Low power of 198 mW per channel at 125 MSPS, two lanes.
- The SPI control offers a wide range of flexible features to meet specific system requirements.
- Medical imaging
- High speed imaging
- Quadrature radio receivers
- Diversity radio receivers
- Portable test equipment
Product Lifecycle Recommended for New Designs
This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
Evaluation Kits (1)
The AD9656EBZ is an evaluation board for the AD9656, quad 16-bit ADC. This reference design provides all of the support circuitry required to operate the devices in their various modes and configurations. It is designed to interface directly with the HSC-ADC-EVALEZ data capture card, allowing users to download captured data for analysis. The Visual Analog software package, which is used to interface with the device's hardware, allows users to download captured data for analysis with a user-friendly graphical interface. The SPI Controller software package is also compatible with this hardware, and allows the user to access the SPI programmable features of the AD9656.
The AD9656 data sheet provides additional information related to device configuration and performance, and should be consulted when using these tools. All documents and Visual Analog and SPI Controller are available at the High Speed ADC Evaluation Boards page. For additional information or questions, please email firstname.lastname@example.org
Features & Benefits
- 6V 2A switching supply (such as CUI EPS060250UH-PHP-SZ) (optional)
- 12V, 3 A switching power supply
- Analog signal source and anti aliasing filter
- Analog Clock source (if not using the on-board crystal)
- PC running Windows
- USB 2.0 port recommended (USB 1.1 compatible)
- AD9656 Evaluation Board (AD9656EBZ)
- HSC-ADC-EVALEZ Data Capture Board
Tools & Simulations
This command line executable tool generates a Verilog module which implements the JESD204 receive transport layer. The user specifies in a configuration file one or more modes to be supported by the transport layer module. These modes are defined as a set of JESD204 parameter values: L, M, F, S, N', and CF. The transport layer converts JESD204 lane data output from a JESD204 link layer IP to a data bus with a fixed width, containing interleaved virtual converter samples. Both JESD204B and JESD204C link layers are supported.
The JESD204x Frame Mapping Table Generator tool consists of two Windows executables that will allow the user to input any valid combination of JESD204x parameters (L, M, F, S, NP) in order to output a .csv file that illustrates the frame mapping of the JESD204x mode in table format. There is an executable that allows the user to input a single JESD204x mode and another, that allows the user to input the parameters for multiple JESD204x modes in a specified .csv format in order to output a .csv file that illustrates the frame mapping of each of the JESD204x modes that were input into separate tables.
For designers who are selecting or evaluating high speed ADCs, VisualAnalog™ is a software package that combines a powerful set of simulation and data analysis tools with a user-friendly graphical interface.
AD9656 Companion Parts
Recommended Driver Amplifiers
- For a high speed, low power, FET input: AD822.
- For RF/IF applications requiring low noise and low distortion: ADL5565.
- For baseband applications requiring ultra low noise, low distortion, low power: ADA4930-1.
Recommended Clock Drivers
FPGA Interoperability Reports (1)
Technical Articles (1)
