- Fast throughput rate of 1 MSPS
- Specified for VDD of 2.7 V to 5.25 V
- Logic voltage VDRIVE of 1.65 V to 5.25 V
- INL of ±1 LSB maximum
- Analog input range of 0 V to VREF
- Ultralow power
- 349 µA typical at 3 V and 1 MSPS
- 264 nA typical at 3 V in power-down mode
- Internal 2.5 V reference, ±4.5 ppm/°C typical drift
- Wide input bandwidth
- Flexible power/throughput rate management
- High speed serial interface
- SPI®/QSPI™/MICROWIRE™/DSP compatible
- BUSY indicator
- Power-down mode
- 10-lead, 3 mm × 2 mm LFCSP and 10-lead MSOP packages
- Temperature range of −40°C to +125°C
The AD7091R is a 12-bit successive approximation analog-to-digital converter (ADC) that offers ultralow power consumption (typically 349 µA at 3 V and 1 MSPS) while achieving fast throughput rates (1 MSPS with a 50 MHz SCLK). Operating from a single 2.7 V to 5.25 V power supply, the part contains a wide bandwidth track-and-hold amplifier that can handle input frequencies in excess of 7 MHz. The AD7091R also features an on-chip conversion clock, accurate reference, and high speed serial interface.
The conversion process and data acquisition are controlled using a CONVST signal and an internal oscillator. The AD7091R has a serial interface that allows data to be read after the conversion while achieving a 1 MSPS throughput rate.
The AD7091R uses advanced design and process techniques to achieve very low power dissipation at high throughput rates. An on-chip, accurate 2.5 V reference is available
Product Highlights
- Lowest Power 12-Bit SAR ADC Available.
- On-Chip, Accurate 2.5 V Reference.
- High Throughput Rate with Ultralow Power Consumption.
- Flexible Power/Throughput Rate Management. Average power scales with the throughput rate. Power-down mode allows the average power consumption to be reduced when the device is not performing a conversion.
- Single Supply Operation with VDRIVE Function. The AD7091R operates from a single 2.7 V to 5.25 V supply. The VDRIVE function allows the serial interface to connect directly to 1.8 V to 3.3 V processors.
Applications
- Battery-powered systems
– Handheld meters
– Medical instruments
– Mobile communications - Instrumentation and control systems
- Data acquisition systems
- Optical sensors
- Diagnostic/monitoring functions
- Energy harvesting
Ask a Question
Submit your question below and we will return the best answer from ADI’s knowledge database:
Other places you can find help
Support
Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.
Visit the ADI Support Page{{modalTitle}}
{{modalDescription}}
{{dropdownTitle}}
- {{defaultSelectedText}} {{#each projectNames}}
- {{name}} {{/each}} {{#if newProjectText}}
- {{newProjectText}} {{/if}}
{{newProjectTitle}}
{{projectNameErrorText}}
AD7091R
Documentation
Filters
1 Applied
Data Sheet
2
Application Note
11
HTML
HTML
HTML
HTML
HTML
HTML
User Guide
2
Technical Articles
6
377 kB
HTML
HTML
HTML
HTML
Documentation
Data Sheet 1
User Guide 1
Application Note 4
Technical Articles 3
Tutorial 3
Circuit Note 7
Product Selection Guide 1
3rd Party Solutions 1
Device Drivers 2
Technical Book 1
Analog Dialogue 1
Video
4
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.
Part Model | Pin/Package Drawing | Documentation | CAD Symbols, Footprints, and 3D Models |
---|---|---|---|
AD7091RBCPZ-RL | 10-Lead LFCSP (2mm x 3mm w/ EP) |
|
|
AD7091RBCPZ-RL7 | 10-Lead LFCSP (2mm x 3mm w/ EP) |
|
|
AD7091RBRMZ | 10-Lead MSOP |
|
|
AD7091RBRMZ-RL7 | 10-Lead MSOP |
|
- AD7091RBCPZ-RL
- Pin/Package Drawing
- 10-Lead LFCSP (2mm x 3mm w/ EP)
- Documentation
- HTML Material Declaration
- HTML Reliablity Data
- CAD Symbols, Footprints, and 3D Models
- Ultra Librarian
- SamacSys
- AD7091RBCPZ-RL7
- Pin/Package Drawing
- 10-Lead LFCSP (2mm x 3mm w/ EP)
- Documentation
- HTML Material Declaration
- HTML Reliablity Data
- CAD Symbols, Footprints, and 3D Models
- Ultra Librarian
- SamacSys
- AD7091RBRMZ
- Pin/Package Drawing
- 10-Lead MSOP
- Documentation
- HTML Material Declaration
- HTML Reliablity Data
- CAD Symbols, Footprints, and 3D Models
- Ultra Librarian
- SamacSys
- AD7091RBRMZ-RL7
- Pin/Package Drawing
- 10-Lead MSOP
- Documentation
- HTML Material Declaration
- HTML Reliablity Data
- CAD Symbols, Footprints, and 3D Models
- Ultra Librarian
- SamacSys
Filter by Model
Part Models
Product Lifecycle
PCN
Aug 8, 2022
- 22_0192
Qualification of an Alternate Adhesive Material and Molding Compound for Select LFCSP Packages
AD7091RBCPZ-RL
PRODUCTION
AD7091RBCPZ-RL7
PRODUCTION
Aug 1, 2016
- 16_0035
Assembly Relocation of Select LFCSP, Mini-LFCSP and LFCSP Side Solderable Products to STATS ChipPAC China Jiangyin
AD7091RBCPZ-RL
PRODUCTION
AD7091RBCPZ-RL7
PRODUCTION
May 31, 2016
- 16_0039
AD7091 and AD7091R Die Revision and AD7091R Specification Change
AD7091RBCPZ-RL
PRODUCTION
AD7091RBCPZ-RL7
PRODUCTION
AD7091RBRMZ
PRODUCTION
AD7091RBRMZ-RL7
PRODUCTION
Jun 19, 2014
- 13_0247
Assembly Transfer of Select 3x2, 4x4, 5x5, 6x6 and 7x7 mm LFCSP Pre-plated Leadframe Products to STATS ChipPAC China
AD7091RBCPZ-RL
PRODUCTION
AD7091RBCPZ-RL7
PRODUCTION
Nov 7, 2013
- 13_0224
Assembly Transfer of Select 2x3 and 3x3mm LFCSP Products to STATS ChipPAC China.
AD7091RBCPZ-RL
PRODUCTION
AD7091RBCPZ-RL7
PRODUCTION
Filter by Model
Part Models
Product Lifecycle
PCN
Aug 8, 2022
- 22_0192
Qualification of an Alternate Adhesive Material and Molding Compound for Select LFCSP Packages
AD7091RBCPZ-RL
PRODUCTION
AD7091RBCPZ-RL7
PRODUCTION
Aug 1, 2016
- 16_0035
Assembly Relocation of Select LFCSP, Mini-LFCSP and LFCSP Side Solderable Products to STATS ChipPAC China Jiangyin
AD7091RBCPZ-RL
PRODUCTION
AD7091RBCPZ-RL7
PRODUCTION
May 31, 2016
- 16_0039
AD7091 and AD7091R Die Revision and AD7091R Specification Change
AD7091RBCPZ-RL
PRODUCTION
AD7091RBCPZ-RL7
PRODUCTION
AD7091RBRMZ
PRODUCTION
AD7091RBRMZ-RL7
PRODUCTION
Jun 19, 2014
- 13_0247
Assembly Transfer of Select 3x2, 4x4, 5x5, 6x6 and 7x7 mm LFCSP Pre-plated Leadframe Products to STATS ChipPAC China
AD7091RBCPZ-RL
PRODUCTION
AD7091RBCPZ-RL7
PRODUCTION
Nov 7, 2013
- 13_0224
Assembly Transfer of Select 2x3 and 3x3mm LFCSP Products to STATS ChipPAC China.
AD7091RBCPZ-RL
PRODUCTION
AD7091RBCPZ-RL7
PRODUCTION
Software & Part Ecosystem
FPGA/HDL
Device Drivers
Looking for Evaluation Software? You can find it here
Parts | Product Life Cycle | Description | ||
---|---|---|---|---|
High Voltage Op Amps ≥12V1 |
||||
PRODUCTION |
Unity-Gain Stable, Ultralow Distortion, 1 nV/√Hz Voltage Noise, High Speed Op Amp |
|||
Low Input Bias Current Op Amps (≤100 pA)3 |
||||
PRODUCTION |
36 V, 19 MHz, Low Noise, Low Bias Current, JFET Op Amp |
|||
PRODUCTION |
30 V, 80 MHz, Low Noise, Low Bias Current, JFET Op Amp |
|||
PRODUCTION |
Precision, Low Input Bias Current, Wide BW JFET Single Op Amp |
|||
Low Noise Op Amps (≤ 10nV/√Hz)2 |
||||
RECOMMENDED FOR NEW DESIGNS |
1 nV/√Hz, Low Power, Rail-to-Rail Output Amplifiers |
|||
RECOMMENDED FOR NEW DESIGNS |
1 nV/√Hz, Low Power, Rail-to-Rail Output Amplifiers |
|||
Low Power Op Amps (≤ 1mA/amp) 1 |
||||
PRODUCTION |
2.7 V, 800 µA, 80 MHz Rail-to-Rail I/O Single Amplifier |
|||
Precision Op Amps (Vos ≤1mV & TCVos ≤2uV/C)2 |
||||
PRODUCTION |
Low Noise, High Speed Amplifier for 16-Bit Systems |
|||
PRODUCTION |
Low Power, Low Noise and Distortion, Rail-to-Rail Output Amplifier |
|||
Series Voltage References4 |
||||
RECOMMENDED FOR NEW DESIGNS |
Ultra-Low-Noise, High-Accuracy 3.0V Voltage Reference |
|||
PRODUCTION |
3.0V Precision Micropower, Low Dropout, Low Voltage Reference |
|||
RECOMMENDED FOR NEW DESIGNS |
Ultra-Low-Noise, High-Accuracy 5.0V Voltage Reference |
|||
PRODUCTION |
5.0V Precision Micropower, Low Dropout, Low Voltage Reference |
Can't find the software or driver you need?
Request a Driver/SoftwareEvaluation Kits 1
EVAL-AD7091R
AD7091R Evaluation Board
Product Detail
The EVAL-AD7091RSDZ is a fully featured evaluation kit for the AD7091R. This board operates in stand alone mode or in conjunction with the System Development Platform, EVAL-SDP-CB1Z . When operated with the System Development Platform software is provided enabling the user to perform detailed analysis of the ADC's performance. This software includes the technical note describing the operation and set up of the evaluation board in standalone operation or when operated with the System Development Platform . When operated in standalone mode the ADZS-BRKOUT-EX3 break out board is recommended for access to various control pins.
The SDP Controller board is a separate list item in the ordering guide below (EVAL-SDP-CB1Z). If you have not previously purchased an SDP Controller board, please do so to ensure a full evaluation setup.
Resources
Evaluation Kits1
Tools & Simulations 1
IBIS Model 1
Reference Designs 8
CN0366
A 40 GHz Microwave Power Meter with a Range from −30 dBm to +15 dBm
CN0335
12-Bit, 300 kSPS, Single-Supply, Fully Isolated, Data Acquisition System for ±10 V Inputs
CN0336
12-Bit, 300 kSPS, Single-Supply, Fully Isolated, Data Acquisition System for 4-20 mA Inputs
CN0337
12-Bit, 300 kSPS, Single-Supply, Fully Isolated RTD Temperature Measurement System with 3-Wire Compensation
CN0350
12-Bit, 1 MSPS, Single-Supply, Two-Chip Data Acquisition System for Piezoelectric Sensors
CN0247
12-Bit ,1 MSPS, Single-Supply, Low Power Data Acquisition System
Resources
CN0399
Battery or USB Powered 9 kHz to 6 GHz RMS Power Measurement System
CN0387
Calibration-Free Return Loss Measurement System
Reference Designs8
CN0366
A 40 GHz Microwave Power Meter with a Range from −30 dBm to +15 dBm
CN0335
