ADA4897-1
1 nV/√Hz, Low Power, Rail-to-Rail Output Amplifiers
Top
Overview
Features and Benefits
- Low wideband noise
1 nV/√Hz
2.8 pA/√Hz - Low 1/f noise: 2.4 nV/√Hz @ 10 Hz
- Low distortion: −115 dBc @ 100 kHz, VOUT = 2 V p-p
- Low power: 3 mA/amp
- Low input offset voltage: 0.5 mV maximum
- High speed
230 MHz, −3 dB bandwidth (G = +1)
120 V/μs slew rate
45 ns settling time to 0.1% - Rail-to-rail output
- Wide supply range: 3 V to 10 V
- Disable feature (ADA4897-1)
- Download ADA4897-1-EP data sheet (pdf)
- Extended industrial temperature range (−55°C to +125°C)
- Controlled manufacturing baseline
- 1 assembly/test site
- 1 fabrication site
- Enhanced product change notification
- Qualification data available on request
- V62/13614 DSCC Drawing Number
Product Details
The ADA4896-2/ADA4897-1 are unity gain stable, low noise, rail-to-rail output, high speed voltage feedback amplifiers that have a quiescent current of 3 mA. With the 1/f noise of 2.4 nV/√Hz at 10 Hz and a spurious-free dynamic range of −80 dBc at 2 MHz, the ADA4896-2/ADA4897-1 are an ideal solution in a variety of applications, including ultrasound, low noise preamplifiers, and drivers of high performance ADCs. The Analog Devices, Inc., proprietary next generation SiGe bipolar process and innovative architecture enable such high performance amplifiers.
TheADA4896-2/ADA4897-1 have 230 MHz bandwidth, 120 V/μs slew rate, and settle to 0.1% in 45 ns. With a wide supply voltage range (3 V to 10 V), the ADA4896-2/ADA4897-1 are ideal candidates for systems that require high dynamic range, precision, and high speed.
The ADA4896-2 is available in 8-lead LFCSP and 8-lead MSOP packages. The ADA4897-1 is available in 8-lead SOIC and 6-lead SOT-23 packages. Both the ADA4896-2 and ADA4897-1 work over the extended industrial temperature range of −40°C to +125°C.
Applications
- Low noise preamplifier
- Ultrasound amplifiers PLL loop filters
- High performance ADC drivers
- DAC buffers
Product Categories
Markets and Technologies
Product Lifecycle
Recommended for New Designs
This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
Evaluation Kits (1)
Documentation & Resources
-
AN-0991: Active Filter Evaluation Board for Standard SOIC Op Amps (Rev. A)2/14/2015PDF99 kB
-
UG-1224: Amplifier Mezzanine Card for ADC Drivers (Rev. 0)1/9/2019PDF821 K
-
UG-838: Evaluation Board for Single, High Speed Op Amps Offered in 5-Lead SOT-23 and 6-Lead SOT-23 Packages10/15/2015PDF184K
-
UG-755: 8-Lead SOIC Amplifier Evaluation Board User Guide (Rev. A)4/14/2015PDF248 K
-
MT-053: Op Amp Distortion: HD, THD, THD + N, IMD, SFDR, MTPR2/14/2015PDF104 kB
-
MT-052: Op Amp Noise Figure: Don't Be Misled2/14/2015PDF60 kB
-
MT-050: Op Amp Total Output Noise Calculations for Second-Order System2/14/2015PDF38 kB
-
MT-049: Op Amp Total Output Noise Calculations for Single-Pole System2/14/2015PDF40 kB
-
MT-048: Op Amp Noise Relationships: 1/f Noise, RMS Noise, and Equivalent Noise Bandwidth2/14/2015PDF81 kB
-
MT-047: Op Amp Noise2/14/2015PDF72 kB
-
MT-060: Choosing Between Voltage Feedback and Current Feedback Op Amps2/14/2015PDF62 kB
-
MT-059: Compensating for the Effects of Input Capacitance on VFB and CFB Op Amps Used in Current-to-Voltage Converters2/14/2015PDF69 kB
-
MT-033: Voltage Feedback Op Amp Gain and Bandwidth2/14/2015PDF251 kB
-
MT-058: Effects of Feedback Capacitance on VFB and CFB Op Amps2/14/2015PDF66 kB
-
MT-056: High Speed Voltage Feedback Op Amps2/3/2009PDF109 kB
-
MT-032: Ideal Voltage Feedback (VFB) Op Amp12/11/2008PDF65 kB
-
SAR ADC & Driver Quick-Match Guide9/13/2013PDF251 kB
-
Power Optimization Techniques for Low Power Signal Chain Applications12/1/2022 Analog Dialogue
-
Selecting an ADC driver to achieve optimized signal chain performance7/13/2015
-
Some Tips on Making a FETching Discrete Amplifier10/1/2013 Analog Dialogue
-
Compensating Amplifiers That Are Stable at Gain ≥ 10 to Operate at Lower Gains12/1/2012 Analog Dialogue
-
Front-End Amplifier and RC Filter Design for a Precision SAR Analog-to-Digital Converter12/1/2012 Analog Dialogue
-
Dual Op Amps and Double Agents7/1/2012
-
The Electromotive Force and Op Amps4/1/2012
-
Beware of big claims and large numbers.1/1/2012
-
Capacitive Sensors: Rugged Enough for the Real World?2/1/2008
-
Are leaky amps sinking your design?8/1/2007
Tools & Simulations
Precision ADC Driver Tool
The Precision ADC Driver Tool is a web application that simulates the performance of precision ADC and driver combinations. Potential issues with driver selection, kickback settling, and distortion are flagged, and design tradeoffs can be quickly evaluated. Simulations and calculations include system noise, distortion, and settling of the ADC input
SPICE Models
CIR
ADA4897 SPICE Macro Model
5.72 K
Design Tools
Analog Filter Wizard
Use the Analog Filter Wizard to design low-pass, high-pass, or band-pass filters with actual op amps in minutes. As you progress through the design process, you can observe the characteristics of your filter design from ideal specifications to real world circuit behavior. Quickly evaluate the tradeoffs in op amp specifications - including gain-bandwidth, noise, and supply current – to determine the best filter design for your requirements.
Reference Designs (2)
Design Resources
