Operational Amplifiers (Op Amps)
The operational amplifier (op amp) is an important part of any analog signal chain, often working as a crucial part of the interface between sensors and our world-leading ADCs. Common analog op amp functions include gain, buffering, filtering, and level-shifting. Analog Devices’ portfolio provides the broadest choice of op amps in the industry, delivering unmatched quality, robustness, and performance to enable optimized solutions in automotive, industrial, consumer, and healthcare markets.
Explore op amps by parameters and find expert system-level advice on design problems with our reference designs (Circuits from the Lab®), design tools, selection guides, filter design, calculators, and LTSpice®/SPICE models for operational amplifiers.
Explore op amps by parameters and find expert system-level advice on design problems with our reference designs (Circuits from the Lab®), design tools, selection guides, filter design, calculators, and LTSpice®/SPICE models for operational amplifiers.
Subcategories
Product Selection Table
- Current Feedback Op Amps
- General Purpose Op Amps
- High Output Current Op Amps ≥ 100mA
- High Speed Op Amps (Bandwidth ≥ 50MHz)
- High Voltage Op Amps ≥12V
- JFET Input Op Amps
- Low Input Bias Current Op Amps (≤100 pA)
- Low Noise Op Amps (≤ 10nV/√Hz)
- Low Power Op Amps (≤ 1mA/amp)
- Precision Op Amps (Vos ≤1mV & TCVos ≤2uV/C)
- Rail-to-Rail Op Amps
- Zero-Drift Op Amps
Analog Filter Wizard Design Tool
Use the Analog Filter Wizard to design low-pass, high-pass, or band-pass filters with actual op amps in minutes. As you progress through the design process, you can observe the characteristics of your filter design from ideal specifications to real world circuit behavior. Quickly evaluate the tradeoffs in op amp specifications - including gain-bandwidth, noise, and supply current – to determine the best filter design for your requirements.
Precision Technology Signal Chains
Save time and deliver your solutions faster with ADI’s new suite of precision technology signal chains. Align your applications ranging from Smart Industry to Instrumentation, Electrification to Digital Health, to exactly the right precision technology combinations.
