MAX9633

Applications

• Industrial control automation
• Servo drive

Competitive Advantages

• High speed
• High accuracy
• Low noise

Features

• Two independent analog inputs
• Two independent analog outputs
• Isolated power and data
• High-speed 400ksps analog input sampling rate
• High-accuracy 16-bit resolution
• Voltage output settles to within 2 LSB in 17µs
• Current output settles to within 2 LSB in 77µs
• Device drivers
• Example C source code
• Configuration files for ZedBoard™ platform
• FMC-compatible

• Two independent analog inputs
• Two independent analog outputs
• Isolated power and data
• High-speed 400ksps analog input sampling rate
• High-accuracy 16-bit resolution
• Voltage output settles to within 2 LSB in 17µs
• Current output settles to within 2 LSB in 77µs
• Device drivers
• Example C source code
• Configuration files for ZedBoard^™ platform
• FMC-compatible

• High accuracy
• -10 to +10V ±20% voltage inputs
• 4 to 20mA +20% current inputs
• Isolated power and data
• Micro PLC form factor
• Device drivers
• Example C source code
• Test data

• Ratiometric measurement or measurement compared to a precision voltage reference
• User-programmable offset and gain calibration for sensor (load cell)
• User-programmable offset and gain calibration for DAC
• User-programmable voltage output range mapping
