Fast Precision Solutions

Fast precision signal chains address applications that demand both high precision and speed. These signal chains offer the flexibility needed to optimize them for either measurement or drive solutions. They combine fast sampling rates with high resolution that support bandwidths up to 1 MHz, with no compromise between DC and AC precision and accuracy. Analog Devices’ catalog of fast precision components enables full signal chain solutions that meet critical specifications for DC linearity, settling time, latency, total harmonic distortion (THD), and signal-to-noise ratios (SNR) exceeding 90 dB.

Values and Benefits

Fast precision signal chains offer curated solutions that combine precision amplifiers, analog-to-digital converters (ADCs), digital-to-analog converters (DACs), circuit protection, voltage references, and isolation components, allowing system designers to explore solutions that can be optimized for both precision and speed.

These solutions offer the flexibility to modify parameters such as resolution, gain, and bandwidth to meet system requirements. They cover applications such as hardware-in-the-loop (HIL), nondestructive test, scanning electron microscopes (SEM), and flow cytometry, where speeds above 100 kHz and SNR >85 dB are required.

Optimized latency and feedback

Sampling rates up to 40 MSPS

Excellent SNR, up to 95 dB

Fast Precision Signal Chains

Current and Voltage Measurement

Current and Voltage Drive
- Optimized for Flexibility
- Density Optimized

Current or Voltage Measurement

Signal Chain options for measuring wide bandwidths up to 1 MHz optimized for noise performance to support AC and/or DC analysis

Density Optimized

Protection	Gain	ADC Driver \| ADC	Voltage Reference	Isolation
ADG5421F ±60 V Fault Protection and Detection, 11 Ω RON, Dual SPST Switch	LTC6373 36V Fully-Differential Programmable-Gain Instrumentation Amplifier with 25pA Input Bias Current	ADAQ23875 16-Bit, 15 MSPS, μModule Data Acquisition Solution ADAQ23876 16-Bit, 15 MSPS, μModule Data Acquisition Solution ADAQ23878 18-Bit, 15 MSPS, μModule Data Acquisition Solution	LTC6655 0.25ppm Noise, Low Drift Precision References	ADN4622 5.7 kV rms/1.5 kV rms, Quad-Channel LVDS 2.5 Gigabit Isolators (2 Reverse Channels)

View in Signal Chain Designer Tool

Power Optimized

Protection	Gain	ADC Driver	ADC	Voltage Reference	Isolation
ADG5421F ±60 V Fault Protection and Detection, 11 Ω RON, Dual SPST Switch	LTC6373 36V Fully-Differential Programmable-Gain Instrumentation Amplifier with 25pA Input Bias Current	ADA4945-1 High Speed, ±0.1 µV/˚C Offset Drift, Fully Differential ADC Driver	AD4080 20-Bit, 40 MSPS, Differential SAR ADC	LTC6655 0.25ppm Noise, Low Drift Precision References	ADN4622 5.7 kV rms/1.5 kV rms, Quad-Channel LVDS 2.5 Gigabit Isolators (2 Reverse Channels)

View in Signal Chain Designer Tool

Noise and Bandwidth Optimized

Protection	Gain	ADC Driver	ADC	Voltage Reference	Isolation
ADG5421F ±60 V Fault Protection and Detection, 11 Ω RON, Dual SPST Switch	LTC6373 36V Fully-Differential Programmable-Gain Instrumentation Amplifier with 25pA Input Bias Current	ADA4899-1 Unity-Gain Stable, Ultralow Distortion, 1 nV/√Hz Voltage Noise, High Speed Op Amp	LTC2387-18 18-Bit, 15Msps SAR ADC AD4080 20-Bit, 40 MSPS, Differential SAR ADC	LTC6655 0.25ppm Noise, Low Drift Precision References	ADN4622 5.7 kV rms/1.5 kV rms, Quad-Channel LVDS 2.5 Gigabit Isolators (2 Reverse Channels)

View in Signal Chain Designer Tool

Current and Voltage Drive

Low latency precision output drive signal chain options

Optimized for Flexibility

DAC	Output Driver	Voltage Reference	Protection
AD3552R Dual Channel, 16-Bit, 33 MUPS, Multispan, Multi-IO SPI DAC	AD8065 High Performance, 145 MHz FastFET™ Op Amps	ADR4525 Ultra-Low-Noise, High-Accuracy 2.5V Voltage Reference	ADG5421F ±60 V Fault Protection and Detection, 11 Ω R_ON, Dual SPST Switch ADG5401F Fault Protection, 6 Ω R_ON, SPST Switch with 0.6 kΩ Feedback Channel

Density Optimized

DAC \| Output Driver	Voltage Reference	Protection
AD3542R Dual Channel, 12-/16-Bit, 16 MUPS, Multispan, Multi-IO SPI DAC	LTC6655 0.25ppm Noise, Low Drift Precision References	ADG5421F ±60 V Fault Protection and Detection, 11 Ω R_ON, Dual SPST Switch ADG5401F Fault Protection, 6 Ω R_ON, SPST Switch with 0.6 kΩ Feedback Channel

LTspice Signal Chain Simulations

Optimized for Flexibility

Power Solutions

Optimized for Flexibility

Density Optimized

Applications

Source Measurement Unit

Parametric Measurement

Impedance Measurement & Analysis

Data Acquisition

Light Measurement

Low latency, low noise precision measurement signal chain options for optical signal chains

Optimized for Noise

TIA	ADC Driver	ADC	Voltage Reference
LTC6268 500MHz Ultra-Low Bias Current FET Input Op Amp	ADA4899-1 Unity-Gain Stable, Ultralow Distortion, 1 nV/√Hz Voltage Noise, High Speed Op Amp	LTC2387-18 18-Bit, 15Msps SAR ADC AD4080 20-Bit, 40 MSPS, Differential SAR ADC	LTC6655 0.25ppm Noise, Low Drift Precision References

Power Optimized

TIA	ADC Driver	ADC	Voltage Reference
LTC6268 500MHz Ultra-Low Bias Current FET Input Op Amp	ADA4945-1 High Speed, ±0.1 µV/˚C Offset Drift, Fully Differential ADC Driver	LTC2387-18 18-Bit, 15Msps SAR ADC AD4080 20-Bit, 40 MSPS, Differential SAR ADC	LTC6655 0.25ppm Noise, Low Drift Precision References
