LTC1559

量产

具可编程输出的备份电池控制器

数据手册产品选型表

产品模型: 12

Viewing:

产品详情

不推荐用于新的设计。可能的替代产品请联系 ADI。
采用 SO-8 封装、16 引脚 GN 封装或 SO 封装的完整电池备份系统
采用单节 1.2V 镍镉 (NiCd) 钮扣电池产生固定的备份电源电压 (3.07V / 4.63V)
主电源至备份电源的自动切换
100mW 最小输出功率
NiCd 电池的自动快速再充电
可编程 NiCd 电池涓流充电电流
智能型 NiCd 电池充电器较大限度缩短了再充电时间，并较大限度提高了启用备份电源之后的系统效率
片内上电和按钮复位发生器
执行 V_CC 监控功能
复位断言得到保证 (在 V_CC = 1V)
短路保护
热限制

  

参考资料

数据手册 1

LTC1559: Backup Battery Controller with Fixed Output Data Sheet 08/22/2007

可靠性数据 1

R370 Reliability Data 03/23/2018

ADI 始终高度重视提供符合最高质量和可靠性水平的产品。我们通过将质量和可靠性检查纳入产品和工艺设计的各个范围以及制造过程来实现这一目标。出货产品的“零缺陷”始终是我们的目标。查看我们的质量和可靠性计划和认证以了解更多信息。

产品型号	引脚/封装图-中文版	文档	CAD 符号，脚注和 3D模型
LTC1559CGN-3.3#PBF	16-Lead SSOP (Narrow 0.15 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LTC1559CGN-3.3#TRPBF	16-Lead SSOP (Narrow 0.15 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LTC1559CGN-5#PBF	16-Lead SSOP (Narrow 0.15 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LTC1559CGN-5#TRPBF	16-Lead SSOP (Narrow 0.15 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LTC1559CS-3.3#PBF	16-Lead SOIC (Narrow 0.15 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LTC1559CS-3.3#TRPBF	16-Lead SOIC (Narrow 0.15 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LTC1559CS-5#PBF	16-Lead SOIC (Narrow 0.15 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LTC1559CS-5#TRPBF	16-Lead SOIC (Narrow 0.15 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LTC1559CS8-3.3#PBF	8-Lead SOIC (Narrow 0.15 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LTC1559CS8-3.3#TRPBF	8-Lead SOIC (Narrow 0.15 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LTC1559CS8-5#PBF	8-Lead SOIC (Narrow 0.15 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
LTC1559CS8-5#TRPBF	8-Lead SOIC (Narrow 0.15 Inch)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
