LTC2974

4-Channel PMBus Power System Manager Featuring Accurate Output Current Measurement

Show More showmore-icon

Info : RECOMMENDED FOR NEW DESIGNS tooltip
Info : RECOMMENDED FOR NEW DESIGNS tooltip
Viewing: Part Details
arrow-icon

Not the part you were looking for?

viewall Go to Product Selection Table
file View Data Sheet (Rev.F)
Documentation View All Documentation
Linduino LTC2974 - DC1978 Linduino.INO File Download 13.00KB Linduino LTC2974 - Linduino CPP File Download 0.00KB Linduino LTC2974 - Linduino Header File Download 4.00KB
Part Models 6
1ku List Price Starting From $10.49
Features
  • Sequence, Trim, Margin and Supervise Four Power Supplies
  • Manage Faults, Monitor Telemetry and Create Fault Logs
  • PMBus™ Compliant Command Set
  • Supported by LTpowerPlay® GUI
  • Margin or Trim Supplies to within 0.25% of Target
  • Fast OV/UV Supervisors Per Channel
  • Fast Output Current Supervisors Per Channel
  • Coordinate Sequencing and Fault Management Across Multiple LTC PSM Devices
  • Automatic Fault Logging to Internal EEPROM
  • Operate Autonomously without Additional Software
  • External Temperature and Input Voltage Supervisors
  • Accurate Monitoring of Four Output Voltages, Four Output Currents, Four External Temperatures, Input Voltage and Internal Die Temperature
  • I2C/SMBus Serial Interface
  • Can Be Powered from 3.3V, or 4.5V to 15V
  • Available in 64-Lead 9mm × 9mm QFN Package
  • AEC-Q100 Qualified for Automotive Applications
Additional Details
show more Icon

The LTC2974 is a 4-channel Power System Manager used to sequence, trim (servo), margin, supervise, manage faults, provide telemetry and create fault logs. PMBus commands support power supply sequencing, precision point-of-load voltage adjustment and margining. DACs use a proprietary soft-connect algorithm to minimize supply disturbances. Supervisory functions include over and under current, voltage and temperature threshold limits for four power supply output channels as well as over and under voltage threshold limits for a single power supply input channel. Programmable fault responses can disable the power supplies with optional retry after a fault is detected. Faults that disable a power supply can automatically trigger black box EEPROM storage of fault status and associated telemetry. An internal 16-bit ADC monitors four output voltages, four output currents, four external temperatures, one input voltage and die temperature. Output power is also calculated. A programmable watchdog timer monitors microprocessor activity for a stalled condition and resets the microprocessor if necessary. A single wire bus synchronizes power supplies across multiple LTC Power System Management (PSM) devices. Configuration EEPROM with ECC supports autonomous operation without additional software.

APPLICATIONS

  • Computers and Network Servers
  • Industrial Test and Measurement
  • High Reliability Systems
  • Medical Imaging
  • Video
Show More Arrow image
file View Data Sheet (Rev.F)
Documentation View All Documentation
Linduino LTC2974 - DC1978 Linduino.INO File Download 13.00KB Linduino LTC2974 - Linduino CPP File Download 0.00KB Linduino LTC2974 - Linduino Header File Download 4.00KB
Part Models 6
1ku List Price Starting From $10.49
