Alternative Parts


Features and Benefits

  • Set of 4 narrow-band VCOs with consistent sensitivity vs. frequency
  • RF and tuning ports common to all 4 VCOs
  • RF output operates from fundamental oscillators with no subharmonic oscillations
  • Up to 4 dBm RF output power
  • Power mute capability
  • No external resonator required
  • 40-lead, 6 mm × 6 mm LFCSP

Product Details

The HMC8364 is a gallium arsenide (GaAs), quadband, monolithic microwave integrated circuit (MMIC), voltage controlled oscillator (VCO) designed to offer wideband frequency capabilities without compromising phase noise performance. The device integrates four independent, narrow-band VCOs with overlapping frequency bands, operating at a fundamental frequency range of 18.10 GHz to 26.60 GHz. The consistent tuning sensitivity across all frequency bands simplifies the synthesizer loop filter design.

The tuning port is common to all VCO cores for a simpler design of the phase-locked loop (PLL) feedback path. The HMC8364 also offers a low typical current consumption of 99 mA for power sensitive applications.

The HMC8364 integrates resonators, negative resistance devices, and varactor diodes. The monolithic structure of the oscillator offers very low phase noise, optimal temperature stability, and is immune to vibration and process variation.

The four VCOs are packaged in a single, 6 mm × 6 mm, surface-mount lead frame chip scale package (LFCSP), and require no external matching components. Combined with a high frequency, high performance PLL, the ADF41513, the HMC8364 offers a complete RF or microwave frequency generation solution.


  • Electronic test and measurement
  • Industrial and medical instrumentation
  • Point to point and multipoint radios
  • Aerospace and defense
  • Wireless communication infrastructure

Product Lifecycle icon-recommended Recommended for New Designs

This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.

Evaluation Kits (1)

Tools & Simulations

Design Tools


ADIsimPLL enables the rapid and reliable evaluation of new high performance PLL products from ADI. It is the most comprehensive PLL Synthesizer design and simulation tool available today. Simulations performed include all key non-linear effects that are significant in affecting PLL performance. ADIsimPLL removes at least one iteration from the design process, thereby speeding the design- to-market.

Reference Designs (1)

Product Recommendations

HMC8364 Companion Parts

Recommended Active Loop Filter Op Amps

  • 36 V, 18 MHz, Low Noise, Fast Settling Single Supply, RRO, JFET Op Amp: ADA4625-1.
  • 30 V, Low Noise, Rail-to-Rail Input/Output, Low Power Operational Single Amplifier: ADA4084-1.
  • High Performance, 145 MHz FastFET Op Amps: AD8065.

Recommended LDO

  • 800 mA, Ultra Low Noise/High PSRR LDO: ADM7150.
  • 20V, 200mA, Ultralow Noise, Ultrahigh PSRR RF Linear Regulator: LT3042.

Recommended Divider

  • 0.1 GHz to 24 GHz, Low Noise, Programmable Divider: HMC862A.

Recommended Phase Locked Loop (PLL)

  • 26.5 GHz, Integer N/Fractional-N, PLL Synthesizer: ADF41513.

Recommended Supply Switch

  • 1 Ω Typical On Resistance, ±5 V, +12 V, +5 V, and +3.3 V, 4:1 Multiplexer: ADG1604.
