I/Q Modulators & Demodulators
Analog Devices offers broadband and narrowband IQ modulators and IQ demodulators with excellent dynamic range, suitable for zero IF (ZIF) designs. ADI's IQ modulators and demodulators are commonly used for direct downconversion designs for point to point radio designs, test and measurement instrumentation applications.
Subcategories
Product Selection Table
Latest Resources
Application Notes
- AN-1390: Manual Band Selection for PLL Lock Time Reduction (Rev. 0) PDF
- AN-683: Strain Gage Measurement Using an AC Excitation (Rev. A) PDF
- AN-214: Ground Rules for High Speed Circuits PDF
- AN-920: Gain, LO, and Phase Compensation in a Single Sideband Transmitter Using the AD9788 TxDAC and ADL5372 Quadrature Modulator (Rev. 0) PDF
- AN-1039: Correcting Imperfections in IQ Modulators to Improve RF Signal Fidelity (Rev. 0) PDF
- AN-924: Digital Quadrature Modulator Gain (Rev. A) PDF
- AN-0974: Multicarrier TD-SCMA Feasibility PDF
- AN-0996: The Advantages of Using a Quadrature Digital Upconverter (QDUC) in Point-to-Point Microwave Transmit Systems (Rev. 0) PDF
- AN-808: Multicarrier CDMA2000 Feasibility (Rev. 0) PDF
- AN-826: A 2.4 GHz WiMAX Direct Conversion Transmitter (Rev. B) PDF
- AN-307: Modem-Circuit Techniques Simplify Instrumentation Designs PDF
- AN-306: Synchronous System Measures µs PDF
- AN-349: Keys to Longer Life for CMOS PDF
- AN-308: Commutating Amp Multiplies Precisely PDF
Technical Articles
User Guides
Evaluation Documentation
- ADL5380-29A Archive-obsolete Board Gerber Files ZIP
- ADRF6720 Gerber Files ZIP
- AD8340 Gerber Files ZIP
- ADRF6801 Gerber Files ZIP
- ADRF6704 Gerber Files ZIP
- ADRF6703 Gerber Files ZIP
- ADRF6702 Gerber Files ZIP
- ADRF6701 Gerber Files ZIP
- ADL5390 Gerber Files ZIP
- ADL5387 Gerber Files ZIP
- ADL5386 Gerber Files ZIP
- ADL5385 Gerber Files ZIP
- ADL5382 Gerber Files ZIP
- ADL5380-30A - Archive-obsolete Board Design and Schematics ZIP
- ADL5375-15 Gerber Files ZIP
- ADL5375-05 Gerber Files ZIP
- ADL5374 Gerber Files ZIP
- ADL5373 Gerber Files ZIP
- ADL5372 Gerber Files ZIP
- ADL5371 Gerber Files ZIP
- ADL5370 Gerber Files ZIP
- AD8349 Gerber Files ZIP
- AD8348 Gerber Files ZIP
- AD8347 Gerber Files ZIP
- AD8346 Gerber Files ZIP
- AD8345 Gerber Files ZIP
- AD8341 Gerber Files ZIP
Circuit Notes
Technical Books
Webcast
Videos
Tutorials
Press Releases
Rarely Asked Questions
I/Q Modulators & Demodulators
| SortOrder | Part# | RF Primary Function | Freq Response RF (min) (Hz) | Freq Response RF (max) (Hz) | Freq BB 3 dB BW (typ) (Hz) | IIP3 (typ) (dBm) | OIP3 (typ) (dBm) | Is (typ) (A) | Vs | Price (1000+) ($ US) |
|---|---|---|---|---|---|---|---|---|---|---|
| 1 | ADMV1013 | I/Q Modulators, IQ Upconverters/Transmitters | 24G | 44G | 6G | - | 23 | 550m | 1.5 V, 1.8 V, 3.3 V | $90.79 (ADMV1013ACCZ) |
| 2 | ADMV1014 | Downconverting Mixer, I/Q Demodulators, I/Q Downconverters/Receivers, Microwave and mmWave Tx/Rx | 24G | 44G | 6G | 0 | - | 500m | 1.5 V, 1.8 V, 3.3 V | $88.37 (ADMV1014ACCZ) |
| 3 | LTC5594 | I/Q Demodulator with Output Amplifiers, I/Q Demodulators | 300M | 9G | 1G | 30.8 | 40 | 470m | 5 | $15.70 (LTC5594IUH#PBF) |
| 4 | ADRF6821 | I/Q Demodulator w/ LO | 450M | 2.8G | 1G | - | 32 | 545m | 3.3 | $15.58 (ADRF6821ACPZ) |
| 5 | LTC5589 | I/Q Modulators | 700M | 6G | 167M | - | 17.5 | 29.5m | 3, 3.3 | $4.45 (LTC5589IUF#PBF) |
| 6 | LTC5586 | I/Q Demodulators | 300M | 6G | 1G | 30 | - | 440m | 5 | $7.79 (LTC5586IUH#PBF) |
| 7 | ADRF6780 | I/Q Modulators, IQ Upconverters/Transmitters | 5.9G | 23.6G | 750M | - | 27 | 521m | 1.8 V, 3.3 V, 5 V | - |
| 8 | LTC5599 | I/Q Modulators | 30M | 1.3G | 57M | - | 20.8 | 28m | 3, 3.3 | $4.45 (LTC5599IUF#PBF) |
| 9 | ADRF6720-27 | I/Q Mod w/ LO | 400M | 3G | 1G | 31.1 | 31.1 | 425m | 3.3 | $7.95 (ADRF6720-27ACPZ-R7) |
| 10 | ADRF6720 | I/Q Modulator w/ LO | 700M | 3G | 1G | - | 35.7 | 420m | 3.3 | $7.95 (ADRF6720ACPZ-R7) |
| 11 | ADRF6820 | I/Q Demodulator w/ LO | 695M | 2.7G | 1.4G | 37 | - | 220m | 3.3, 5 | $12.98 (ADRF6820ACPZ-R7) |
| 12 | LTC5584 | I/Q Demodulators | 30M | 1.4G | 530M | 31 | - | 200m | 5 | $5.65 (LTC5584IUF#PBF) |
| 13 | HMC1197 | I/Q Modulator w/ LO | 100M | 4G | 600M | - | 30 | 320m | 3.3, 5 | - |
| 14 | ADRF6755 | I/Q Modulator w/ LO | 300M | 2.31G | 600M | 20.5 | 21 | 350m | 5 | $7.99 (ADRF6755ACPZ) |
| 15 | LTC5585 | I/Q Demodulators | 700M | 3G | 530M | 28.7 | - | 200m | 5 | $5.98 (LTC5585IUF#PBF) |
| 16 | HMC1097 | I/Q Modulators | 100M | 6G | 700M | - | 29 | 170m | 3.3, 5 | - |
| 17 | ADRF6807 | I/Q Demodulator w/ LO | 700M | 1.05G | 170M | 26.7 | - | 86m | 5 | $9.98 (ADRF6807ACPZ-R7) |
| 18 | ADRF6704 | I/Q Modulator w/ LO | 2.05G | 3G | 750M | 27.2 | 27.2 | 226m | 5 | $7.00 (ADRF6704ACPZ-R7) |
| 19 | ADRF6701 | I/Q Modulator w/ LO | 400M | 1.25G | 750M | - | 31.7 | 240m | 5 | $7.00 (ADRF6701ACPZ-R7) |
| 20 | ADRF6703 | I/Q Modulator w/ LO | 1.55G | 2.65G | 750M | 32.7 | 32.7 | 240m | 5 | $7.00 (ADRF6703ACPZ-R7) |
| 21 | ADRF6702 | I/Q Modulator w/ LO | 1.2G | 2.4G | 750M | 30.1 | 30.1 | 240m | 5 | $7.00 (ADRF6702ACPZ-R7) |
| 22 | ADRF6801 | Digitally Controlled Attenuator | 750M | 1.15G | 275M | 25 | - | 262m | 5 | $9.98 (ADRF6801ACPZ-R7) |
| 23 | ADRF6850 | I/Q Demodulator w/ LO | 100M | 1G | 300M | 22.5 | - | 350m | 3, 3.3 | $9.98 (ADRF6850BCPZ) |
| 24 | ADRF6806 | I/Q Demodulator w/ LO | 50M | 525M | 170M | 28.5 | - | 86m | 3, 5 | $9.98 (ADRF6806ACPZ-R7) |
| 25 | LTC5588-1 | I/Q Modulators | 200M | 6G | 500M | - | 30.9 | 303m | 3.3 | $5.70 (LTC5588IPF-1#PBF) |
| 26 | HMC795 | I/Q Modulators | 50M | 2.8G | 440M | - | 25 | 120m | 3.3, 5 | - |
| 27 | ADRF6750 | I/Q Modulator w/ LO | 950M | 1.575G | 600M | 23 | 23 | 310m | 5 | $7.24 (ADRF6750ACPZ-R7) |
| 28 | ADL5380 | I/Q Demodulators | 400M | 6G | 390M | 27.8 | - | 245m | 5 | $5.28 (ADL5380ACPZ-R7) |
| 29 | LTC5598 | I/Q Modulators | 5M | 1.6G | 400M | - | 25.5 | 165m | 5 | $5.19 (LTC5598IUF#PBF) |
| 30 | ADL5386 | I/Q Modulators | 50M | 2.2G | 700M | 25 | 25 | 230m | 5 | $5.29 (ADL5386ACPZ-R7) |
| 31 | ADL5382 | I/Q Demodulators | 700M | 2.7G | 370M | 30.5 | - | 220m | 5 | $5.28 (ADL5382ACPZ-R7) |
| 32 | ADL5375 | I/Q Modulators | 400M | 6G | 750M | 23.4 | 26.8 | 194m | 5 | $5.04 (ADL5375-15ACPZ-WP) |
| 33 | ADL5387 | I/Q Demodulators | 30M | 2G | 240M | 31 | - | 180m | 5 | $5.28 (ADL5387ACPZ-R7) |
| 34 | AD8339 | I/Q Demodulators | 0 | 50M | 50M | 31 | - | 35m | +/-5 | $12.09 (AD8339ACPZ) |
| 35 | ADL5373 | I/Q Modulators | 2.3G | 3G | 500M | - | 26 | 174m | 5 | $5.04 (ADL5373ACPZ-R7) |
| 36 | LT5568-2 | I/Q Modulators | 600M | 1.1G | 380M | - | 22.9 | 110m | 5 | $5.35 (LT5568-2EUF#PBF) |
| 37 | ADL5591 | I/Q Modulators | 805M | 1.905G | 250M | - | 30 | 170m | 5 | $4.98 (ADL5591ACPZ-R7) |
| 38 | ADL5590 | I/Q Modulators | 869M | 900M | 250M | - | 29 | 170m | 5 | $4.98 (ADL5590ACPZ-R7) |
| 39 | ADL5372 | I/Q Modulators | 1.5G | 2.5G | 500M | 27 | 27 | 165m | 5 | $5.04 (ADL5372ACPZ-R7) |
| 40 | ADL5371 | I/Q Modulators | 500M | 1.5G | 500M | - | 27 | 175m | 5 | $5.04 (ADL5371ACPZ-R7) |
| 41 | ADL5385 | I/Q Modulators | 300M | 2.2G | 500M | 26 | 26 | 215m | 5 | $5.04 (ADL5385ACPZ-R7) |
| 42 | ADL5370 | I/Q Modulators | 300M | 1G | 500M | - | 24 | 205m | 5 | $5.04 (ADL5370ACPZ-R7) |
| 43 | LT5558 | I/Q Modulators | 600M | 1.1G | 400M | - | 22.4 | 108m | 5 | $5.35 (LT5558EUF#PBF) |
| 44 | LT5575 | I/Q Demodulators | 800M | 2.7G | 490M | 28 | - | 132m | 5 | $7.75 (LT5575EUF#PBF) |
| 45 | LT5571 | I/Q Modulators | 620M | 1.1G | 400M | - | 21.7 | 97m | 5 | $4.95 (LT5571EUF#PBF) |
| 46 | LT5568 | I/Q Modulators | 600M | 1.2G | 380M | - | 22.9 | 117m | 5 | $5.35 (LT5568EUF#PBF) |
| 47 | AD8333 | I/Q Demodulators | 0 | 50M | 50M | 30 | - | 44m | +/-5 | $9.06 (AD8333ACPZ-REEL7) |
| 48 | LT5572 | I/Q Modulators | 1.5G | 2.5G | 460M | - | 21.6 | 120m | 5 | $4.95 (LT5572EUF#PBF) |
| 49 | LT5518 | I/Q Modulators | 1.5G | 2.4G | 400M | - | 22.8 | 128m | 5 | $4.95 (LT5518EUF#PBF) |
| 50 | LT5528 | I/Q Modulators | 1.5G | 2.4G | 400M | - | 21.8 | 125m | 5 | $4.95 (LT5528EUF#PBF) |
