惯性测量单元(IMUs)

Analog Devices, Inc.（简称ADI）备受好评的惯性测量单元(IMU)包括ADI iSensor 智能传感器加速度计和陀螺仪。ADI IMU是高度集成器件，可以检测多个轴上的运动，包括运动类型、速率和方向。IMU利用多个加速度计和陀螺仪惯性检测器件的组合输入，就能够借助单一器件来测量复杂应用中的多个自由度(DoF)。了解有关 惯性检测的更多信息。

ADI公司提供广泛的接口兼容型IMU解决方案，各芯片的集成度高，并且所有复杂、关键的IMU校准和补偿均由ADI公司完成，因此系统开发时间可减少达12个月。客户无需购买测试设备，可以节省大笔投资；同时可以让设计人员确信器件将能提供精确而稳定的反馈信息。这些器件还配有简单的可编程接口，确保器件打开包装就能与系统集成，使用极为便捷。

Inertial Sensors

新产品

资源与相关信息

Up
Up
Up
Up

正在加载选型表数据，请稍候...

Processing request. Please wait.

帮助

  • Sort: Click on the arrows beneath the parameter on which you would like to sort, ascending and descending order.

  • Add/Remove Parameters: Click on the Add/Remove Parameters button. Select/deselect the checkbox of the parameter in the add/remove parameter pop up box. Click on "Update" for the table to redraw with new selection of parameters.

  • Filter: Enter the desired value to filter parameter(s) by, and click the "Update Results" button to update the table display.

  • Reset Table: Click "Reset Table" to clear all filters/sorts and restore table back to default view.

  • Quick Filters: When applicable, select a quick filter with preset parameters filtered to narrow the results returned.

  • No Parts Returned: Adjust the filters on your least critical selection parameters in order to broaden your search.

Inertial Measurement Units (IMU)
  • Use Up or Down Arrows in Heading to Sort in Ascending or Descending Order
  • Narrow Results by Entering Values in Numeric Fields or by Pull Down Selections

添加/移除参数










Part#
Results: 9
Product DescriptionRangeSensitivityTypical Bandwidth (kHz)Noise Density (°/s/rtHz)Voltage Supply (V)Supply Current Temp Range (°C)Package
Sort
sortDescending sortAscending

sortDescending sortAscending
sortDescending sortAscending
sortDescending sortAscending
sortDescending sortAscending
sortDescending sortAscending
sortDescending sortAscending
Filter By Value

ADIS163004 DoF Inertial Sensor +/- 75 to +/- 300 °/s 0.0125°/s/LSB (+/-75°/s) 0.330.0384.75 to 5.2546.2mA-40 to 85°C(31 x 23 x 7.5) mm Mod
ADIS163506 DoF Sensor (room temp CAL) +/- 75 to +/- 300 °/s 0.0183 °/s/LSB (+/-80°/s)0.350.054.75 to 5.2557mA-40 to 85°C23 mm x 23 mm x 23 mm Mod
ADIS163546 DoF Sensor (-20 to 70C CAL) +/- 75 to +/- 300 °/s 0.0183 °/s/LSB (+/-80°/s)0.350.054.75 to 5.2557mA-40 to 85°C23 mm x 23 mm x 23 mm Mod
ADIS163556 DoF Sensor (-40 to 85C CAL +/- 75 to +/- 300 °/s 0.0183 °/s/LSB (+/-80°/s)0.350.054.75 to 5.2557mA-40 to 85°C23 mm x 23 mm x 23 mm Mod
ADIS163606 DoF Sensor (Room Temp CAL) +/- 75 to +/- 300 °/s 0.0125°/s/LSB (+/-75°/s) 0.330.054.75 to 5.2549mA-40 to 105°C 23 mm x 23 mm x 23 mm Mod
ADIS163626 DoF Inertial Sensor (-20 to 70C CAL)+/- 75 to 300 °/s 0.0125°/s/LSB (+/-75°/s) 0.330.0444.75 to 5.2549mA-40 to 105°C 23 mm x 23 mm x 23 mm Mod
ADIS163646 DoF Sensor (-20 to 70C CAL) +/- 75 to 300 °/s 0.0125°/s/LSB (+/-75°/s) 0.330.054.75 to 5.2549mA-40 to 105°C 23 mm x 23 mm x 23 mm Mod
ADIS163656 DoF Sensor (-40 to 85C CAL) +/- 75 to +/- 300 °/s 0.0125°/s/LSB (+/-75°/s) 0.330.054.75 to 5.2549mA-40 to 105°C 23 mm x 23 mm x 23 mm Mod
ADIS16405High Precision Tri-Axis Gyroscope, Accelerometer, Magnetometer (with Temp CAL) +/- 75 to +/- 300 °/s 0.0125°/s/LSB (+/-75°/s) 0.330.054.75 to 5.2570mA-40 to 105°C 23 mm x 23 mm x 23 mm Mod
Please scroll down to see more data.
