| Part# | Small Signal Bandwidth | Slew Rate | Input Offset Voltage | Amplifiers Per Package | V Span Min | V Span Max | US Price 1000-4999 | Package |
|---|---|---|---|---|---|---|---|---|
| AD549 | 1MHz | 3V/µs | 500µV | 1 | 10V | 36V |
$ | TO-X |
| AD704 | 800KHz | 150mV/µs | 30µV | 4 | 4V | 36V |
$ | DIP, LCC, SOIC |
| AD706 | 800KHz | 150mV/µs | 30µV | 2 | 4V | 36V |
$ | DIP, SOIC |
| AD708 | 900KHz | 300mV/µs | 30µV | 2 | 6V | 36V |
$ | DIP |
| AD711 | 4MHz | 20V/µs | 300µV | 1 | 9V | 36V |
$ | DIP, SOIC |
| AD712 | 4MHz | 20V/µs | 300µV | 2 | 9V | 36V |
$ | DIP, SOIC |
| AD713 | 4MHz | 20V/µs | 300µV | 4 | 9V | 36V |
$ | DIP, SOIC |
| AD743 | 4.5MHz | 2.8V/µs | 250µV | 1 | 9.6V | 36V |
$ | DIP, SOIC |
| AD745 | 20MHz | 12.5V/µs | 250µV | 1 | 9.6V | 36V |
$ | DIP, SOIC |
| AD746 | 13MHz | 75V/µs | 300µV | 2 | 9.6V | 36V |
$ | DIP, SOIC |
| AD795 | 1.6MHz | 1V/µs | 100µV | 1 | 8V | 36V |
$ | SOIC |
| AD797 | 8MHz | 20V/µs | 25µV | 1 | 10V | 36V |
$ | DIP, SOIC |
| AD8000 | 1.58GHz | 4.1KV/µs | 1mV | 1 | 4.5V | 12V |
$ | CSP, SOIC |
| AD8001 | 880MHz | 1KV/µs | 2mV | 1 | 6V | 12V |
$ | DIP, SOIC, SOT |
| AD8002 | 600MHz | 1.2KV/µs | 2mV | 2 | 6V | 12V |
$ | DIP, SOIC, SOP |
| AD8003 | 1.65GHz | 3.8KV/µs | 700µV | 3 | 4.5V | 10V |
$ | CSP |
| AD8004 | 250MHz | 3KV/µs | 1mV | 4 | 4V | 12V |
$ | DIP, SOIC |
| AD8005 | 270MHz | 1.5KV/µs | 5mV | 1 | 4V | 12V |
$ | DIP, SOIC, SOT |
| AD8007 | 650MHz | 1KV/µs | 500µV | 1 | 5V | 12V |
$ | SC70, SOIC |
| AD8008 | 650MHz | 1KV/µs | 500µV | 2 | 5V | 12V |
$ | SOIC, SOP |
| AD8009 | 1GHz | 5.5KV/µs | 2mV | 1 | 5V | 12V |
$ | SOIC, SOT |
| AD8010 | 230MHz | 800V/µs | 5mV | 1 | 9V | 12V |
$ | DIP, SOIC |
| AD8011 | 400MHz | 3.5KV/µs | 2mV | 1 | 3V | 12V |
$ | DIP, SOIC |
| AD8012 | 350MHz | 2.25KV/µs | 1mV | 2 | 3V | 12V |
$ | SOIC, SOP |
| AD8013 | 480MHz | 1KV/µs | 2mV | 3 | 4.2V | 13V |
$ | DIP, SOIC |
| AD8014 | 400MHz | 4KV/µs | 2mV | 1 | 4.5V | 12V |
$ | SOIC, SOT |
| AD8016 | 380MHz | 1KV/µs | 1mV | 2 | 6V | 26V |
$ | SOIC |
| AD8017 | 160MHz | 1.6KV/µs | 1.8mV | 2 | 4.4V | 12V |
$ | SOIC |
| AD8018 | 130MHz | 300V/µs | 1mV | 2 | 3.3V | 8V |
$ | SOIC, SOP |
| AD8021Reference Circuit Available | 490MHz | 150V/µs | 400µV | 1 | 4.5V | 24V |
$ | SOIC, SOP |
| AD8022Reference Circuit Available | 130MHz | 50V/µs | 1.5mV | 2 | 4.5V | 26V |
$ | SOIC, SOP |
| AD8023 | 125MHz | 1.2KV/µs | 2mV | 3 | 4.2V | 15V |
$ | SOIC |
| AD8024 | 200MHz | 390V/µs | 2mV | 4 | 5V | 24V |
$ | SOIC |
| AD8027 | 190MHz | 100V/µs | 200µV | 1 | 2.7V | 12V |
$ | SOIC, SOT |
| AD8028 | 190MHz | 100V/µs | 200µV | 2 | 2.7V | 12V |
$ | SOIC, SOP |
| AD8029 | 125MHz | 62V/µs | 1.6mV | 1 | 2.7V | 12V |
$ | SC70, SOIC |
| AD8030 | 125MHz | 62V/µs | 1.6mV | 2 | 2.7V | 14V |
$ | SOIC, SOT |
| AD8031Reference Circuit Available | 80MHz | 35V/µs | 1mV | 1 | 2.7V | 12V |
$ | DIP, SOIC, SOT |
| AD8032Reference Circuit Available | 80MHz | 35V/µs | 1mV | 2 | 2.7V | 12V |
$ | DIP, SOIC, SOP |
| AD8033 | 80MHz | 80V/µs | 1mV | 1 | 5V | 24V |
$ | SC70, SOIC |
| AD8034Reference Circuit Available | 80MHz | 70V/µs | 1mV | 2 | 5V | 24V |
$ | SOIC, SOT |
| AD8036 | 240MHz | 1.2KV/µs | 2mV | 1 | 6V | 12V |
$ | DIP, SOIC |
| AD8037 | 270MHz | 1.5KV/µs | 2mV | 1 | 6V | 12V |
$ | DIP, SOIC |
| AD8038Reference Circuit Available | 350MHz | 425V/µs | 500µV | 1 | 3V | 12V |
$ | SC70, SOIC |
| AD8039 | 350MHz | 425V/µs | 500µV | 2 | 3V | 12V |
$ | SOIC, SOT |
| AD8040 | 125MHz | 62V/µs | 1.6mV | 4 | 2.7V | 12V |
$ | SOIC, SOP |
| AD8041 | 170MHz | 170V/µs | 2mV | 1 | 3V | 12V |
$ | DIP, SOIC |
| AD8042Reference Circuit Available | 170MHz | 225V/µs | 3mV | 2 | 3V | 12V |
$ | DIP, SOIC |
| AD8044 | 160MHz | 190V/µs | 1.4mV | 4 | 3V | 12V |
$ | DIP, SOIC |
| AD8045 | 1GHz | 1.35KV/µs | 200µV | 1 | 3.3V | 12V |
$ | CSP, SOIC |
| AD8047 | 250MHz | 750V/µs | 1mV | 1 | 6V | 12V |
$ | DIP, SOIC |
| AD8048 | 260MHz | 1KV/µs | 1mV | 1 | 6V | 12V |
$ | DIP, SOIC |
| AD8051 | 110MHz | 170V/µs | 1.7mV | 1 | 3V | 12V |
$ | SOIC, SOT |
| AD8052 | 110MHz | 170V/µs | 1.7mV | 2 | 3V | 12V |
$ | SOIC, SOP |
| AD8054 | 150MHz | 190V/µs | 1.7mV | 4 | 3V | 12V |
$ | SOIC, SOP |
| AD8055 | 300MHz | 1.4KV/µs | 3mV | 1 | 8V | 12V |
$ | DIP, SOIC, SOT |
| AD8056 | 300MHz | 1.4KV/µs | 3mV | 2 | 8V | 12V |
$ | DIP, SOIC, SOP |
| AD8057 | 325MHz | 1.15KV/µs | 1mV | 1 | 3V | 12V |
$ | SOIC, SOT |
| AD8058 | 325MHz | 1.15KV/µs | 1mV | 2 | 3V | 12V |
$ | SOIC, SOP |
| AD8061 | 320MHz | 650V/µs | 1mV | 1 | 2.7V | 8V |
$ | SOIC, SOT |
| AD8062 | 320MHz | 650V/µs | 1mV | 2 | 2.7V | 8V |
$ | SOIC, SOP |
| AD8063 | 320MHz | 650V/µs | 1mV | 1 | 2.7V | 8V |
$ | SOIC, SOT |
| AD8065Reference Circuit Available | 145MHz | 180V/µs | 400µV | 1 | 5V | 24V |
$ | SOIC, SOT |
| AD8066Reference Circuit Available | 145MHz | 180V/µs | 400µV | 2 | 5V | 24V |
$ | SOIC, SOP |
| AD8067 | 54MHz | 640V/µs | 200µV | 1 | 5V | 24V |
$ | SOT |
| AD8072 | 100MHz | 500V/µs | 2mV | 2 | 5V | 12V |
$ | DIP, SOIC |
| AD8073 | 100MHz | 500V/µs | 2mV | 3 | 5V | 12V |
$ | DIP, SOIC |
| AD8074 | 600MHz | 1.6KV/µs | 2.5mV | 3 | 9V | 11V |
$ | SOP |
| AD8075 | 550MHz | 1.35KV/µs | 2.5mV | 3 | 9V | 11V |
$ | SOP |
| AD8079 | 260MHz | 800V/µs | 5mV | 2 | 6V | 12V |
$ | SOIC |
| AD8091 | 110MHz | 170V/µs | 1.6mV | 1 | 3V | 12V |
$ | SOIC, SOT |
| AD8092 | 110MHz | 170V/µs | 1.6mV | 2 | 3V | 12V |
$ | SOIC, SOP |
| AD8099 | 500MHz | 1.35KV/µs | 200µV | 1 | 5V | 12V |
$ | CSP, SOIC |
| AD810 | 80MHz | 1KV/µs | 1.5mV | 1 | 5V | 36V |
$ | DIP, SOIC |
| AD811 | 140MHz | 2.5KV/µs | 500µV | 1 | 9V | 36V |
$ | DIP, LCC, SOIC |
| AD812 | 145MHz | 425V/µs | 2mV | 2 | 2.4V | 36V |
$ | DIP, SOIC |
| AD813 | 100MHz | 250V/µs | 2mV | 3 | 2.4V | 36V |
$ | DIP, LCC, SOIC |
| AD815 | 120MHz | 900V/µs | 10mV | 2 | 10V | 36V |
$ | DDPAK, SIP, SOIC |
| AD817 | 50MHz | 350V/µs | 500µV | 1 | 5V | 36V |
$ | DIP, SOIC |
| AD818 | 130MHz | 500V/µs | 500µV | 1 | 5V | 36V |
$ | DIP, SOIC |
| AD820 | 1.9MHz | 3V/µs | 100µV | 1 | 5V | 36V |
$ | DIP, SOIC, SOP |
| AD822Reference Circuit Available | 1.9MHz | 3V/µs | 100µV | 2 | 5V | 30V |
$ | DIP, SOIC, SOP |
| AD823 | 16MHz | 25V/µs | 700µV | 2 | 3V | 36V |
$ | DIP, SOIC |
| AD824 | 2MHz | 2V/µs | 500µV | 4 | 3V | 36V |
$ | SOIC |
| AD825 | 46MHz | 140V/µs | 1mV | 1 | 10V | 36V |
$ | SOIC |
| AD826 | 50MHz | 350V/µs | 500µV | 2 | 5V | 36V |
$ | DIP, SOIC |
| AD827 | 50MHz | 300V/µs | 500µV | 2 | 9V | 36V |
$ | DIP, LCC, SOIC |
| AD828 | 130MHz | 450V/µs | 500µV | 2 | 5V | 36V |
$ | DIP, SOIC |
| AD829 | 120MHz | 230V/µs | 200µV | 1 | 9V | 36V |
$ | DIP, LCC, SOIC |
| AD8397 | 69MHz | 53V/µs | 1mV | 2 | 3V | 24V |
$ | SOIC |
| AD8432 | 200MHz | 170V/µs | 1mV | 2 | 4.5V | 5.5V |
$ | CSP |
| AD844 | 60MHz | 2KV/µs | 50µV | 1 | 9V | 36V |
$ | DIP, SOIC |
| AD847 | 50MHz | 300V/µs | 500µV | 1 | 9V | 36V |
$ | DIP, SOIC |
| AD8500 | 7KHz | 4mV/µs | 235µV | 1 | 1.8V | 5.5V |
$ | SC70 |
| AD8502 | 7KHz | 4mV/µs | 500µV | 2 | 1.8V | 5.5V |
$ | SOT-23 |
| AD8504 | 7KHz | 4mV/µs | 500µV | 4 | 1.8V | 5.5V |
$ | SOP |
| AD8505 | 95Hz | 13mV/µs | 500µV | 1 | 1.8V | 5V |
$ | SOT-23 |
| AD8506 | 150KHz | 13mV/µs | 2.5mV | 2 | 1.8V | 5.5V |
$ | CSP, SOP |
| AD8508 | 95KHz | 13mV/µs | 500µV | 4 | 1.8V | 5V |
$ | CSP, SOP |
| AD8509 | - | 7V/µs | 20mV | 9 | 3.3V | 6.5V |
$ | CSP |
| AD8510Reference Circuit Available | 8MHz | 20V/µs | 80µV | 1 | 9V | 36V |
$ | SOIC, SOP |
| AD8512Reference Circuit Available | 8MHz | 20V/µs | 80µV | 2 | 9V | 36V |
$ | SOIC, SOP |
| AD8513 | 8MHz | 20V/µs | 80µV | 4 | 9V | 36V |
$ | SOIC, SOP |
| AD8515Reference Circuit Available | 5MHz | 2.7V/µs | 1mV | 1 | 1.8V | 6V |
$ | SC70, SOT |
| AD8519 | 8MHz | 2.9V/µs | 600µV | 1 | 2.7V | 12V |
$ | SC70, SOIC, SOT |
| AD8529 | 8MHz | 2.9V/µs | 600µV | 2 | 2.7V | 12V |
$ | SC70, SOIC, SOP |
| AD8531 | 3MHz | 5V/µs | 25mV | 1 | 2.7V | 6V |
$ | SC70, SOIC, SOT |
| AD8532 | 3MHz | 5V/µs | 25mV | 2 | 3V | 6V |
$ | SOIC, SOP |
| AD8534 | 3MHz | 5V/µs | 25mV | 4 | 3V | 6V |
$ | SOIC, SOP |
| AD8538 | 430KHz | 400mV/µs | 5µV | 1 | 2.7V | 5.5V |
$ | SOIC, SOT |
| AD8539 | 430KHz | 400mV/µs | 5µV | 2 | 2.7V | 5.5V |
$ | SOIC, SOP |
| AD8541Reference Circuit Available | 1MHz | 920mV/µs | 1mV | 1 | 2.7V | 5.5V |
$ | SC70, SOIC, SOT-23 |
| AD8542 | 1MHz | 920mV/µs | 1mV | 2 | 2.7V | 5.5V |
$ | SOIC, SOP |
| AD8544 | 1MHz | 920mV/µs | 1mV | 4 | 2.7V | 5.5V |
$ | SOIC, SOP |
| AD8551 | 1.5MHz | 400mV/µs | 1µV | 1 | 2.7V | 6V |
$ | SOIC, SOP |
| AD8552 | 1.5MHz | 400mV/µs | 1µV | 2 | 2.7V | 5.5V |
$ | SOIC, SOP |
| AD8554 | 1.5MHz | 400mV/µs | 1µV | 4 | 2.7V | 5.5V |
$ | SOIC, SOP |
| AD8565 | 5MHz | 6V/µs | 2mV | 1 | 4.5V | 16V |
$ | SC70 |
| AD8566 | 5MHz | 6V/µs | 2mV | 2 | 4.5V | 16V |
$ | SOIC, SOP |
| AD8567 | 5MHz | 6V/µs | 2mV | 4 | 4.5V | 16V |
$ | CSP, SOP |
| AD8571 | 1.5MHz | 400mV/µs | 1µV | 1 | 2.7V | 6V |
$ | SOIC, SOP |
| AD8572 | 1.5MHz | 400mV/µs | 1µV | 2 | 2.7V | 6V |
$ | SOIC, SOP |
| AD8574 | 1.5MHz | 400mV/µs | 1µV | 4 | 2.7V | 6V |
$ | SOIC, SOP |
| AD8591 | 5MHz | 3.5V/µs | 25mV | 1 | 2.5V | 6V |
$ | SOT |
| AD8592 | 2.2MHz | 3.5V/µs | 25mV | 2 | 2.5V | 6V |
$ | SOIC, SOP |
| AD8594 | 2.2MHz | 3.5V/µs | 25mV | 4 | 2.5V | 6V | ** | SOIC, SOP |
| AD8597Reference Circuit Available | 10MHz | 14V/µs | 10µV | 1 | 10V | 36V |
$ | CSP, SOIC |
| AD8599Reference Circuit Available | 10MHz | 16.8V/µs | 10µV | 2 | 9V | 30V |
$ | SOIC |
| AD8601Reference Circuit Available | 8.4MHz | 6V/µs | 500µV | 1 | 2.7V | 6V |
$ | SOT |
| AD8602 | 8.4MHz | 6V/µs | 500µV | 2 | 2.7V | 6V |
$ | SOIC, SOP |
| AD8603Reference Circuit Available | 400KHz | 100mV/µs | 12µV | 1 | 1.8V | 6V |
$ | SOT |
| AD8604 | 8.4MHz | 6V/µs | 500µV | 4 | 2.7V | 6V |
$ | SOIC, SOP |
| AD8605Reference Circuit Available | 10MHz | 5V/µs | 20µV | 1 | 2.7V | 6V |
$ | SOT |
| AD8606Reference Circuit Available | 10MHz | 5V/µs | 20µV | 2 | 2.7V | 6V |
$ | SOIC, SOP |
| AD8607 | 400KHz | 100mV/µs | 12µV | 2 | 1.8V | 5V |
$ | SOIC, SOP |
| AD8608Reference Circuit Available | 10MHz | 5V/µs | 20µV | 4 | 2.7V | 6V |
$ | SOIC, SOP |
| AD8609Reference Circuit Available | 400KHz | 100mV/µs | 12µV | 4 | 1.8V | 5V |
$ | SOIC, SOP |
| AD8610Reference Circuit Available | 25MHz | 60V/µs | 75µV | 1 | 10V | 27V |
$ | SOIC, SOP |
| AD8613 | 400KHz | 100mV/µs | 400µV | 1 | 1.8V | 5V |
$ | SC70, SOT |
| AD8614 | 5.5MHz | 7.5V/µs | 1mV | 1 | 5V | 18V |
$ | SOT |
| AD8615Reference Circuit Available | 23MHz | 12V/µs | 80µV | 1 | 2.7V | 6V |
$ | SOIC, SOP, SOT |
| AD8616 | 24MHz | 12V/µs | 23µV | 2 | 2.7V | 6V |
$ | SOIC, SOP |
| AD8617Reference Circuit Available | 400KHz | 100mV/µs | 400µV | 2 | 1.8V | 5V |
$ | SOIC, SOP |
| AD8618Reference Circuit Available | 24MHz | 12V/µs | 23µV | 4 | 2.7V | 6V |
$ | SOIC, SOP |
| AD8619 | 400KHz | 100mV/µs | 400µV | 4 | 1.8V | 5V |
$ | SOIC, SOP |
| AD8620Reference Circuit Available | 25MHz | 50V/µs | 85µV | 2 | 10V | 27V |
$ | SOIC |
| AD8622Reference Circuit Available | 560KHz | 280mV/µs | 10µV | 2 | 5V | 30V |
$ | SOIC, SOP |
| AD8624 | 560KHz | 480mV/µs | 10µV | 4 | 4V | 36V |
$ | CSP, SOP |
| AD8625 | 5MHz | 5V/µs | 50µV | 4 | 5V | 26V |
$ | SOIC, SOP |
| AD8626 | 5MHz | 5V/µs | 50µV | 2 | 5V | 26V |
$ | SOIC, SOP |
| AD8627Reference Circuit Available | 5MHz | 5V/µs | 50µV | 1 | 5V | 26V |
$ | SC70, SOIC |
| AD8628Reference Circuit Available | 2.5MHz | 1V/µs | 1µV | 1 | 2.7V | 6V |
$ | SOIC, SOT |
| AD8629Reference Circuit Available | 2.5MHz | 1V/µs | 1µV | 2 | 2.7V | 6V |
$ | SOIC, SOP |
| AD8630 | 2.5MHz | 1V/µs | 1µV | 4 | 2.7V | 6V |
$ | SOP |
| AD8638Reference Circuit Available | 1.5MHz | 2V/µs | 3µV | 1 | 5V | 16V |
$ | SOIC, SOT-23 |
| AD8639 | 1.5MHz | 2V/µs | 3µV | 2 | 5V | 16V |
$ | CSP, SOP |
| AD8641Reference Circuit Available | 3.5MHz | 3V/µs | 50µV | 1 | 5V | 26V |
$ | SC70, SOIC |
| AD8642 | 3.5MHz | 3V/µs | 50µV | 2 | 5V | 26V |
$ | SOIC, SOP |
| AD8643 | 3.5MHz | 3V/µs | 50µV | 4 | 5V | 26V |
$ | CSP, SOIC |
| AD8644 | 5.5MHz | 7.5V/µs | 1mV | 4 | 5V | 18V |
$ | SOIC, SOP |
| AD8646Reference Circuit Available | 24MHz | 11V/µs | 600µV | 2 | 2.7V | 5.5V |
$ | SOIC, SOP |
| AD8647 | 24MHz | 11V/µs | 600µV | 2 | 2.7V | 5.5V |
$ | SOP |
| AD8648 | 22MHz | 12V/µs | 700µV | 4 | 2.7V | 5.5V |
$ | SOIC, SOP |
| AD8651 | 50MHz | 41V/µs | 100µV | 1 | 2.7V | 5.5V |
$ | SOIC, SOP |
| AD8652 | 50MHz | 41V/µs | 100µV | 2 | 2.7V | 5.5V |
$ | SOIC, SOP |
| AD8655Reference Circuit Available | 28MHz | 11V/µs | 50µV | 1 | 2.7V | 5.5V |
$ | SOIC, SOP |
| AD8656 | 28MHz | 11V/µs | 50µV | 2 | 2.7V | 5.5V |
$ | SOIC, SOP |
| AD8657Reference Circuit Available | 200KHz | 70mV/µs | 350µV | 2 | 2.7V | 18V |
$ | CSP, SOP |
| AD8659 | 230KHz | 80mV/µs | 350µV | 4 | 2.7V | 18V |
$ | SOIC |
| AD8661 | 4MHz | 3.5V/µs | 30µV | 1 | 5V | 16V |
$ | CSP, SOIC |
| AD8662Reference Circuit Available | 4MHz | 3.5V/µs | 1mV | 2 | 5V | 16V |
$ | SOIC, SOP |
| AD8663Reference Circuit Available | 540KHz | 300mV/µs | 30µV | 1 | 5V | 16V |
$ | CSP, SOIC |
| AD8664 | 4MHz | 3.5V/µs | 50µV | 4 | 5V | 16V |
$ | SOIC, SOP |
| AD8665 | 4MHz | 3.5V/µs | 600µV | 1 | 5V | 16V |
$ | SOIC, SOT |
| AD8666 | 4MHz | 3.5V/µs | 600µV | 2 | 5V | 16V |
$ | SOIC, SOP |
| AD8667 | 520KHz | 260mV/µs | 30µV | 2 | 5V | 16V |
$ | SOIC, SOP |
| AD8668 | 4MHz | 3.5V/µs | 600µV | 4 | 5V | 16V |
$ | SOIC, SOP |
| AD8669 | 520KHz | 260mV/µs | 30µV | 4 | 5V | 16V |
$ | SOIC, SOP |
| AD8671 | 10MHz | 4V/µs | 20µV | 1 | 10V | 36V |
$ | SOIC, SOP |
| AD8672Reference Circuit Available | 10MHz | 4V/µs | 20µV | 2 | 10V | 36V |
$ | SOIC, SOP |
| AD8674 | 10MHz | 4V/µs | 20µV | 4 | 10V | 36V |
$ | SOIC, SOP |
| AD8675Reference Circuit Available | 10MHz | 2.5V/µs | 10µV | 1 | 10V | 36V |
$ | SOIC, SOP |
| AD8676Reference Circuit Available | 10MHz | 2.5V/µs | 12µV | 2 | 10V | 36V |
$ | SOIC, SOP |
| AD8677 | 600KHz | 200mV/µs | 45µV | 1 | 10V | 36V |
$ | SOIC, SOT |
| AD8682 | 3.5MHz | 9V/µs | 350µV | 2 | 9V | 32V |
$ | SOIC, SOP |
| AD8684 | 3.5MHz | 9V/µs | 350µV | 4 | 9V | 36V |
$ | SOIC, SOP |
| AD8691 | 10MHz | 5V/µs | 400µV | 1 | 2.7V | 6V |
$ | SC70, SOT |
| AD8692 | 10MHz | 5V/µs | 400µV | 2 | 2.7V | 6V |
$ | SOIC, SOP |
| AD8694 | 10MHz | 5V/µs | 400µV | 4 | 2.7V | 6V |
$ | SOIC, SOP |
| AD8698 | 1MHz | 400mV/µs | 20µV | 2 | 5V | 30V | ** | SOIC, SOP |
| AD9631 | 320MHz | 1.3KV/µs | 3mV | 1 | 6V | 12V |
$ | DIP, SOIC |
| AD9632 | 250MHz | 1.5KV/µs | 2mV | 1 | 6V | 12V |
$ | DIP, SOIC |
| ADA4000-1Reference Circuit Available | 5MHz | 20V/µs | 200µV | 1 | 8V | 36V |
$ | SOIC, SOT |
| ADA4000-2 | 5MHz | 20V/µs | 200µV | 2 | 8V | 36V |
$ | SOIC, SOP |
| ADA4000-4 | 5MHz | 20V/µs | 200µV | 4 | 8V | 36V |
$ | SOIC, SOP |
| ADA4001-2 | 10.3MHz | 25V/µs | 500µV | 2 | 10V | 36V |
$ | SOIC |
| ADA4004-1 | 12MHz | 2.7V/µs | 40µV | 1 | 10V | 30V |
$ | SOIC, SOT-23 |
| ADA4004-2Reference Circuit Available | 12MHz | 2.7V/µs | 40µV | 2 | 10V | 30V |
$ | SOIC, SOP |
| ADA4004-4 | 12MHz | 2.7V/µs | 40µV | 4 | 10V | 30V |
$ | CSP, SOIC |
| ADA4051-1 | 125KHz | 60mV/µs | 2µV | 1 | 1.8V | 5.5V |
$ | SC70, SOT-23 |
| ADA4051-2Reference Circuit Available | 200KHz | 40mV/µs | 2µV | 2 | 1.8V | 5.5V |
$ | SOP |
| ADA4062-2Reference Circuit Available | 1.4MHz | 3.3V/µs | 500µV | 2 | 8V | 36V |
$ | CSP, SOIC, SOP |
| ADA4062-4 | 1.4MHz | 3.3V/µs | 500µV | 4 | 30V | 30V |
$ | CSP, SOP |
| ADA4075-2 | 6.5MHz | 12V/µs | 300µV | 2 | 24V | 36V |
$ | CSP, SOIC |
| ADA4077-2 | 4MHz | 1V/µs | 10µV | 2 | 10V | 30V |
$ | - |
| ADA4084-2 | 12.3MHz | 2.6V/µs | 100µV | 2 | 3V | 30V |
$ | SOIC, SOP |
| ADA4091-2Reference Circuit Available | 1.27MHz | 460mV/µs | 35µV | 2 | 3V | 30V |
$ | CSP, SOIC |
| ADA4091-4Reference Circuit Available | 1.27MHz | 460mV/µs | 35µV | 4 | 3V | 30V |
$ | CSP, SOP |
| ADA4092-4 | 1.4MHz | 400mV/µs | 200µV | 4 | 2.7V | 30V |
$ | SOP |
| ADA4096-2Reference Circuit Available | 1.5MHz | 250mV/µs | 35µV | 2 | 3V | 30V |
$ | CSP, SOP |
| ADA4096-4 | 800KHz | 400mV/µs | 35µV | 4 | 3V | 30V |
$ | CSP, SOP |
| ADA4310-1 | 190MHz | 820V/µs | 1mV | 2 | - | - |
$ | CSP, Mini-SO |
| ADA4500-2 | 10MHz | 8.7V/µs | 120µV | 2 | 2.7V | 5.5V |
$ | CSP, SOP |
| ADA4505-1 | 50KHz | 6mV/µs | 500µV | 1 | 1.8V | 5V |
$ | SOT-23 |
| ADA4505-2Reference Circuit Available | 50KHz | 6mV/µs | 500µV | 2 | 1.8V | 5V |
$ | CSP, SOP |
| ADA4505-4 | 50KHz | 6mV/µs | 500µV | 4 | 1.8V | 5V |
$ | CSP, SOP |
| ADA4528-1Reference Circuit Available | 6.5MHz | 500mV/µs | 300nV | 1 | 2.2V | 5.5V |
$ | SOP |
| ADA4528-2 | 3.4MHz | 500mV/µs | 300nV | 2 | 2.2V | 5.5V |
$ | CSP, Mini-SO |
| ADA4610-2 | 10.6MHz | 25V/µs | 200µV | 2 | 9V | 30V |
$ | CSP, SOIC, SOP |
| ADA4627-1Reference Circuit Available | 19MHz | 40V/µs | 70µV | 1 | 10V | 30V |
$ | CSP, SOIC |
| ADA4637-1 | - | 170V/µs | - | 1 | 10V | 30V |
$ | - |
| ADA4638-1 | 2.5MHz | 1.5V/µs | 500nV | 1 | 4.5V | 30V |
$ | CSP, SOIC |
| ADA4665-2 | 1.2MHz | 1V/µs | 1mV | 2 | 5V | 16V |
$ | SOIC, SOP |
| ADA4691-2 | 3.6MHz | 1.3V/µs | 500µV | 2 | 2.7V | 5V |
$ | CSP |
| ADA4691-4 | 3.6MHz | 1.3V/µs | 500µV | 4 | 2.7V | 5V |
$ | CSP |
| ADA4692-2 | 3.6MHz | 1.3V/µs | 500µV | 2 | 2.7V | 5V |
$ | CSP, SOIC |
| ADA4692-4 | 3.6MHz | 1.3V/µs | 500µV | 4 | 2.7V | 5V |
$ | SOP |
| ADA4800 | 400MHz | 415V/µs | 30mV | 1 | 4V | 17V |
$ | - |
| ADA4817-1 | 1.05GHz | 870V/µs | 400µV | 1 | 5V | 10V |
$ | CSP, SOIC |
| ADA4817-2Reference Circuit Available | 1.05GHz | 870V/µs | 2mV | 2 | 5V | 10V |
$ | CSP |
| ADA4841-1Reference Circuit Available | 80MHz | 13V/µs | 40µV | 1 | 2.7V | 12V |
$ | SOIC, SOT |
| ADA4841-2 | 80MHz | 13V/µs | 40µV | 2 | 2.7V | 12V |
$ | SOIC, SOP |
| ADA4850-1 | 175MHz | 220V/µs | 600µV | 1 | 2.7V | 6V |
$ | CSP |
| ADA4850-2 | 175MHz | 220V/µs | 600µV | 2 | 2.7V | 6V |
$ | CSP |
| ADA4851-1Reference Circuit Available | 130MHz | 375V/µs | 600µV | 1 | 2.7V | 12V |
$ | SOT |
| ADA4851-2 | 130MHz | 375V/µs | 600µV | 2 | 2.7V | 12V |
$ | SOP |
| ADA4851-4 | 130MHz | 375V/µs | 600µV | 4 | 2.7V | 12V |
$ | SOP |
| ADA4853-1Reference Circuit Available | 90MHz | 100V/µs | 1mV | 1 | 2.65V | 5V |
$ | SC70 |
| ADA4853-2Reference Circuit Available | 100MHz | 120V/µs | 2mV | 2 | 2.65V | 5V |
$ | CSP |
| ADA4853-3Reference Circuit Available | 100MHz | 120V/µs | 1mV | 3 | 2.65V | 5V |
$ | CSP, SOP |
| ADA4855-3 | 400MHz | 800V/µs | 1mV | 3 | 3V | 5.5V |
$ | CSP |
| ADA4856-3 | 225MHz | 800V/µs | 1.3mV | 3 | 3V | 5.5V |
$ | CSP |
| ADA4857-1 | 850MHz | 2.8KV/µs | 2mV | 1 | 4.5V | 10.5V |
$ | CSP, SOIC |
| ADA4857-2 | 750MHz | 2.8KV/µs | 2mV | 2 | 4.5V | 10.5V |
$ | CSP |
| ADA4858-3 | 600MHz | 600V/µs | 500µV | 3 | 3V | 5.5V |
$ | CSP |
| ADA4859-3 | 265MHz | 740V/µs | - | 3 | 3V | 5.5V |
$ | CSP |
| ADA4860-1 | 520MHz | 790V/µs | 3.5mV | 1 | 5V | 12V |
$ | SOT |
| ADA4861-3 | 730MHz | 680V/µs | 100µV | 3 | 5V | 12V |
$ | SOIC |
| ADA4862-3 | 310MHz | 830V/µs | 2mV | 3 | 5V | 12V |
$ | SOIC |
| ADA4891-1 | 240MHz | 170V/µs | 2.5mV | 1 | 2.7V | 5.5V |
$ | SOIC, SOT |
| ADA4891-2 | 220MHz | 170V/µs | 2.5mV | 2 | 2.7V | 5.5V |
$ | Mini-SO, SOP, SOT |
| ADA4891-3 | 220MHz | 170V/µs | 2.5mV | 3 | 2.7V | 5.5V |
$ | Mini-SO, SOP |
| ADA4891-4Reference Circuit Available | 220MHz | 170V/µs | 2.5mV | 4 | 2.7V | 5.5V |
$ | - |
| ADA4895-1 | 236MHz | 943V/µs | 28µV | 1 | 3V | 10V |
$ | SOP |
| ADA4895-2 | 236MHz | 943V/µs | 28µV | 2 | 3V | 10V |
$ | SOP |
| ADA4896-2 | 230MHz | 120V/µs | 28µV | 2 | 3V | 10V |
$ | Mini-SO |
| ADA4897-1Reference Circuit Available | 230MHz | 120V/µs | 28µV | 1 | 3V | 10V |
$ | SOP |
| ADA4897-2Reference Circuit Available | 230MHz | 120V/µs | 28µV | 2 | 3V | 10V |
$ | SOP |
| ADA4898-1 | 65MHz | 55V/µs | 20µV | 1 | 9V | 33V |
$ | SOIC |
| ADA4898-2 | 65MHz | 55V/µs | 20µV | 2 | 9V | 33V |
$ | SOIC |
| ADA4899-1Reference Circuit Available | 600MHz | 310V/µs | 35µV | 1 | 4.5V | 12V |
$ | CSP, SOIC |
| ADD8504 | - | 7V/µs | 20mV | 4 | 3.3V | 6.5V |
$ | SOP |
| ADD8704 | 6.8MHz | 6V/µs | 2mV | 4 | 4.5V | 16.5V |
$ | CSP, SOP |
| ADD8710 | 5MHz | 8V/µs | 4mV | 11 | 4.5V | 18V |
$ | SOP |
| ADR827 | 1MHz | 500mV/µs | 100µV | 1 | 2.7V | 30V |
$ | SOP |
| ADTL082 | 5MHz | 20V/µs | 1.5mV | 2 | 8V | 36V |
$ | SOIC, SOP |
| ADTL084 | 5MHz | 20V/µs | 1.5mV | 4 | 8V | 36V |
$ | SOP, SOT |
| OP07 | 600KHz | 300mV/µs | 30µV | 1 | 6V | 44V |
$ | DIP, SOIC |
| OP07DReference Circuit Available | 600KHz | 200mV/µs | 45µV | 1 | 8V | 36V |
$ | DIP, SOIC |
| OP113 | 3.4MHz | 1.2V/µs | 150µV | 1 | 4V | 36V |
$ | DIP, SOIC |
| OP1177Reference Circuit Available | 1.3MHz | 700mV/µs | 15µV | 1 | 5V | 36V |
$ | SOIC, SOP |
| OP162 | 15MHz | 13V/µs | 25µV | 1 | 2.7V | 12V |
$ | SOIC, SOP |
| OP177Reference Circuit Available | 600KHz | 300mV/µs | 10µV | 1 | 6V | 44V |
$ | DIP, SOIC |
| OP183 | 5MHz | 15V/µs | 100µV | 1 | 5V | 36V | ** | SOIC |
| OP184Reference Circuit Available | 4.25MHz | 4V/µs | 175µV | 1 | 3V | 36V |
$ | SOIC |
| OP191 | 3MHz | 500mV/µs | 80µV | 1 | 2.7V | 12V |
$ | SOIC |
| OP193Reference Circuit Available | 35KHz | 15mV/µs | 150µV | 1 | 1.7V | 36V |
$ | SOIC |
| OP196 | 450KHz | 300mV/µs | 35µV | 1 | 3V | 12V |
$ | SOIC |
| OP200 | 500KHz | 150mV/µs | 80µV | 2 | 6V | 40V |
$ | DIP, LCC, SOIC |
| OP213 | 3.4MHz | 1.2V/µs | 250µV | 2 | 4V | 36V |
$ | SOIC |
| OP2177Reference Circuit Available | 1.3MHz | 700mV/µs | 15µV | 2 | 5V | 36V |
$ | SOIC, SOP |
| OP249 | 4.7MHz | 22V/µs | 400µV | 2 | 9V | 36V |
$ | DIP, LCC, SOIC |
| OP262 | 15MHz | 13V/µs | 25µV | 2 | 2.7V | 12V |
$ | SOIC, SOP |
| OP27 | 8MHz | 2.8V/µs | 30µV | 1 | 8V | 44V |
$ | DIP, SOIC, TO-X |
| OP270 | 5MHz | 2.4V/µs | 50µV | 2 | 9V | 36V |
$ | DIP, SOIC |
| OP275 | 9MHz | 22V/µs | 1mV | 2 | 9V | 44V |
$ | DIP, SOIC |
| OP279 | 5MHz | 3V/µs | 4mV | 2 | 4.5V | 12V |
$ | SOIC, SOP |
| OP281 | 105KHz | 28mV/µs | 100µV | 2 | 2.7V | 12V |
$ | SOIC, SOP |
| OP282 | 4MHz | 9V/µs | 200µV | 2 | 9V | 36V |
$ | SOIC |
| OP284 | 4.25MHz | 4V/µs | 175µV | 2 | 3V | 36V |
$ | DIP, SOIC |
| OP285 | 9MHz | 22V/µs | 35µV | 2 | 9V | 44V |
$ | SOIC |
| OP290 | 20KHz | 12mV/µs | 125µV | 2 | 1.6V | 36V |
$ | DIP |
| OP291 | 3MHz | 500mV/µs | 80µV | 2 | 2.7V | 12V |
$ | SOIC |
| OP292 | 4MHz | 4V/µs | 1mV | 2 | 4.5V | 33V |
$ | SOIC |
| OP293Reference Circuit Available | 35KHz | 15mV/µs | 250µV | 2 | 1.7V | 36V |
$ | SOIC |
| OP295 | 85KHz | 30mV/µs | 300µV | 2 | 3V | 36V |
$ | DIP, SOIC |
| OP296 | 450KHz | 300mV/µs | 35µV | 2 | 3V | 12V |
$ | SOIC, SOP |
| OP297 | 500KHz | 150mV/µs | 80µV | 2 | 4V | 40V |
$ | DIP, SOIC |
| OP37 | 12MHz | 17V/µs | 30µV | 1 | 8V | 44V |
$ | DIP, SOIC |
| OP400 | 500KHz | 150mV/µs | 80µV | 4 | 6V | 40V |
$ | DIP, LCC, SOIC |
| OP413 | 3.4MHz | 1.2V/µs | 275µV | 4 | 4V | 36V |
$ | SOIC |
| OP4177 | 1.3MHz | 700mV/µs | 15µV | 4 | 5V | 36V |
$ | SOIC, SOP |
| OP42 | 10MHz | 50V/µs | 1.5mV | 1 | 16V | 40V |
$ | DIP, LCC, SOIC, TO-X |
| OP462 | 15MHz | 13V/µs | 25µV | 4 | 2.7V | 12V |
$ | SOIC, SOP |
| OP467 | 28MHz | 170V/µs | 200µV | 4 | 9V | 36V |
$ | DIP, LCC, SOIC |
| OP470 | 6MHz | 2V/µs | 400µV | 4 | 9V | 36V |
$ | DIP, LCC, SOIC |
| OP471 | 6.5MHz | 8V/µs | 1mV | 4 | 9V | 36V |
$ | LCC, SOIC |
| OP481 | 105KHz | 28mV/µs | 100µV | 4 | 2.7V | 12V |
$ | SOIC, SOP |
| OP482 | 4MHz | 9V/µs | 200µV | 4 | 9V | 36V |
$ | DIP, SOIC |
| OP484 | 4.25MHz | 4V/µs | 250µV | 4 | 3V | 36V |
$ | DIP, SOIC |
| OP490 | 20KHz | 12mV/µs | 600µV | 4 | 3V | 36V |
$ | DIP, SOIC |
| OP491 | 3MHz | 500mV/µs | 80µV | 4 | 2.7V | 12V |
$ | DIP, SOIC, SOP |
| OP492 | 4MHz | 4V/µs | 1.4mV | 4 | 4.5V | 33V |
$ | SOIC |
| OP495 | 85KHz | 30mV/µs | 300µV | 4 | 3V | 36V |
$ | DIP, SOIC |
| OP496 | 450KHz | 300mV/µs | 35µV | 4 | 3V | 12V |
$ | SOIC, SOP |
| OP497 | 500KHz | 150mV/µs | 80µV | 4 | 4V | 40V |
$ | DIP, LCC, SOIC |
| OP727 | 700KHz | 200mV/µs | 30µV | 2 | 3V | 36V |
$ | SOIC, SOP |
| OP747 | 700KHz | 200mV/µs | 30µV | 4 | 3V | 36V |
$ | SOIC, SOP |
| OP77 | 600KHz | 300mV/µs | 50µV | 1 | 6V | 44V |
$ | DIP, LCC, TO-X |
| OP777 | 700KHz | 200mV/µs | 20µV | 1 | 3V | 36V |
$ | SOIC, SOP |
| OP97 | 900KHz | 200mV/µs | 30µV | 1 | 4V | 40V |
$ | DIP, SOIC |
| SSM2135 | 3.5MHz | 600mV/µs | 200µV | 2 | 4V | 36V |
$ | SOIC |
