集成式温度传感器

查找能够高精度和可靠检测和测量温度的模拟和数字温度传感器。 ADI公司的数字温度传感器可在宽温度范围内实现最高±0.25°C的精度,具有NIST可跟踪性,可即插即用,而不需要额外进行信号调理或校准。 此外,ADI公司的数字温度传感器可集成DAC、ADC、基准电压源以及限值警报寄存器。 还提供一系列接口,包括I2C、SPI和PWM(针对数字产品)以及电流和电压(针对模拟产品)。
产品选型表

集成式温度传感器

  按住Shift键进行二次排序
SortOrderPart#Device Primary FunctionMax Error Over Temp
(Deg)
25°C Temp Error
(typ)
(Deg)
Bits
(bits)
Temp Resolution
(typ)
(°C/LSB)
Temp RangeOutput Data FormatVs+
(min)
(V)
Vs+
(max)
(V)
Is
(typ)
(A)
Output SensitivityUS Price 1000 to 4999
($ US)
1LTC2944 Internal 3- 14 3 -40 to 85°C Digital 3.6 60 80µ Digital $2.85 (LTC2944CDD#PBF)
2LTC2986 Diode, RTD, Thermistor, Thermocouple 0.1- 24 0.1 -40 to 85°C Digital 2.85 5.25 15m Digital $16.56 (LTC2986CLX#PBF)
3LTC2943-1 Internal 5- 14 5 -40 to 85°C Digital 3.6 20 80µ Digital $2.70 (LTC2943CDD-1#PBF)
4LTC2984 Diode, RTD, Thermistor, Thermocouple 0.1- 24 0.1 -40 to 85°C Digital 2.85 5.25 15m Digital $21.43 (LTC2984CLX#PBF)
5LTC2983 Diode, RTD, Thermistor, Thermocouple 0.1- 24 0.1 -40 to 85°C Digital 2.85 5.25 15m Digital $19.49 (LTC2983CLX#PBF)
6LTC2943 Internal 5- 14 5 -40 to 85°C Digital 3.6 20 80µ Digital $2.35 (LTC2943CDD#PBF)
7ADT7420 Temperature Sensor 0.5 0.002 16 0.0078 -40 to 150°C Digital, I²C 2.7 5.5 210µ Digital $3.10 (ADT7420UCPZ-R2)
8ADT7320Reference Circuit Available Temperature Sensor 0.5 0.002 16 0.0078 -40 to 150°C Digital 2.7 5.5 210µ Digital $3.10 (ADT7320UCPZ-RL7)
9ADT7312 Temperature Sensor 1.5 1 16 0.0078 -55 to 175°C Digital 2.7 5.5 245µ Digital $75.00 (ADT7312WCZ-PT7)
10LTC2991 Diode, Internal 1.5- 14 1.5 -40 to 85°C Digital 3 5.5 1.1m Digital $4.50 (LTC2991CMS#PBF)
11ADT7311Reference Circuit Available Temperature Sensor 1 0.015 13 0.0078 -40 to 150°C Digital 2.7 5.5 250µ Digital $1.72 (ADT7311WTRZ-RL)
12LTC2990 Diode, Internal 1.5- 14 1.5 -40 to 85°C Digital 3 5.5 1.1m Digital $2.25 (LTC2990CMS#PBF)
13LTC2942-1 Diode 5- 14 5 -40 to 85°C Digital 2.7 5.5 70µ Digital $1.85 (LTC2942CDCB-1#TRPBF)
14LTC2942 Internal 5- 14 5 -40 to 85°C Digital 2.7 5.5 70µ Digital $1.50 (LTC2942CDCB#TRPBF)
15ADT7410 Temperature Sensor 1 0.5 16 0.0078 -55 to 150°C Digital, I²C, SMBus 2.7 5.5 210µ Digital $1.36 (ADT7410TRZ)
16ADT7310Reference Circuit Available Temperature Sensor 1 0.5 16 0.0078 -55 to 150°C Digital 2.7 5.5 210µ Digital $1.36 (ADT7310TRZ)
17ADT7408 Temperature Sensor 4 0.5 12 0.0625 -20 to 125°C Digital, I²C, SMBus 3 3.6 550µ Digital $0.90 (ADT7408CCPZ-REEL7)
18ADT75 Temperature Sensor 3 1 12 0.0625 -55 to 125°C Digital, I²C, SMBus 3 5.5 525µ Digital $0.66 (ADT75ARMZ)
19ADT7302 Temperature Sensor 2 1 13 0.03125 -40 to 125°C Digital 2.7 5.25 2.2m Digital $0.80 (ADT7302ARTZ-500RL7)
20ADT7301 Temperature Sensor 1 1 13 0.03125 -40 to 150°C Digital 2.7 5.25 1.6m Digital $1.25 (ADT7301ARMZ)
21ADT7470 PWM Output Fan Control---- -40 to 125°C Digital, I²C 3 5.5 500µ Digital $2.25 (ADT7470ARQZ-REEL7)
22TMP06 Temperature Sensor 5 0.2 12 0.025 -40 to 150°C Digital, PWM 3 5.5 650µ Digital $0.83 (TMP06AKSZ-500RL7)
23TMP05 Temperature Sensor 5 0.2 12 0.025 -40 to 150°C Digital, PWM 3 5.5 650µ Digital $0.72 (TMP05ARTZ-500RL7)
24ADT7517 Temperature Sensor 7 3 10 0.25 -40 to 120°C Analog, Digital, I2C, SPI 2.7 5.5 3m Digital-
25ADT7516 Temperature Sensor 5 0.5 10 0.25 -40 to 120°C Analog, Digital, I2C, SPI 2.7 5.5 3m Digital $4.68 (ADT7516ARQZ)
26ADT7411 Temperature Sensor 5 0.5 10 0.25 -40 to 120°C Digital, I²C 2.7 5.5 3m Digital $2.29 (ADT7411ARQZ)
27ADT7318 Temperature Sensor 5 0.5 10-- Digital 2.7 5.5 2.2m Digital-
28ADT7317 Temperature Sensor 5 0.5 10-- Digital 2.7 5.5 2.2m Digital-
29ADT7316 Temperature Sensor 5 0.5 10- -40 to 120°C Digital 2.7 5.5 2.2m Digital $4.68 (ADT7316ARQZ-REEL7)
30AD7314 Temperature Sensor 2 1 10 0.25 -35 to 85°C Digital, Serial 2.65 5.5 300µ Digital $1.01 (AD7314ARMZ-REEL7)
31AD7415 Temperature Sensor 3 0.5 10 0.25 -40 to 125°C Digital, I²C 2.7 5.5 900µ Digital $1.07 (AD7415ARTZ-0500RL7)
32AD7414 Temperature Sensor 2- 10 0.25 -40 to 125°C Digital, I²C 2.7 5.5 900µ Digital $1.07 (AD7414ARTZ-1REEL7)
33AD7814 Temperature Sensor 3.5 2 10 0.25 -55 to 125°C Digital 2.7 5.5 400µ Digital $1.10 (AD7814ARTZ-REEL7)
34AD7418 Temperature Sensor 2 1 10 0.25 -40 to 125°C Digital, I²C 2.7 5.5 600µ Digital $3.01 (AD7418ARMZ-REEL7)
35AD7417 Temperature Sensor 2 1 10 0.25 -40 to 125°C Digital, I²C 2.7 5.5 600µ Digital $3.29 (AD7417ARUZ-REEL)
36AD7416 Temperature Sensor 2- 10 0.25 -40 to 125°C Digital, I²C 2.7 5.5 600µ Digital $1.10 (AD7416ARMZ)
37TMP04 Temperature Sensor 5 1.5 16 0.3 -40 to 85°C Digital, PWM 4.5 7 1.3m Digital $3.88 (TMP04FSZ)
38TMP03 Temperature Sensor 5 1.5 16 0.3 -40 to 85°C Digital, PWM 4.5 7 1.3m Digital $3.88 (TMP03FT9Z)
39LTC1392 Internal 4- 10 4 -40 to 85°C Digital-- 700µ Digital $3.95 (LTC1392CN8#PBF)
