AD8694

PRODUCTION

Low Cost, Low Noise, CMOS Rail-to-Rail Output Quad Op Amp

Data Sheet (Rev. F) Product Selection Table

Part Models: 6
1ku List Price: Starting From $0.98

Viewing:

Overview

Offset voltage: 400 μV typical
Low offset voltage drift: 6 μV/°C maximum (AD8692/AD8694)
Very low input bias currents: 1 pA maximum
Low noise: 8 nV/√Hz
Qualified for automotive applications.
Low distortion: 0.0006%
Wide bandwidth: 10 MHz
Unity-gain stable
Single-supply operation: 2.7 V to 6 V

The AD8691, AD8692, and AD8694 are low cost, single, dual, and quad rail-to-rail output, single-supply amplifiers featuring low offset and input voltages, low current noise, and wide signal bandwidth. The combination of low offset, low noise, very low input bias currents, and high speed make these amplifiers useful in a wide variety of applications. Filters, integrators, photodiode amplifiers, and high impedance sensors all benefit from this combination of performance features. Audio and other ac applications benefit from the wide bandwidth and low distortion of these devices.

Applications for these amplifiers include power amplifier (PA) controls, laser diode control loops, portable and loop-powered instrumentation, audio amplification for portable devices, and ASIC input and output amplifiers.

The small SC70 and TSOT package options for the AD8691 allow it to be placed next to sensors, thereby reducing external noise pickup.

The AD8691, AD8692, and AD8694 are specified over the extended industrial temperature range of −40°C to +125°C. The AD8691 single is available in 5-lead SC70 and 5-lead TSOT packages. The AD8692 dual is available in 8-lead MSOP and narrow SOIC surface-mount packages. The AD8694 quad is available in 14-lead TSSOP and narrow 14-lead SOIC packages.

See ordering guide section for automotive grades.

Applications

Photodiode amplification
Battery-powered instrumentation
Medical instruments
Multipole filters
Sensors
Portable audio devices

Part Models: 6
1ku List Price: Starting From $0.98

Documentation

Data Sheet 1

AD8691/AD8692/AD8694: Low Cost, Low Noise, CMOS, RRO Operational Amplifiers Data Sheet (Rev.F) 10/01/2004

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
AD8694ARUZ	14-Lead TSSOP	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
AD8694ARUZ-REEL	14-Lead TSSOP	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
AD8694ARZ	14-Lead SOIC	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
AD8694ARZ-REEL7	14-Lead SOIC	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
AD8694WARUZ	14-Lead TSSOP	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
AD8694WARUZ-REEL	14-Lead TSSOP	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

May 8, 2023 - 23_0068 Qualification of Alternate Wafer Fab Site at ADI Limerick for 0.6um CMOS Amplifier Product
		PCN23_0068_Form Material_Report Detailed Change Description Delta Qualification Matrix Qualification Results Summary
AD8694ARUZ	PRODUCTION
AD8694ARUZ-REEL	PRODUCTION
AD8694ARZ	PRODUCTION
AD8694ARZ-REEL7	PRODUCTION
AD8694WARUZ	PRODUCTION
AD8694WARUZ-REEL	PRODUCTION
May 17, 2012 - 10_0184 CANCELLED: AD8694 Wafer fabrication qualification at ADI's Limerick Manufacturing Location
		PCN10_0184_Form Material_Report AD8694 Qual Plan Reliability Report
AD8694ARUZ	PRODUCTION
AD8694ARUZ-REEL	PRODUCTION
AD8694ARZ	PRODUCTION
AD8694ARZ-REEL7	PRODUCTION
Feb 11, 2011 - 10_0005 Halogen Free Material Change for TSSOP Products Assembled at Amkor
		PCN10_0005_Form Material_Report Reliability Report
AD8694ARUZ	PRODUCTION
AD8694ARUZ-REEL	PRODUCTION
Aug 19, 2009 - 07_0024 Package Material Changes for SOT23, MiniSO, MQFP, PDIP, PLCC, SOIC (narrow and wide body), SSOP, TSSOP and TSSOP exposed pad
		Material_Report Material_Report Parts List PCN07_0024_Form Qual Data
AD8694ARUZ	PRODUCTION
AD8694ARUZ-REEL	PRODUCTION
AD8694ARZ	PRODUCTION
AD8694ARZ-REEL7	PRODUCTION
Jun 22, 2010 - 09_0217 Addition of Jiangsu Changjiang Electronics Technology (JCET) as an alternate Assembly source for 10L MSOP and 14L TSSOP,and Advanced Semiconductor Engineering (ASE) for 10L MSOP and 14L SOICN package.
		PCN09_0217_Form Material_Report Detailed Parts List Detailed Parts List Detailed Change Description Detailed Change Description Reliability Report Reliability Report
AD8694ARZ	PRODUCTION
AD8694ARZ-REEL7	PRODUCTION
Jan 16, 2012 - 11_0244 Halogen Free Material Change for Select TSSOP Products Assembled at Amkor
		PCN11_0244_Form Material_Report Qualification Report Summary
AD8694WARUZ	PRODUCTION
AD8694WARUZ-REEL	PRODUCTION

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Hardware Ecosystem

Parts	Product Life Cycle	Description
ADA4691-4	PRODUCTION	Low Power, 3.6 MHz, Low Noise, Rail-to-Rail Output, Operational Amplifiers

Tools & Simulations

Analog Photodiode Wizard

Use Photodiode Wizard to design a transimpedance amplifier circuit to interface with a photodiode. Select a photodiode from the library included in the tool, or enter custom photodiode specifications. Quickly observe tradeoffs between Bandwidth, Peaking (Q), and ENOB/SNR. Modify circuit parameters, and immediately see results in plots for pulse response, frequency response, and noise gain.

Open Tool

Signal Chain Designer

Signal Chain Designer is a web-based tool designed to create and simulate complex precision signal chains. See your circuit’s performance before you commit to your PCB: transfer function, noise, power consumption, input range, and DC error. Quickly experiment with different parts and architectures. Signal chains can be exported to LTspice for further analysis.

Open Tool

Analog Filter Wizard

Use the Analog Filter Wizard to design low-pass, high-pass, or band-pass filters with actual op amps in minutes. As you progress through the design process, you can observe the characteristics of your filter design from ideal specifications to real world circuit behavior. Quickly evaluate the tradeoffs in op amp specifications - including gain-bandwidth, noise, and supply current – to determine the best filter design for your requirements.

Open Tool

Evaluation Kits

EVAL-OPAMP-4 Evaluation Board

Buy Now View Details

Product Details

The Universal Precision Op Amp Evaluation Boards has been designed and optimized for many circuit configurations allowing the users to best suit their applications. These boards are all RoHs Compliant. See references below on what board to order by lead count and package.
