Apollo MxFE™: 16Tx / 16Rx X-Band Radar Platform
The Quad-Apollo MxFE™ X-Band Digital Beamforming Development Platform- a 16-channel Tx, 16-channel Rx phased-array system--enables RADAR, SATCOM, multi-channel communications and select electronic warfare applications.
Watch how four Apollo MxFE digitizer ICs on a single board improve multi-chip synchronization and multichannel calibration methods. Featured is an associated clock tree that includes four 22 GHz Clock ICs, power distribution network, and analog front ends comprising tunable filters and gain control to exemplify how an Apollo MxFE-hardened DSP is leveraged to correct digital and analog anomalies.
Also observe multi-channel phase and amplitude calibration methods, needed to enable phased array applications.
