MAX25307

Two/Three Output Low Noise LDO Linear Regulators

Industry's Only Auto-Qualified Low-Voltage Triple Output LDO Linear Regulator

立即购买

预发布

顶部

概览

优势和特点
产品详情

优势和特点

1.7V to 5.5V Input Voltage Range
Factory Selectable Output Voltage of 0.6V to 3.7875V in 12.5mV Steps
37µV_RMS Output Noise, 10Hz to 100kHz
1.95mA (Max) Operating Supply Current
70dB PSRR at 10kHz
600mA Maximum Output Current (OUT1)
300mA Maximum Output Current (OUT2/3)
±1.25% DC Accuracy Over Load, Line, and Temperature
155mV (Max) Dropout at I_MAX1/2/3 Load (3.3V_IN)
< 1µA Shutdown Supply Current
Overcurrent and Overtemperature Protection
Output-to-Input Reversed Current Protection
Individual Active-Low RESET Outputs
3mm x 3mm 16 pin TQFN Package
-40°C to 125°C Grade 1 Automotive Temperature Range

产品详情

The MAX25307/MAX25308 are a two/three output linear regulator family that deliver up to 600mA on channel 1 and up to 300mA on channels 2 and 3 with only 37μV_RMS of output noise from 10Hz to 100kHz. These regulators maintain ±1.25% output accuracy over a wide input voltage range, requiring only 155mV (max) of input-to-output headroom at full load. The 1.95mA maximum no-load supply current is independent of dropout voltage. Each output is factory programmable between 0.6V to 3.7875V in 12.5mV steps. No external components are needed except for the input, output, and bypass capacitors. Each output has an independent enable input and active-low RESET output.

Applications

Advanced Driver-Assistance Systems (ADAS)
Infotainment Systems
Point of Load

产品分类

电源管理
- 正线性稳压器(LDO)

类似器件点击在参数搜索中查看所有

产品生命周期预发布

本产品为新品，工程验证可能仍在进行中。我们正在准备量产，数量可能有限，设计规格可能会改变。

评估套件 (1)

MAX25308EVKIT

Evaluation Kit for the MAX25308

MAX25308EVKIT

查看此评估套件详细信息

The MAX25308 EV kit is a fully assembled and tested PCB intended to demonstrate the capability of the MAX25308 LDO regulator. The MAX25308 is a 3-output linear regulator family that delivers up to 600mA on Channel 1 and up to 300mA on channels 2 and 3 with only 37μVRMS of output noise from 10Hz to 100kHz. These regulators maintain ±1.25% output accuracy over a wide input voltage range, requiring only 155mV (max) of inputto- output headroom at full load. The 1.95mA maximum no-load supply current is independent of dropout voltage. Each output is factory programmable between 0.6V to 3.7875V in 12.5mV steps. No external components are needed except for the input, output, and bypass capacitors. Each output has an independent enable input and active-low RESET output.
