ZERO-DRIFT/LOW TcVos AMPLIFIERS

Zero-Drift op amps or Low TC (temperature coefficient) op amps meet the requirement for applications demanding constant offset voltage over time and temperature. Analog Devices is the leader in the low-drift op amp architecture and offers the broadest portfolio of products in this category. Select parts from the parametric search table below to download parts datasheets and order samples.

PRODUCT SELECTION TABLES

All Design Tools

  • Filter Filter
  • Photodiode Photodiode
  • Amp Tools Amp Tools
  • Product Search Product Search
  • ADIsimADC ADIsimADC
  • ADIsimDAC ADIsimDAC
  • ADC/DAC Tools ADC/DAC Tools
  • Product Search Product Search
  • ADIsimRF ADIsimRF
  • ADIsimPLL ADIsimPLL
  • RF Tools RF Tools
  • Product Search Product Search
  • ADIsimPower ADIsimPower
  • ADIsimPE ADIsimPE
  • Power Tools Power Tools
  • Product Search Product Search

Precision Zero Drift/Low Tempco Amplifiers

Part#Amps per Package-3dB Bandwidth at min gain (typ)GBP (typ)Slew Rate (typ)Voltage Noise Density (typ)Vsupply Span (min)Vsupply Span (max)Vos (typ)Iq/Amp (typ)Ib (typ)PSRR (typ)CMRR (typ)Rail-Rail InRail-Rail OutVos TC (typ)Type of Amplifier
ADA4528-2Reference Circuit Available 2 3.4 MHz - 0.5 V/µs 5.9 nV/rtHz 2.2 5.5 0.3 µV 1.5 mA 200 pA 150 137 Yes Yes 0.002 µV/degC Precision
ADA4638-1 1 2.5 MHz 1.5 MHz 1.5 V/µs 66 nV/rtHz 4.5 30 500 nV 0.85 mA 45 pA 143 130 - Yes 0.08 µV/degC Precision
ADA4528-1Reference Circuit Available 1 6.5 MHz 4 MHz 0.5 V/µs 5.3 nV/rtHz 2.2 5.5 0.3 µV 1.4 mA 200 pA 150 137 Yes Yes 0.002 µV/degC Precision
ADA4051-1 1 125 kHz 125 kHz 0.06 V/µs 95 nV/rtHz 1.8 5.5 2 µV 15 µA 20 pA 135 110 Yes Yes 0.02 µV/degC Precision
ADA4051-2Reference Circuit Available 2 200 kHz 125 kHz 40 mV/µs 95 nV/rtHz 1.8 5.5 2 µV 13 µA 20 pA 135 110 Yes Yes 0.02 µV/degC Precision
AD8639Reference Circuit Available 2 1.5 MHz 1.35 MHz 2 V/µs 80 nV/rtHz 5 16 3 µV 1.5 mA 1 pA 143 127 No Yes 0.03 µV/degC Precision
AD8638Reference Circuit Available 1 1.5 MHz 1.35 MHz 2 V/µs 59 nV/rtHz 5 16 3 µV 1.5 mA 1 pA - 127 No Yes 0.004 µV/degC Precision
AD8539 2 430 kHz 430 kHz 0.4 V/µs 50 nV/rtHz 2.7 5.5 5 µV 210 µA 15 pA 125 115 Yes Yes 30 µV/degC Precision
AD8538 1 430 kHz 430 kHz 0.4 V/µs 50 nV/rtHz 2.7 5.5 5 µV 180 µA 15 pA 125 115 No Yes 0.03 µV/degC Precision
AD8630 4 2.5 MHz 2.5 MHz 1 V/µs 22 nV/rtHz 2.7 6 1 µV 1.1 mA 30 pA 130 120 Yes Yes 0.002 µV/degC Precision
AD8629Reference Circuit Available 2 2.5 MHz 2.5 MHz 1 V/µs 22 nV/rtHz 2.7 6 1 µV 1.1 mA 30 pA 130 120 Yes Yes 0.002 µV/degC Precision
AD8628Reference Circuit Available 1 2.5 MHz 2.5 MHz 1 V/µs 22 nV/rtHz 2.7 6 1 µV 1.1 mA 30 pA 130 120 Yes Yes 2 nV/degC Precision
AD8574 4 1.5 MHz 1.5 MHz 400 mV/µs 51 nV/rtHz 2.7 6 1 µV 975 µA 10 pA 130 120 Yes Yes 50 nV/degC Precision
AD8572 2 1.5 MHz 1.5 MHz 400 mV/µs 51 nV/rtHz 2.7 6 1 µV 975 µA 10 pA 130 120 Yes Yes 50 nV/degC Precision
AD8571 1 1.5 MHz 1.5 MHz 400 mV/µs 51 nV/rtHz 2.7 6 1 µV 975 µA 10 pA 130 120 Yes Yes 50 nV/degC Precision
AD8554 4 1.5 MHz 1.5 MHz 0.4 V/µs 42 nV/rtHz 2.7 5.5 1 µV 975 µA 10 pA 115 120 Yes Yes 40 nV/degC Precision
AD8552 2 1.5 MHz 1.5 MHz 0.4 V/µs 42 nV/rtHz 2.7 5.5 1 µV 975 µA 10 pA 115 120 Yes Yes 40 nV/degC Precision
AD8551 1 1.5 MHz 1.5 MHz 0.4 V/µs 42 nV/rtHz 2.7 6 1 µV 975 µA 10 pA 115 120 Yes Yes 40 nV/degC Precision
