RFパワー・ディテクタ

アナログ・デバイセズは、ワイヤレス・システムにおけるRF信号とIF信号を正確に検出して測定する高性能RFディテクタの幅広いポートフォリオを提供しています。当社のログアンプは、最高100dBまでのダイナミック・レンジで、DCからマイクロ波までの信号を精度±2dBで測定し、RSSIおよび送信パワー・レベルのどちらの検出にも最適です。
TruPwr™ RMSディテクタは、スペクトラム拡散CDMA/W-CDMAや、より高次のQAM変調システムに見られる複雑な波形の測定という課題に対応し、正確にスケーリングしたDC電圧を提供します。このDC電圧は入力波形のRMS値に相当します。

RFパワー・ディテクタ

  2つめ以降の並び替え条件は、“Shift” キーを押しながら選択してください。
SortOrderPart#RF Primary Function# of ChannelsFreq Response RF
(min)
(Hz)
Freq Response RF
(max)
(Hz)
Input Dynamic Range
(typ)
(dB)
Temp Drift
(typ)
(dB)
Specified at Freq
(Hz)
Pin Test Level
(dBm)
Is
(typ)
(A)
Vs+
(min)
(V)
Vs+
(max)
(V)
Price (1000+)
($ US)
1LTC5597 RMS Responding Detector 1 100M 70G 35 1 42G- 33.5m 2.7 3.6 $48.95 (LTC5597IDC#TRMPBF)
2ADL6012 Envelope/Peak Detectors 1 2G 67G 40 1 18G- 28.6m 3.15 5.25 $42.76 (ADL6012ACPZN)
3ADL5920 RMS Responding Detector 1 9k 7G 50 0.5 1G -10 160m 4.9 5.1 $14.50 (ADL5920ACPZ)
4ADL6010S Envelope/Peak Detectors 1 500M 43.5G 45 0.3-- 3m 4.78 5.25-
5ADL5910 Envelope/Peak Detectors 1 0 6G 45 0.5 900M 10 3.5m 3.15 3.45 $1.95 (ADL5910ACPZN-R7)
6LTC5596 RF RMS Detector 1 100M 40G 35 1.25 40G -25 30m 2.7 3.5 $35.00 (LTC5596IDC#TRMPBF)
7ADL5904Reference Circuit Available Envelope/Peak Detectors, RMS Responding Detector 1 0 6G 45 0.5 900M 10 3.5m 3.15 3.45 $2.30 (ADL5904ACPZN-R7)
8ADL6010Reference Circuit Available Envelope/Peak Detectors 1 500M 43.5G 45 0.3 10G -10 3m 4.78 5.25-
9HMC1120 Envelope/Peak Detectors, RMS Responding Detector 1 0 3.9G 72 0.5 1900M- 70m 3.15 3.45-
10ADL5903 RMS Responding Detector 1 200M 6G 35 0.2 900M -10 2.5m 3 5.25 $2.35 (ADL5903ACPZN-R7)
11ADL5506 non-RMS Responding Detector 1 30M 4.5G 45 1 900M -10 3.75m 2.5 5.5 $1.27 (ADL5506ACBZ-R7)
12HMC7447 Envelope/Peak Detectors 1 71G 86G 24 0.5 81G 18- 3 5-
13HMC1094 non-RMS Responding Detector 1 1G 23G 50 0.5 10M -10 85m 3.15 3.45-
14ADL5906Reference Circuit Available RMS Responding Detector 1 10M 10G 67 1 900M -10 70m 4.75 5.25 $5.59 (ADL5906ACPZN-R2)
15ADL5501S RMS Responding Detector 1 50M 6G 30---- 2.7 5.5-
16ADL5513S RF Log Detector 1 1M 4G 80- 900M -10- 2.7 5.5-
17AD8306S RF Log Detector 1 5M 400M 100- 10M 0- 2.7 6.5-
18ADL5304 RF Log Detector 1-- 200--- 20.8m 4.5 5.5 $10.47 (ADL5304ACPZ-R7)
19ADL5511 Envelope/Peak Detectors, RMS Responding Detector 1 0 6G 47 0.1 900M 10 21.5m 4.75 5.25 $7.33 (ADL5511ACPZ-R7)
20HMC662 non-RMS Responding Detector 1 8G 30G 54 0.5 10M -10 88m 3.15 3.45-
21HMC1030 Envelope/Peak Detectors, RMS Responding Detector 1 0 3.9G 69 0.5 900M -10 143m 5 5-
22HMC1013 SDLVA Detector 1 500M 18.5G 67 0.5 10G 0 183m- 3.3-
23LTC5587 RF RMS Detector 1 10M 6G 40 1 2.14G- 3m 2.7 3.6 $5.17 (LTC5587IDD#PBF)
24LTC5583 RF RMS Detector 1 40M 6G 60 0.5 2.14G -45 80.5m 3.1 3.5 $9.50 (LTC5583IUF#PBF)
25LTC5582 RF RMS Detector 1 40M 10G 57 0.5 2.14G -45 41.6m 3.1 3.5 $6.20 (LTC5582IDD#PBF)
26ADL5902Reference Circuit Available RMS Responding Detector 1 50M 9G 65 0.5 900M -10 73m 4.5 5.5 $6.33 (ADL5902ACPZ-R7)
27ADL5505 RMS Responding Detector 1 450M 6G 36 0.1 900M 10 1.8m 2.5 3.3 $2.40 (ADL5505ACBZ-P7)
28LTC5564 RF Schottky Peak Detector 1 600M 15G 40 2 5.8G 5 44m 3.1 5.5 $2.90 (LTC5564IUD#PBF)
29HMC948 non-RMS Responding Detector 1 1G 23G 54 0.5 10M -10 91m 3.15 3.45-
30HMC913LC4B SDLVA Detector 1 0.6G 20G 59- 10G -10 80m---
31HMC913-Die SDLVA Detector 1 0.6G 20G 59 1.5 18G -30 80m---
32HMC909 RMS Responding Detector 1 0 5.8G 40 0.5 900M -15 42m 4.5 5.5-
33HMC813LC4B SDLVA Detector 1 1G 20G 55 0.5 10G -10 150m---
34HMC813-Die SDLVA Detector 1 1G 26G 55 0.5-- 150m---
35HMC1021 Envelope/Peak Detectors, RMS Responding Detector 1 0 3.9G 70 0.5 900M -10 75m 4.5 5.5-
36HMC1020 RMS Responding Detector 1 0 3.9G 72 0.75 900M -10 55m 4.5 5.5-
37HMC1010 RMS Responding Detector 1 0 3.9G 62 0.5 900M 0 48m 4.5 5.5-
38ADL5504 RMS Responding Detector 1 450M 6G 35 0.1 900M 10 1.8m 2.5 3.3 $2.90 (ADL5504ACBZ-P7)
39AD8363 RMS Responding Detector 1 50 6G 60 0.5 900M -10 60m 4.5 5.5 $3.55 (AD8363ACPZ-R7)
40HMC713MS8 non-RMS Responding Detector 1 45M 2.7G 54 -0.5 2.7G- 17m 2.7 5.5-
41HMC713LP3E non-RMS Responding Detector 1 50M 8G 54 0.5 2.7G- 17m 2.7 5.5-
42ADL5513 non-RMS Responding Detector 1 1M 4G 80 0.5 900M -10 31m 2.7 5.5 $5.56 (ADL5513ACPZ-R7)
43ADL5502Reference Circuit Available Envelope/Peak Detectors, RMS Responding Detector 1 450M 6G 35 0.1 900M 10 3m 2.5 3.3 $5.97 (ADL5502ACBZ-P7)
44LT5581 RF RMS Detector 1 10M 6G 40 1 2.14G- 1.4m 2.7 6 $2.29 (LT5581IDDB#TRPBF)
45LT5538 RF Log Detector 1 40M 3.8G 75 0.5 2.14G -35 29m 3 5.25 $4.50 (LT5538IDD#PBF)
46HMC613 SDLVA Detector 1 100M 20G 59 0.5 10G -10 83m 3.15 3.45-
47HMC611LP4 non-RMS Responding Detector 1 1M 10G 60- 7G -10 106m 4.5 5.5-
48ADL5519 non-RMS Responding Detector 1 1M 10G 62 0.5 0.9M -10 60m 3.3 5.5 $5.04 (ADL5519ACPZ-R7)
49LT5570 RF RMS Detector 1 40M 2.7G 51 0.5 2.14G -30 26.5m 4.75 6 $5.75 (LT5570IDD#PBF)
50ADL5501 RMS Responding Detector 1 50M 6G 30 0.1 900M 5 1.1m 2.7 5.5 $2.42 (ADL5501AKSZ-R7)
