Analog Temperature Sensors

Analog Devices analog temperature sensors provide current or voltage output proportional to the absolute temperature with accuracies of up to ±1°C. Our diverse range of analog output temperatures sensors can be used in a broad range of applications with no need for external calibration, and with minimal signal conditioning/conversion circuitry. To better suit your varied design needs, our portfolio of temperature sensors are available in multiple package options.
Product Selection Table

Analog Temperature Sensors

  Hold Shift Key for secondary sorting
SortOrderPart#Device Primary FunctionTemp Sensor InterfaceMax Error Over Temp
(Deg)
25°C Temp Error
(typ)
(Deg)
Output SensitivityVs+
(min)
(V)
Vs+
(max)
(V)
Data Output InterfacePrice (1000+)
($ US)
1LTC2996 Temperature Sensor Diode, Internal Temp Sensor 1.5 0.5 4 mV/°K 2.25 5.5 Analog, OV, UV $1.95 (LTC2996CDD#PBF)
2LTC2995 Temperature Sensor, Voltage Monitor Diode 1.5 0.5 4 mV/°K 2.25 5.5 Analog $2.45 (LTC2995CUD#PBF)
3LTC2997 Temperature Sensor Diode, Internal Temp Sensor 1.5 0.5 4 mV/°K 2.5 5.5 Analog $1.45 (LTC2997CDCB#TRPBF)
4AD8496 Thermocouple Signal Conditioner Thermocouple- 1 5 mV/°C 2.7 36 Analog $2.36 (AD8496ARMZ)
5AD8494 Thermocouple Signal Conditioner Thermocouple- 1 5 mV/°C 2.7 36 Analog $2.36 (AD8494ARMZ)
6AD8497 Thermocouple Signal Conditioner Thermocouple- 1 5 mV/°C 2.7 36 Analog $2.36 (AD8497ARMZ)
7AD8495Reference Circuit Available Thermocouple Signal Conditioner Thermocouple- 1 5 mV/°C 2.7 36 Analog $2.36 (AD8495ARMZ)
8TMP17 Temperature Sensor Internal Temp Sensor 4.5 2.5- 4 30 Analog $1.94 (TMP17GSZ)
9TMP37 Temperature Sensor Internal Temp Sensor 4 1 20 mV/°C 2.7 5.5 Analog $0.52 (TMP37FT9Z)
10TMP36 Temperature Sensor Internal Temp Sensor 4 1 10 mV/°C 2.7 5.5 Analog $0.50 (TMP36GSZ)
11TMP35 Temperature Sensor Internal Temp Sensor 4 1 10 mV/°C 2.7 5.5 Analog $0.50 (TMP35GRTZ-REEL7)
12AD22103 Temperature Sensor Internal Temp Sensor 2.5 0.5 28 mV/°C 2.7 3.6 Analog $1.66 (AD22103KTZ)
13AD22100 Temperature Sensor Internal Temp Sensor 2 0.5 22.5 mV/°C 4 6.5 Analog $1.79 (AD22100KTZ)
14TMP01 Thermostatic Switch Internal Temp Sensor 5 0.5 5 mV/°K, Thermostatic Switch 4.5 13.2 Analog, Switch (Off/On) $3.43 (TMP01FSZ)
15AD597 Thermocouple Signal Conditioner Thermocouple 4 4 10 mV/°C 5 30 Analog, Switch (Off/On) $3.12 (AD597ARZ)
16AD596 Thermocouple Signal Conditioner Thermocouple 4 4 10 mV/°C 5 30 Analog, Switch (Off/On) $10.10 (AD596AHZ)
17AD592 Temperature Sensor Internal Temp Sensor 1 0.3 5 mV/°K 4 30 Analog $2.35 (AD592ANZ)
18AD595 Thermocouple Signal Conditioner Thermocouple 1 1 10 mV/°C 5 30 Analog $9.17 (AD595AQ)
19AD594 Thermocouple Signal Conditioner Thermocouple 3.5 1 10 mV/°C 5 30 Analog $9.17 (AD594AQ)
20AC2626 Temperature Probe Internal Temp Sensor 1.7 0.5 5 mV/°K 4 30 Analog-
21AD590 Temperature Sensor Internal Temp Sensor 1.7 0.5 1µA/K 4 30 Analog $2.07 (AD590JCPZ-R5)
