RF Power Detectors
Analog Devices’ RF Power Detectors are a broad portfolio of Logarithmic Amplifiers, TruPwr™ RMS Detectors, Peak/Envelope Detectors and Successive Detection Log Video Amplifiers (SDLVAs). With detection ranges up to 100 dB, our RF power detectors are used in applications including Transmit/Receive Power Measurement, Input Protection, Return Loss Measurement, RF Pulse Detection, Radar, Electronic Warfare and Precise RF Power Measurement in Test and Measurement, Materials Analysis and HealthCare.
Subcategories
Product Selection Table
Latest Resources
Data Sheets
Application Notes
Technical Articles
- Log amps and directional couplers enable VSWR detection
- Simple and Affordable RMS Power Meter that Operates from 100 MHz to 40 GHz
- Understanding, Operating, and Interfacing to Integrated Diode-Based RF Detectors
- High Performance Integrated 24 GHz FMCW Radar Transceiver Chipset for Auto and Industrial Sensor Applications
Evaluation Documentation
- ADL5506 Gerber Files ZIP
- ADL5903 Gerber Files ZIP
- ADL5906 Gerber Files ZIP
- ADL5902 Gerber Files ZIP
- AD8318 Gerber Files ZIP
- AD8319 Gerber Files ZIP
- AD8312 Gerber Files ZIP
- AD8310 Gerber Files ZIP
- AD8306 Gerber Files ZIP
- AD831 Gerber Files ZIP
- AD8311 Gerber Files ZIP
- AD8302 Gerber Files ZIP
- AD8309 Gerber Files ZIP
- ADL5519 Gerber Files ZIP
- ADL5513 Gerber Files ZIP
- ADL5511 Gerber Files ZIP
- ADL5505 Gerber Files ZIP
- ADL5504 Gerber Files ZIP
- ADL5502 Gerber Files ZIP
- ADL5501 Gerber Files ZIP
- ADL5500 Gerber Files ZIP
- AD8364 Gerber Files ZIP
- AD8363 Gerber Files ZIP
- AD8362 Gerber Files ZIP
- AD8361 Gerber Files ZIP
- AD8361ART Gerber Files ZIP
- AD8317 Gerber Files ZIP
- AD8315 Gerber Files ZIP
- AD8315ACP Gerber Files ZIP
- AD8314ACP Gerber Files ZIP
- AD8314 Gerber Files ZIP
- AD8313 Gerber Files ZIP
Technical Books
Design Tools
Solutions Bulletins & Brochures
Webcast
Videos
- Low Power Portable RF Power Detector Circuit
- RF Power Measurement Made Easy
- X-Microwave & Analog Devices collaborate to offer Modular Drop-In Components
- RF Power Measurement Made Easy
- Calibration Free VSWR Measurement
- High Performance Integrated 24 GHz FMCW Radar Transceiver Chipset
Press Releases
Analog Dialogue
Frequently Asked Questions
- What is input voltage range and how is it determined?
- Why can't I get my amplifier to go to my full-scale output voltage?
- My reference voltage changes when I connect it to the amplifier's input?
- What is the output headroom or voltage range of an amplifier and how is it determined?
- Can I exceed the parameters specified in the absolute maximum ratings table?
- Why is my output signal clipping?
- Why is my input signal clipping?
- What is input common-mode voltage range (CMVR)?
- What are op amp input and output common-mode and differential voltage ranges and how are they determined?
- Why doesn't my amplifier output go to zero when I ground the input?
RF Power Detectors
| SortOrder | Part# | RF Primary Function | # of Channels | Freq Response RF (min) (Hz) | Freq Response RF (max) (Hz) | Input Dynamic Range (typ) (dB) | Temp Drift (typ) (dB) | Specified at Freq (Hz) | Pin Test Level (dBm) | Is (typ) (A) | Vs+ (min) (V) | Vs+ (max) (V) | Price (1000+) ($ US) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | ADL5920 | RMS Responding Detector | 1 | 9k | 7G | 50 | 0.5 | 1G | -10 | 160m | 4.9 | 5.1 | $14.50 (ADL5920ACPZ) |
| 2 | ADL6012 | Envelope/Peak Detectors | 1 | 2G | 43.5G | 25 | - | - | - | 26m | 3.15 | 5.25 | - |
| 3 | ADL6010S | Envelope/Peak Detectors | 1 | 500M | 43.5G | 45 | 0.3 | - | - | 3m | 4.78 | 5.25 | - |
| 4 | ADL5910 | Envelope/Peak Detectors | 1 | 0 | 6G | 45 | 0.5 | 900M | 10 | 3.5m | 3.15 | 3.45 | $1.95 (ADL5910ACPZN-R7) |
| 5 | LTC5596 | RF RMS Detector | 1 | 100M | 40G | 35 | 1.25 | 40G | -25 | 30m | 2.7 | 3.5 | $35.00 (LTC5596IDC#TRMPBF) |
| 6 | ADL5904 | Envelope/Peak Detectors, RMS Responding Detector | 1 | 0 | 6G | 45 | 0.5 | 900M | 10 | 3.5m | 3.15 | 3.45 | $2.30 (ADL5904ACPZN-R7) |
| 7 | ADL6010 | Envelope/Peak Detectors | 1 | 500M | 43.5G | 45 | 0.3 | 10G | -10 | 3m | 4.78 | 5.25 | - |
| 8 | HMC1120 | Envelope/Peak Detectors, RMS Responding Detector | 1 | 0 | 3.9G | 72 | 0.5 | 1900M | - | 70m | 3.15 | 3.45 | - |
| 9 | ADL5903 | RMS Responding Detector | 1 | 200M | 6G | 35 | 0.2 | 900M | -10 | 2.5m | 3 | 5.25 | $2.35 (ADL5903ACPZN-R7) |
| 10 | ADL5506 | non-RMS Responding Detector | 1 | 30M | 4.5G | 45 | 1 | 900M | -10 | 3.75m | 2.5 | 5.5 | $1.27 (ADL5506ACBZ-R7) |
| 11 | HMC7447 | Envelope/Peak Detectors | 1 | 71G | 86G | 24 | 0.5 | 81G | 18 | - | 3 | 5 | - |
| 12 | HMC1094 | non-RMS Responding Detector | 1 | 1G | 23G | 50 | 0.5 | 10M | -10 | 85m | 3.15 | 3.45 | - |
| 13 | ADL5906 | RMS Responding Detector | 1 | 10M | 10G | 67 | 1 | 900M | -10 | 70m | 4.75 | 5.25 | $5.59 (ADL5906ACPZN-R2) |
| 14 | ADL5304 | RF Log Detector | 1 | - | - | 200 | - | - | - | 20.8m | 4.5 | 5.5 | $10.47 (ADL5304ACPZ-R7) |
| 15 | ADL5511 | Envelope/Peak Detectors, RMS Responding Detector | 1 | 0 | 6G | 47 | 0.1 | 900M | 10 | 21.5m | 4.75 | 5.25 | $7.33 (ADL5511ACPZ-R7) |
| 16 | HMC662 | non-RMS Responding Detector | 1 | 8G | 30G | 54 | 0.5 | 10M | -10 | 88m | 3.15 | 3.45 | - |
| 17 | HMC1030 | Envelope/Peak Detectors, RMS Responding Detector | 1 | 0 | 3.9G | 69 | 0.5 | 900M | -10 | 143m | 5 | 5 | - |
| 18 | HMC1013 | SDLVA Detector | 1 | 500M | 18.5G | 67 | 0.5 | 10G | 0 | 183m | - | 3.3 | - |
| 19 | LTC5587 | RF RMS Detector | 1 | 10M | 6G | 40 | 1 | 2.14G | - | 3m | 2.7 | 3.6 | $5.17 (LTC5587IDD#PBF) |
| 20 | LTC5583 | RF RMS Detector | 1 | 40M | 6G | 60 | 0.5 | 2.14G | -45 | 80.5m | 3.1 | 3.5 | $9.50 (LTC5583IUF#PBF) |
| 21 | LTC5582 | RF RMS Detector | 1 | 40M | 10G | 57 | 0.5 | 2.14G | -45 | 41.6m | 3.1 | 3.5 | $6.20 (LTC5582IDD#PBF) |
| 22 | ADL5902 | RMS Responding Detector | 1 | 50M | 9G | 65 | 0.5 | 900M | -10 | 73m | 4.5 | 5.5 | $6.33 (ADL5902ACPZ-R7) |
| 23 | ADL5505 | RMS Responding Detector | 1 | 450M | 6G | 36 | 0.1 | 900M | 10 | 1.8m | 2.5 | 3.3 | $2.40 (ADL5505ACBZ-P7) |
| 24 | LTC5564 | RF Schottky Peak Detector | 1 | 600M | 15G | 40 | 2 | 5.8G | 5 | 44m | 3.1 | 5.5 | $2.90 (LTC5564IUD#PBF) |
| 25 | HMC948 | non-RMS Responding Detector | 1 | 1G | 23G | 54 | 0.5 | 10M | -10 | 91m | 3.15 | 3.45 | - |
| 26 | HMC913LC4B | SDLVA Detector | 1 | 0.6G | 20G | 59 | - | 10G | -10 | 80m | - | - | - |
| 27 | HMC913-Die | SDLVA Detector | 1 | 0.6G | 20G | 59 | 1.5 | 18G | -30 | 80m | - | - | - |
| 28 | HMC909 | RMS Responding Detector | 1 | 0 | 5.8G | 40 | 0.5 | 900M | -15 | 42m | 4.5 | 5.5 | - |
| 29 | HMC813LC4B | SDLVA Detector | 1 | 1G | 20G | 55 | 0.5 | 10G | -10 | 150m | - | - | - |
| 30 | HMC813-Die | SDLVA Detector | 1 | 1G | 26G | 55 | 0.5 | - | - | 150m | - | - | - |
| 31 | HMC1021 | Envelope/Peak Detectors, RMS Responding Detector | 1 | 0 | 3.9G | 70 | 0.5 | 900M | -10 | 75m | 4.5 | 5.5 | - |
| 32 | HMC1020 | RMS Responding Detector | 1 | 0 | 3.9G | 72 | 0.75 | 900M | -10 | 55m | 4.5 | 5.5 | - |
| 33 | HMC1010 | RMS Responding Detector | 1 | 0 | 3.9G | 62 | 0.5 | 900M | 0 | 48m | 4.5 | 5.5 | - |
| 34 | ADL5504 | RMS Responding Detector | 1 | 450M | 6G | 35 | 0.1 | 900M | 10 | 1.8m | 2.5 | 3.3 | $2.90 (ADL5504ACBZ-P7) |
| 35 | AD8363 | RMS Responding Detector | 1 | 50 | 6G | 60 | 0.5 | 900M | -10 | 60m | 4.5 | 5.5 | $3.55 (AD8363ACPZ-R7) |
| 36 | HMC713MS8 | non-RMS Responding Detector | 1 | 45M | 2.7G | 54 | -0.5 | 2.7G | - | 17m | 2.7 | 5.5 | - |
| 37 | HMC713LP3E | non-RMS Responding Detector | 1 | 50M | 8G | 54 | 0.5 | 2.7G | - | 17m | 2.7 | 5.5 | - |
| 38 | ADL5513 | non-RMS Responding Detector | 1 | 1M | 4G | 80 | 0.5 | 900M | -10 | 31m | 2.7 | 5.5 | $5.56 (ADL5513ACPZ-R7) |
| 39 | ADL5502 | Envelope/Peak Detectors, RMS Responding Detector | 1 | 450M | 6G | 35 | 0.1 | 900M | 10 | 3m | 2.5 | 3.3 | $5.97 (ADL5502ACBZ-P7) |
| 40 | LT5581 | RF RMS Detector | 1 | 10M | 6G | 40 | 1 | 2.14G | - | 1.4m | 2.7 | 6 | $2.29 (LT5581IDDB#TRPBF) |
| 41 | LT5538 | RF Log Detector | 1 | 40M | 3.8G | 75 | 0.5 | 2.14G | -35 | 29m | 3 | 5.25 | $4.50 (LT5538IDD#PBF) |
| 42 | HMC613 | SDLVA Detector | 1 | 100M | 20G | 59 | 0.5 | 10G | -10 | 83m | - | 3.3 | - |
| 43 | HMC611LP4 | non-RMS Responding Detector | 1 | 1M | 10G | 60 | - | 7G | -10 | 106m | 4.5 | 5.5 | - |
| 44 | ADL5519 | non-RMS Responding Detector | 1 | 1M | 10G | 62 | 0.5 | 0.9M | -10 | 60m | 3.3 | 5.5 | $5.04 (ADL5519ACPZ-R7) |
| 45 | LT5570 | RF RMS Detector | 1 | 40M | 2.7G | 51 | 0.5 | 2.14G | -30 | 26.5m | 4.75 | 6 | $5.75 (LT5570IDD#PBF) |
| 46 | ADL5501 | RMS Responding Detector | 1 | 50M | 6G | 30 | 0.1 | 900M | 5 | 1.1m | 2.7 | 5.5 | $2.42 (ADL5501AKSZ-R7) |
| 47 | HMC602 | non-RMS Responding Detector | 1 | 1M | 8G | 70 | 1 | 0.9M | -10 | 113m | 3 | 5 | - |
| 48 | HMC601 | non-RMS Responding Detector | 1 | 10M | 4G | 75 | 0.5 | 900M | -15 | 30m | 3 | 5 | - |
| 49 | HMC600 | non-RMS Responding Detector | 1 | 50M | 4G | 75 | 0.5 | 900M | -15 | 29m | 2.7 | 5.5 | - |
| 50 | AD8319 | non-RMS Responding Detector | 1 | 1M | 10G | 45 | 0.5 | 0.9M | -10 | 22m | 3 | 5.5 | $1.77 (AD8319ACPZ-R7) |
