Overview
Features and Benefits
- 18-bit resolution with no missing codes
- Throughput: 2 MSPS (TURBO = high), 1.5 MSPS (TURBO = low)
- Low power dissipation
- 15 mW at 2 MSPS, with external reference
- 26 mW at 2 MSPS with internal reference
- INL: ±1 LSB typical, ±2.5 LSB maximum
- SNR
- 95.5 dB, with on-chip reference
- 97.0 dB, with external reference
- 4.096 V internal reference: typical drift of 10 ppm/°C
- True differential analog input voltage range: ±VREF
- 0 V to VREF with VREF up to 5.0 V
- Allows use of any input range
- See data sheet for additional features
Product Details
The AD7986 is an 18-bit, 2 MSPS successive approximation, analog-to-digital converter (ADC). It contains a low power, high speed, 18-bit sampling ADC, an internal conversion clock, an internal reference (and buffer), error correction circuits, and a versatile serial interface port. On the rising edge of CNV, the AD7986 samples the voltage difference between the IN+ and IN− pins. The voltages on these pins usually swing in opposite phases between 0 V and VREF. It features a very high sampling rate turbo mode (TURBO = high) and a reduced power normal mode (TURBO = low) for low power applications where the power is scaled with the throughput.
In normal mode (TURBO = low), the SPI-compatible serial interface also features the ability, using the SDI input, to daisychain several ADCs on a single 3-wire bus and provide an optional busy indicator. It is compatible with 1.8 V, 2.5 V, and 2.7 V using the separate VIO supply.
The AD7986 is available in a 20-lead LFCSP with operation specified from −40°C to +85°C.
Applications
- Battery-powered equipment
- Data acquisition systems
- Medical instruments
- Seismic data acquisition systems
Product Categories
Markets and Technologies
Product Lifecycle
Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
