See how ADI's methodology to meet power domain sensitivity and realistic power supply noise requirements optimizes power solutions for RF signal chains. The optimized power solution improves form factor, power efficiency and power loss of the standard power solution while achieving the RF signal chain dynamic performances. This methodology demonstrates various power supply design optimizations including RF Transceivers, RF Amplifiers, High Speed ADCs and DACs, and more.

Witness ADI's full signal chain solution for SATCOM applications, along with a reference design, that enables customers to accelerate their own designs.

Learn more about ADI's antenna-to-bits system platform which integrates ADC/DAC solutions with RF/Microwave up-/down-converter circuitry and analog beamforming ICs (BFICs). The platform enables a full hybrid beamforming signal chain capable of being controlled and evaluated with example HDL and software scalable to a customer’s end system.

The “Quad-MxFE” System Development Platform is a 16 Tx/16 Rx channel direct sampling phased array system solution that supports applications including radars, electronic warfare, and SATCOM. Built from four MxFE^® transceivers, RF front-ends, clocking, and power circuitry, the platform features multi-chip synchronization, system level calibrations and beamforming algorithms. The system mates with a commercially-available FPGA evaluation board and includes HDL code and MATLAB^® software.

ADRV9002 RF Agile Software-Defined Radio (SDR) Transceivers for Mission Critical Communications operate from 30 MHz to 6000 MHz with narrow-band signals down to 12 kHz and wideband signals up to 40 MHz. See how these high dynamic range direct conversion transceivers minimize Bill of Material (BOM), incorporate RF system calibrations, programmable digital filtering, and advanced system level features such as Fast Frequency Hopping (FFH), Digital Pre-distortion (DPD), Multichip Synchronization (MCS), Dynamic Profile Switching (DPS) and Monitor Mode (MM) for optimal size, weight, power, and cost (SWaP-C).

Learn about ADI's high power SOI switches and select tuned GaN amplifiers in a power amplifier bank application. An easy-to-use alternate to GaN and PIN switches.

ADI enables fast switching and high performance in a novel PLL circuit design using quadband VCOs comprised of four narrow bands integrated into a single package. The design delivers benefits similar to the frequency range of wideband PLLs, as well as the phase noise performance and lock time of narrowband PLL performance.

Ultra-low jitter and synchronized multiple high frequency clocks are essential to achieving high performance in modern communication, instrumentation and radar applications. This demo illustrates how to achieve high performance in clocks with EZSYNC and Timed-SYNC capabilities of our new Fractional PLL chips. The solution enables selection of the most suitable synchronization method while providing the best-in-class jitter performance up to 12.8 GHz.

See how ADI is addressing data interconnect over rotary joint applications in Industry 4.0, factory automation and other robotic settings.

Discover the breadth of ADI’s sub-6 GHz and mmWave 5G portfolio through a complete 28 GHz 4T4R 5G RU designed fully in-house with ADI ICs and antenna IP from low PHY through an air interface. This comprehensive solution, comprising market-proven IP, significantly reduces the customer execution risk, time to market, and resources required by utilizing ADI’s RF, mixed-signal, and mmWave IC and system-level design expertise. Learn how ADI can accelerate your mmWave 5G deployments across the entire 24 GHz to 47 GHz space.

The Vanteon vProtean SDR demonstrates a self-contained ADRV9004 based radio utilizing fast frequency hopping of custom waveforms for long range communication applications.

See how ADI's methodology to meet power domain sensitivity and realistic power supply noise requirements optimizes power solutions for RF signal chains. The optimized power solution improves form factor, power efficiency and power loss of the standard power solution while achieving the RF signal chain dynamic performances. This methodology demonstrates various power supply design optimizations including RF Transceivers, RF Amplifiers, High Speed ADCs and DACs, and more.

ADI's technology expertise in direct RF data converters as well as high performance clocking and power solutions are showcased in this demo. Included are the AD9213 development platform, ADF4377 clock PLL/VCO, and a complete power management solution.

Vector network analysis is now used beyond the lab in applications that range from system health monitoring solutions to production test equipment. See how a small form factor 20GHz, 8-port network analyzer solution that performs live measurements and displays s-parameter magnitude and phase measurement results in a custom-built graphical user interface.

Wireless systems depend on filters to attenuate out of band spurious signals. As systems scale from Narrowband to Wideband (Multi GHzs), next generation wideband designs are requiring large numbers of fixed filters in switched bank configuration to cover all frequency requirements. Using ADIs next generation ADMV8818, a single IC can replace a large array of fixed filters in multi GHz systems, to deliver PCBA savings and enable a wideband software defined solution. Interface control is enjoyed via the Digitally selectable frequency of operation and ultimate design flexibility is at hand as the ADMV8818 offers LFP, HPF and BPF configurations along with a bypass path as needed. Save board space, design effort and deliver immersive wideband systems using ADIs next generation ADMV8818 solution.

Innovative wideband switches and attenuators in SOI process are exhibited on their evaluation boards for key performance metrics within a live demo. The latest devices in bondable and packaged form warrant solid performance over the mmWave 5G frequency span, while offering an attractive solution to bias and size challenges in microwave assemblies.

Learn more about ADI's high performance millimeter wave signal chain for 50GHz+ wireless communications test solutions. The system demonstrates instrument grade error vector magnitude (EVM) performance (<-40dB) covering the latest 5G and Wifi frequency bands. The demo features ADI's latest RF sampling MxFE^® converters and widest bandwidth RF front end components, including mixers, amplifiers and switches. The Signal Chain also highlights clocking and power management devices for rapid evaluation and deployment.

The AD-SYNCHRONA14-EBZ is an affordable solution for high-accuracy time and frequency reference distribution. Accepting accepts various reference clocks including 10 MHz and PPS signals from external sources, it is an ideal self-contained device to use in applications that need a highly accurate frequency and phase controlled source clocks. Designed around the Analog Devices AD9545 and HMC7044, it greatly simplifies clock distribution and multi-channel synchronization in complex systems. Coming in a 1U mechanical form factor it is compact to use on the lab bench or equipment rack. Using popular industry connector SMA and TwinAX interfaces most labs will already have the needed cables.

ADI's Silent Switcher^® architecture minimizes EMI emissions enabling the µModule Regulator to pass CISPR22 class B. The combination of Silent Switcher, wide operating frequency range and multiple operating modes minimize EMI and make it ideal for noise sensitive applications. Quad configurable output Silent Switcher regulators can replace up to 4 single output competitive modules enabling design acceleration and BOM reduction.

To ease design challenges, Arrow and Analog Devices provide validated reference platforms that connect Analog Devices’ precision data converters, sensors, and other signal chain components to FPGAs and microprocessors. One such example is the DataStorm DAQ Platform. The DataStorm DAQ is an Intel^® Cyclone^® V development kit designed for quick prototyping or proof of concept development. The DataStorm DAQ platform includes demo designs and tools, such as HDL code, device drivers, and reference project examples for the ADRV9002 for rapid prototyping and reduced development time.

Today there are few platforms that provide a common data and control path that allow system level prototyping of microwave and RF front ends with high speed digitizers. This leads to isolation between development teams (Front end and baseband), and complicates system integration because it happens very late in the development cycle. Without a common platform that can be used in controlling the Microwave, RF and digitizer hardware, it is difficult and sometimes impossible to perform reproduceable tests on the full signal chain. The FMC X-Microwave Bridge Kit solves this industry challenge by enabling the controller used for the high speed digitizer, to connect to and control the Microwave and RF front ends. X-Microwave modules provide solutions for prototyping microwave and RF circuits faster, easier and at a lower cost. They offer a broad selection of ADI parts as drop-in blocks in different configurations and optimized for different frequencies. The “Bridge” allows these blocks to be controlled by a standard Xilinx or Intel Development Kit, via FMC, enabling control both microwave, RF front ends and high speed digitizers in a unified environment (on the FPGA or SoC).
