PMIC 和多功能

Analog Devices 的许多电池管理产品都把我们的独立型电池充电器功能与一种或多种其他功能结合。我们的电源管理 IC (PMIC) 产品组合了电池充电、电源通路 (PowerPath™) 控制、以及一个或多个 DC-DC 稳压器,旨在实现针对手持式产品的完整电源解决方案。我们的 PowerPath 产品和架构允许从 VIN 和电池向负载供电,从而确保较短的充电时间,并为便携式设备设计提供更大的灵活性。它们还可在电池电量耗尽的情况下于系统中实现 “即时接通”。其他特点包括用于 USB 和墙上适配器的双路输入、开关稳压器、比较器或 LDO。
Quick Battery Management Search
Chemistry |
Charger |
V
A
Features |
DC/DC* |

*DC/DC in addition to battery charger

PMIC 和多功能

  按住Shift键进行二次排序
SortOrderPart#Number of OutputsBuck Output Current
(typ)
(A)
Buck-Boost Output Current
(typ)
(A)
Boost Switch Current
(typ)
(A)
Inverting Switch Current
(typ)
(A)
LDO Output Current
(typ)
(A)
PowerPathBattery ChemistryPrice (1000+)
($ US)
1ADP5072 2-- 1 600m--- $2.19 (ADP5072ACBZ-R7)
2ADP1031 3--- 300m--- $5.18 (ADP1031ACPZ-4-R7)
3ADP2450 2 500m------ $1.50 (ADP2450ACPZ-1-R7)
4LTC7815 3 25, 25- 25---- $4.35 (LTC7815EUHF#PBF)
5LTC4091 1 2---- Linear PowerPath Li-Ion, Li-Polymer $3.25 (LTC4091EDJC#PBF)
6ADP5350 4-- 500m- 150m, 150m, 150m- Li-Ion $3.49 (ADP5350ACBZ-1-R7)
7LT8603 4 1.5, 1.8, 2.5- 20---- $5.35 (LT8603EUJ#PBF)
8LTC7813 2 20- 20---- $4.82 (LTC7813EUH#PBF)
9LTC7812 2 20- 20---- $4.00 (LTC7812EUH#PBF)
10LTC3106 1- 300m---- Li-Ion, Li-Poly, NiMH $2.94 (LTC3106EUDC#PBF)
11LTC3899 3 15, 15- 15---- $4.95 (LTC3899EUHF#PBF)
12ADP5070Reference Circuit Available 2-- 1 600m--- $2.19 (ADP5070ACPZ)
13ADP5071 2-- 2 1.2--- $2.39 (ADP5071ACPZ)
14LT3668 3 400m--- 200m, 200m-- $2.55 (LT3668EMSE#PBF)
15LT8471 2 2, 2- 2, 2 2, 2--- $3.75 (LT8471EFE#PBF)
16LT3667 3 400m--- 200m, 200m-- $2.55 (LT3667EMSE#PBF)
17ADP5080 8 800m, 1.15, 1.5, 2, 3 2-- 300m, 400m-- $3.99 (ADP5080ACBZ-1-RL)
18LTC3676 7 1.5, 1.5, 2.5, 2.5--- 300m, 300m, 300m-- $5.50 (LTC3676EUJ#PBF)
19LTC4089-3 1----- Linear PowerPath Li-Ion, Li-Polymer $2.95 (LTC4089EDJC-3#PBF)
20LTC3859AL 3 25, 25- 25---- $4.35 (LTC3859ALEUHF#PBF)
21ADP5052 5 1.2, 1.2, 4, 4--- 200m-- $3.59 (ADP5052ACPZ-R7)
22ADP5050 5 1.2, 1.2, 4, 4--- 200m-- $4.39 (ADP5050ACPZ-R7)
23LTC4090-3 1----- Linear PowerPath Li-Ion, Li-Polymer $3.25 (LTC4090EDJC-3#PBF)
24LTC4000-1 1----- External PFET Lead Acid, LiFePO4, Li-Ion, Li-Polymer, NiCd, NiMH $3.95 (LTC4000EUFD-1#PBF)
25LTC3586-3 4 400m, 400m 1 800m-- Switching PowerPath Li-Ion, Li-Polymer $5.30 (LTC3586EUFE-3#PBF)
26LTC3586-2 4 400m, 400m 1 800m-- Switching PowerPath Li-Ion, Li-Polymer $5.30 (LTC3586EUFE-2#PBF)
27LTC4156 1----- Internal Ideal Diode, Switching PowerPath LiFePO4 $2.95 (LTC4156EUFD#PBF)
28LTC3553-2 2 200m--- 150m Linear PowerPath Li-Ion, Li-Polymer $2.25 (LTC3553EUD-2#PBF)
29LT8582 2-- 3, 3 4.3--- $3.75 (LT8582EDKD#PBF)
30ADP5041 3 1.2--- 300m, 300m-- $1.79 (ADP5041ACPZ-1-R7)
31ADP5040 3 1.2--- 300m, 300m-- $1.39 (ADP5040ACPZ-1-R7)
32ADP5037 4 800m, 800m--- 300m, 300m-- $1.69 (ADP5037ACPZ-1-R7)
33ADP5024 3 1.2, 1.2--- 300m-- $1.79 (ADP5024ACPZ-1-R7)
34ADP5023 3 800m, 800m--- 300m-- $1.59 (ADP5023ACPZ-1-R7)
35LTC4155 2----- Switching PowerPath Li-Ion, Li-Polymer $2.95 (LTC4155EUFD#PBF)
36LTC4000 1----- External PFET Lead Acid, LiFePO4, Li-Ion, Li-Polymer, NiCd, NiMH $3.95 (LTC4000EUFD#PBF)
37LT3507A 4 1.8, 1.8, 2.7--- 1-- $4.25 (LT3507AEUHF#PBF)
38ADP5034 4 1.2, 1.2--- 300m, 300m-- $1.99 (ADP5034ACPZ-1-R7)
39ADP5033 4 800m, 800m--- 300m, 300m-- $1.90 (ADP5033ACBZ-10-R7)
40LTC4085-4 1----- Linear PowerPath Li-Ion, Li-Polymer $1.65 (LTC4085EDE-4#PBF)
41LTC4085-3 1----- Linear PowerPath Li-Ion, Li-Polymer $1.65 (LTC4085EDE-3#PBF)
42LT3645 2 500m--- 200m-- $2.25 (LT3645EUD#PBF)
43ADP5043 2 800m--- 300m-- $1.79 (ADP5043ACPZ-1-R7)
44ADP5042 3 800m--- 300m, 300m-- $1.99 (ADP5042ACPZ-1-R7)
45LTC4160-1 1----- Switching PowerPath Li-Ion, Li-Polymer $2.85 (LTC4160EUDC-1#PBF)
46LTC4160 1----- Switching PowerPath Li-Ion, Li-Polymer $2.85 (LTC4160EUDC#PBF)
47LTC4098-3.6 1----- Switching PowerPath LiFePO4 $2.65 (LTC4098EUDC-3.6#PBF)
48LTC3675 7 500m, 500m, 1, 1 1 1- 25m-- $5.05 (LTC3675EUFF#PBF)
49LTC3589-2 8 1, 1, 1.6 1.2-- 25m, 250m, 250m, 250m-- $4.65 (LTC3589EUJ-2#PBF)
50LTC3589-1 8 1, 1, 1.6 1.2-- 25m, 250m, 250m, 250m-- $4.65 (LTC3589EUJ-1#PBF)
