DS2186

发送线路接口

Viewing:

产品详情

Line interface for T1 (1.544MHz) and CEPT (2.048MHz) primary rate networks
On-chip transmit LBO (line build-out) and line drivers eliminate external components
Programmable output-pulse shape supports short- and long-loop applications
Supports bipolar and unipolar input data formats
Transparent B8ZS and HDB3 zero-code-suppression modes
Compatible with DS2180A T1 and DS2181A CEPT transceivers DS2141A T1 and DS2143 E1 controllers
Companion to the DS2187 receive line interface and DS2188 T1/CEPT jitter attenuator
Single 5V supply; low-power CMOS technology
