DS2180AQN
searchIcon

DS2180AQN

T1收发器

更多 showmore-icon

产品详情
特性
  • Single-chip DS1 rate transceiver
  • Supports common framing standards
    • 12 frames/superframe "193S"
    • 24 frames/superframe "193E"
  • Three zero suppression modes:
    • B7 stuffing
    • B8ZS
    • Transparent
  • Simple serial interface used for configuration, control and status monitoring in processor mode
  • Hardware mode requires no host processor; intended for standalone applications
  • Selectable 0, 2, 4, 16-state robbed-bit signaling modes
  • Allows mix of clear and non-clear DS0 channels on same DS1 link
  • Alarm generation and detection
  • Receive error detection and counting for transmission performance monitoring
  • 5V supply, low-power CMOS technology
  • Surface-mount package available, designated DS2180AQ
  • Industrial temperature range of -40°C to +85°C available, designated DS2180AN or DS2180AQN
  • Compatible to DS2186 transmit line interface, DS2187 receive line interface, DS2188 jitter attenuator, DS2175 T1/CEPT elastic store, DS2290 T1 isolation stik, and DS2291 T1 long loop stik
