Инструментальные усилители

Компания ADI представляет на рынке полную линейку недорогих усилителей малой мощности, а также усилителей общего назначения для всех возможных сфер применения. Например, инструментальный усилитель общего назначения с улучшенными характеристиками AD8221, усилитель с нулевым дрейфом AD8230 и усилитель на полевых транзистрах AD8220.

Готовится к печати и уже доступно на нашем сайте 3-е издание A Designer's Guide to Instrumentation Amplifiers

Новые продукты

Loading Selection Table Data. Please wait...

Processing request. Please wait.

Help

  • Sort: Click on the arrows beneath the parameter on which you would like to sort, ascending and descending order.

  • Add/Remove Parameters: Click on the Add/Remove Parameters button. Select/deselect the checkbox of the parameter in the add/remove parameter pop up box. Click on "Update" for the table to redraw with new selection of parameters.

  • Filter: Enter the desired value to filter parameter(s) by, and click the "Update Results" button to update the table display.

  • Reset Table: Click "Reset Table" to clear all filters/sorts and restore table back to default view.

  • Quick Filters: When applicable, select a quick filter with preset parameters filtered to narrow the results returned.

  • No Parts Returned: Adjust the filters on your least critical selection parameters in order to broaden your search.

Instrumentation Amplifiers
  • Use Up or Down Arrows in Heading to Sort in Ascending or Descending Order
  • Narrow Results by Entering Values in Numeric Fields or by Pull Down Selections

Add/Remove Parameters

























Part#
Results: 56
DescriptionSingle/Dual SupplyVcc-VeeSupply Current Gain Setting MethodBandwidth G=10 (kHz typ)Gain min.Gain max.Gain Range (min to max)Min CMRR @ 60 Hz Min GainMin CMRR @ 60Hz Max GainVnoise RTI 1-10 Hz µVp-p Price* (1000-4999)TypeArchitecture
Sort
sortDescending sortAscending
sortDescending sortAscending

sortDescending sortAscending
sortDescending sortAscending
sortDescending sortAscending
sortDescending sortAscending
sortDescending sortAscending
sortDescending sortAscending
sortDescending sortAscending
sortDescending sortAscending

Filter By Value

AD522Diff AmpDual10V to 36V8mAResistor3011,0001,00075dB100dB4**In-amp-
AD524Precision IADual12V to 36V5mAPin40011,0001,00070dB110dB0.3 $9.52 In-amp-
AD526Software ProgrammableDual9V to 33V14mADigital35011616--3 $6.39 In-amp-
AD620General Purpose IADual4.6V to 36V1.3mAResistor800110,00010,00073dB110dB0.28 $3.31 In-amp-
AD621Precision IADual4.6V to 36V1.3mAPin800101009093dB110dB0.28 $4.09 In-amp-
AD622Low Cost IADual5.2V to 36V1.3mAResistor80011,0001,00066dB103dB0.3 $2.51 In-amp-
AD623S.S R-R IASingle/Dual2.7V to 12V0.55mAResistor10011,0001,00070dB105dB2 $1.40 In-amp-
AD624Precision IADual12V to 36V5mAPin15011,0001,00070dB110dB0.3 $15.87 In-amp-
AD625Programmable Gain IADual12V to 36V5mAResistor400110,00010,00070dB110dB0.3 $8.78 In-amp-
AD626Diff AmpSingle/Dual4.8V to 12V2mAPin100101009055dB55dB2 $3.70 Current Sense, In-ampCurrent Sense
AD627Micropower IASingle/Dual2.2V to 36V0.085mAResistor3051,00099577dB77dB0.56 $2.56 In-amp-
AD628High CMV DASingle/Dual4.5V to 36V1.6mAPin, Resistor6000.110010075dB75dB15 $1.78 -Difference Amp
AD629High CMV DADual5V to 36V1mAfixed50011177dB77dB15 $2.84 -Difference Amp
AD8202High CMV DASingle3.5V to 12V0.25mAfixed50--2082dB82dB10 $1.51 Current SenseCurrent Sense
AD8203High CMV DASingle3.5V to 12V0.25mAfixed60--1482dB82dB10 $1.37 Current SenseCurrent Sense
AD8205S.S Diff AmpSingle4.5V to 5.5V2mAfixed50--5078dB78dB20 $1.51 Current SenseCurrent Sense
AD8206S.S Diff AmpSingle4.5V to 5.5V2mAfixed100--2076dB76dB20 $1.37 Current SenseCurrent Sense
AD8210Bi-Directional Shunt MonSingle4.5V to 5.5V1.5mAfixed500202020100dB100dB7 $1.81 Current SenseCurrent Sense
AD8211High CMV Shunt MonSingle4.5V to 5.5V2mAfixed500202020100dB100dB7 $0.81 Current SenseCurrent Sense
AD8212High CMV Shunt MonSingle7V to 65V720µAResistor100011,0001,000100dB100dB1.1 $0.93 Current SenseCurrent Sense
AD8213Dual High CMV Shunt MonSingle4.5V to 5.5V2.5mAfixed500202020100dB100dB7 $2.01 Current SenseCurrent Sense
AD8214High CMV Threshold DetecSingle5V to 65V1.2mAResistor-110010080dB80dB2.2 $0.76 Current SenseCurrent Sense
AD8215High CMV Shunt MonSingle4.5V to 5.5V2.2mAfixed450202020100dB100dB7 $1.21 Current SenseCurrent Sense
AD8216High BW 65 V Diff AmpSingle4.5V to 5.5V2mAfixed300033380dB80dB20 $1.62 Current SenseCurrent Sense
AD8220R-R JFET IASingle/Dual4.6V to 36V750µAResistor80011,0001,00078dB94dB0.8 $2.32 In-amp-
AD8221High Performance IADual4.6V to 36V1mAResistor56211,0001,00080dB130dB0.25 $2.01 In-amp-
AD8222Dual High Performance IADual-1.1mAResistor75011,0001,00080dB130dB0.25 $3.63 In-amp-
AD8223S.S R-R IASingle/Dual3V to 24V0.5mAPin12551,000-80dB90dB0.6 $1.05 In-amp-
AD8224Dual JFET R-R IASingle/Dual4.6V to 36V0.8mAResistor80011,000-78dB94dB0.8 $4.17 In-amp-
AD8225Fixed G=5 IADual3.4V to 36V1.2mAfixed900--586dB86dB1.5 $3.29 In-amp-
AD8226Wide Supply R-R out IASingle/Dual2.2V to 36V400µAResistor20051,00099580dB105dB2 $1.40 In-ampDifference Amp
AD8227Wide Supply R-R out IASingle/Dual2.2V to 36V400µAResistor20051,00099590dB105dB0.5 $1.38 In-amp-
AD8228Precision IADual4.6V to 36V1mAPin6501010010,100100dB120dB0.5 $3.03 In-ampDifference Amp
AD8230Zero Drift IASingle/Dual8V to 16V3.5mAResistor221,000998-110dB3 $2.99 In-amp-
AD8231Zero Drift Software ProgSingle3V to 6V5mADigital, Pin, Software700112812880dB110dB0.7 $1.71 In-amp-
AD8236-Single1.8V to 5.5V40µAResistor9--10094dB110dB4 $0.99 In-amp-
AD8250Software ProgrammableDual10V to 34V4.5mADigital, Pin30001101080dB98dB1 $5.01 In-amp-
AD8251Software ProgrammableDual10V to 34V4.5mADigital, Pin250018880dB98dB1.2 $5.01 In-amp-
AD8253Software ProgrammableDual10V to 34V5.3mADigital, Pin400011,00099980dB100dB1 $4.95 In-amp-
AD8270Dual Diff AmpDual5V to 36V2.5mAPin-0.51.21.270dB80dB1 $1.91 -Difference Amp
AD8271--5V to 36V2.6mA--0.51.21.2--- $1.25 -Difference Amp
AD8273Dual Audio Diff AmpDual5V to 36V2.5mAPin-0.52277dB-2 $1.67 -Difference Amp
AD8274Precision Diff AmpDual5V to 36V2.6mA-100000.522--- $1.05 Difference AmpDifference Amp
AD8275Level Shifting ACD DriverSingle3.3V to 15V2.3mAResistor---0.296dB96dB- $1.60 -Difference Amp
AD8276-Single/Dual2V to 36V0.2mAfixed---186dB-- $0.95 --
AD8277--2V to 36V0.4mA----1--- $1.60 -Difference Amp
AD8278--2V to 36V0.2mA----2--- $0.95 -Difference Amp
AD8290Sensor Amp-2.6V to 5.5V1.8mAfixed-505050--0.75 $1.52 In-ampDifference Amp
AD8293G160Zero Drift Filter AmpSingle1.8V to 5.5V1.3mAfixed0.516016016094dB94dB0.7 $0.99 Current Sense, In-ampCurrent Sense
AD8293G80Zero Drift Filter AmpSingle1.8V to 5.5V1.3mAfixed0.580808094dB94dB0.7 $0.99 Current Sense, In-ampCurrent Sense
AD8295Precision IADual4.6V to 36V2.3mAResistor75011,0001,00080dB130dB0.25 $2.59 In-ampDifference Amp
AD8553Zero Drift IASingle1.8V to 5.5V1.3mAResistor10.110,00010,00080dB120dB0.7 $1.32 In-ampDifference Amp
AD8555Sensor AmpSingle2.7V to 5.5V2.5mADigitaln/a701,2801,21080dB96dB0.5 $3.12 In-amp-
AD8556Sen/Filter AmpSingle4.5V to 5.5V2.7mADigitaln/a701,2801,21080dB94dB0.5 $2.88 In-amp-
AD8557Sensor AmpSingle2.7V to 5.5V-Digital-281,300-75dB96dB- $2.13 In-amp-
AMP03Precision Diff AmpDual12V to 36V2.5mAfixed---185dB85dB2 $2.81 -Difference Amp
Please scroll down to see more data.
