ADAQ4381-4

発売前

ADAQ4381-4

Quad, 14-bit, 4 MSPS, Simultaneous Sampling, μModule Data Acquisition Solution

すべて表示

発売前

製品の詳細

ADAQ4381-4 Functional Block Diagram slide

お探しの製品ではありませんか

製品セレクション・テーブル

すべてのドキュメントを表示

質問する

以下に質問を入力すると、アナログ・デバイセズのナレッジ・ベースからよくある質問の答えを見ることができます。

検索

その他のサポート

サポート

アナログ・デバイセズのサポート・ページはアナログ・デバイセズへのあらゆるご質問にお答えするワンストップ・ポータルです。

ADIサポート・ページはこちら

ADIコミュニティに問い合わせる。

EngineerZoneコミュニティはこちら

よく聞かれる質問（FAQ）

ご購入＆ご注文に関するFAQ

製品モデル 1

1Ku当たりの価格

価格は未定

特長

Easy to use μModule^® data acquisition system
- 11× footprint reduction vs. discrete solution
- Integrated critical passive components
- 5 V single supply operation
Guaranteed 14-bit no missing codes
On-chip oversampling function
2-bit resolution boost
Out of range Indicator (ALERT)
INL: ±0.5 LSB typical, ±1 LSB maximum
SNR (typical)
- 84 dB at Gain = 1.0, f_IN= 1 kHz
- 90 dB with OSR = ×8 at Gain = 1.0, f_IN= 1 kHz
Channel-to-Channel phase matching: 0.005° typical at f_IN= 20kHz
Integrated high precision reference, 3 ppm/oC typical drift

Gain error: 0.005% typical
Gain drift: 0.8 ppm/°C typical
Integrated internal buffer with VCM generation
Integrated fully differential ADC driver with signal scaling
- Wide input common-mode voltage range
- High common-mode rejection
Single-ended to differential conversion
Pin selectable input range with overrange
- Input range: ±2 V, ±3.3 V, ±5.5 V, ±11 V
- Gain/Attenuation: G = 0.3, 0.6, 1.0, and 1.6
High-speed serial interface
8 mm x 8 mm, 0.8 mm pitch, 81-ball CSP_BGA package

製品概要

The ADAQ4381-4 is a quad-channel precision data acquisition (DAQ) signal chain μModule solution that reduces the development cycle of a precision measurement system by transferring the signal chain design challenges of component selection, optimization, and layout from the designer to the device.

Using system-in-package (SIP) technology, the ADAQ4381-4 reduces end system component count by combining multiple common signal processing and conditioning blocks into a single device. These blocks include a quad-channel, high resolution 14-bit, 4 MSPS simultaneous sampling SAR ADC, low noise, fully differential ADC driver amplifier, a 3.3 V precision voltage reference, low-noise buffer amplifiers, and low-dropout linear regulator.

The ADAQ4381-4 has an on-chip oversampling blocks to improve the dynamic range and reduce noise at lower bandwidths. The oversampling can boost up to two bits of added resolution. It provides the flexibility of a configurable ADC driver feedback loop to allow four gain and attenuation adjustments, and accept both fully differential or single-ended to differential input configuration.

Using Analog Devices, Inc. iPassives^® technology, the ADAQ4381-4 incorporates critical passive components with superior matching and drift characteristics to minimize temperature dependent error sources and to offer optimized signal chain performance. Housed in a small 8 mm × 8 mm × 0.8 mm pitch, 81- ball CSP_BGA package, the ADAQ4381-4 enables compact design without sacrificing performance and simplifies end system bill of materials management. The ADAQ4381-4's optimum performance is guaranteed with a single 5 V supply operation, all the required bypass and decoupling capacitors are included inside the package. The level of ADAQ4381-4 system integration solves many design challenges, which enables a compact and simple solution for a multichannel application.

The conversion result can clock out simultaneously through 4-wire mode for faster throughput or through 1-wire serial mode when slower throughput is allowed. The ADAQ4381-4 is compatible with 1.8 V, 2.5 V, and 3.3 V interfaces using the separate logic supply. The ADAQ4381-4 is specified to operate over a temperature range of −40°C to +105°C.

APPLICATIONS

Lab grade battery test system
Motor control current sense
Motor control position feedback
Sonar
Power quality monitoring
Data acquisition system
Erbium-Doped Fiber Amplifier (EDFA) applications
I and Q demodulation
