Quad or More Supply Monitors
Analog Devices quad-supply supervisory circuits help simplify design due to their high accuracy, adjustable thresholds and tolerances, and a guaranteed reset signal down to an industry-leading low of 0.5 V. Most ADI supervisors exhibit ±1.5% threshold accuracy around the nominal threshold voltage—minimizing the required system voltage margin and probability of system malfunction. Voltage supervisors with pin or I2C/SMBus adjustable thresholds and tolerances provide users with maximum flexibility, which allows a single part to be used across multiple designs.
Product Selection Table
Product Selector Card
LT Journal
- Power Supply Sequencing Simplified PDF
- I2C Programmable Multichannel Voltage Supervisors with EEPROM PDF
- 4- and 6-Supply Monitors Feature ±1.5% Accuracy and Watchdog Timers for Rails Down to 1.2V PDF
- Mar 2008 - 6-Input Supervisors Offer Accurate Monitoring and 125°C Operation PDF
- Dec 2003 Hot Swap Controller with Power-Up Timeout Function Simplifies Hot Swapping Boards with Multiple Power Supplies PDF
- May 2001 Ramp Three Supplies with a Supply Monitor and Hot Swap Controller PDF
- Sep 2006 Sequencer-Supervisor Simplifies Design of Multi-Supply Systems PDF
- Dec 2003 Low Voltage Wizardry Provides the Ultimate Power-On Reset Circuit PDF
- Dec 2002 Programmable Quad Supervisors Offer Unparalleled Flexibility for Multi-Voltage Monitoring Applications PDF
Application Notes
Technical Articles
Quad or More Supply Monitors
| SortOrder | Part# | Number of Supplies | Reset Voltage | Second Reset Voltage | Third Reset Voltage | Fourth Reset Voltage | Fifth Reset Voltage (V) | Isupply (typ) (A) | Vs+ (max) (V) | Price (1000+) ($ US) |
|---|---|---|---|---|---|---|---|---|---|---|
| 1 | LTC2964 | 4 | 1.2V, 1.5V, 1.8V, 1V, 2.5V, 3.3V, 5V, Adj, -Adj | Adj, -Adj | Adj, -Adj | Adj, -Adj | Adj, -Adj | 140µ | 5.5 | $2.23 (LTC2964CUDC#PBF) |
| 2 | LTC2962 | 4 | 1.2V, 1.5V, 1.8V, 1V, 2.5V, 3.3V, 5V, Adj, -Adj | Adj, -Adj | Adj, -Adj | Adj, -Adj | Adj, -Adj | 140µ | 5.5 | $1.98 (LTC2962CUD#PBF) |
| 3 | LTC2963 | 4 | 1.2V, 1.5V, 1.8V, 1V, 2.5V, 3.3V, 5V, Adj, -Adj | Adj, -Adj | Adj, -Adj | Adj, -Adj | Adj, -Adj | 140µ | 5.5 | $2.23 (LTC2963CUDC-1#PBF) |
| 4 | LTC2937 | 6 | Adj | Adj | Adj | Adj | Adj | 1m | 16.5 | $5.95 (LTC2937CUHE#PBF) |
| 5 | LTC2936 | 6 | Adj | Adj | Adj | Adj | Adj | 700µ | 13.9 | $5.60 (LTC2936CGN#PBF) |
| 6 | ADM8710 | 4 | 1.8V, 3.3V, Adj | 1.8V, 3.3V | Adj | Adj | - | 100µ | 5.5 | $1.79 (ADM8710L2ARJZ-RL7) |
| 7 | LTC2933 | 6 | Adj | Adj | Adj | Adj | Adj | 700µ | 13.9 | $4.85 (LTC2933CDHD#PBF) |
| 8 | ADM12914 | 4 | Adj | Adj | Adj | Adj | - | 40µ | - | $2.87 (ADM12914-1ARQZ) |
| 9 | LTC2939 | 6 | 3.3V, 5V | 1.2V, 1.5V, 1.8V, 2.5V, 3.3V | 1.2V, 1.5V, 1.8V, 2.5V, Adj | 1.2V, 1.5V, 1.8V, Adj, -Adj | Adj | 80µ | 6 | $2.70 (LTC2939CMS#PBF) |
| 10 | LTC2938 | 4 | 3.3V, 5V | 1.2V, 1.5V, 1.8V, 2.5V, 3.3V | 1.2V, 1.5V, 1.8V, 2.5V, Adj | 1.2V, 1.5V, 1.8V, Adj, -Adj | - | 80µ | 6 | $2.15 (LTC2938CDE#PBF) |
| 11 | ADM6339 | 4 | 1.8V, 2.5V, 3.3V, 3V, 5V, -5V | Adj, -Adj | Adj, -Adj | Adj, -Adj | - | 500n | 5.5 | $1.79 (ADM6339AARJZ-RL7) |
| 12 | ADM2914 | 4 | Adj, -Adj | Adj, -Adj | - | Adj, -Adj | - | 20µ | - | $2.56 (ADM2914-1ARQZ) |
| 13 | AD5100 | 4 | Adj | Adj | Adj | Adj | - | 2m | 30 | $3.05 (AD5100YRQZ-1RL7) |
| 14 | ADM1184 | 4 | Adj | Adj | Adj | Adj | - | 80µ | 5.5 | $1.84 (ADM1184ARMZ) |
| 15 | ADM6710 | 4 | 1.8V, 2.5V, 3.3V, 5V | Adj | Adj | Adj | - | 12µ | 5.5 | $1.67 (ADM6710BARJZ-REEL7) |
| 16 | LTC2932 | 6 | 3.3V, 5V | 2.5V, 3.3V, 3V | 1.5V, 1.8V, 2.5V, Adj | 1.5V, 1.8V, Adj, -Adj | Adj | 52µ | 7 | $2.80 (LTC2932CF#PBF) |
| 17 | LTC2931 | 6 | 3.3V, 5V | 2.5V, 3.3V | 1.5V, 1.8V, 2.5V, Adj | 1.5V, 1.8V, Adj, -Adj | Adj | 52µ | 7 | $2.80 (LTC2931CF#PBF) |
| 18 | LTC2930 | 6 | 3.3V, 5V | 2.5V, 3.3V, 3V | 1.5V, 1.8V, 2.5V, Adj | 1.5V, 1.8V, Adj, -Adj | Adj | 52µ | 7 | $2.56 (LTC2930CDD#PBF) |
| 19 | LTC2914 | 4 | Adj, -Adj | Adj, -Adj | Adj, -Adj | Adj, -Adj | - | 70µ | 6.6 | $3.75 (LTC2914CDHC-1#PBF) |
| 20 | LTC2910 | 8 | Adj | Adj | Adj | Adj | Adj | 70µ | 6.6 | $3.20 (LTC2910CDHC#PBF) |
| 21 | LTC2928 | 4 | Adj | Adj | Adj | Adj | - | 1m | 16.5 | $3.95 (LTC2928CG#PBF) |
| 22 | LTC2908 | 6 | 3.3V | 2.5V | 1.8V | 1.5V | Adj | 50µ | 7 | $2.56 (LTC2908CDDB-A1#TRPBF) |
| 23 | LTC2903-E1 | 4 | 5V | Adj | Adj | Adj | - | 20µ | 6.5 | $1.71 (LTC2903CS6-E1#TRPBF) |
| 24 | LTC2903-D1 | 4 | 3.3V | Adj | Adj | Adj | - | 20µ | 6.5 | $1.71 (LTC2903CS6-D1#TRPBF) |
| 25 | LTC2903-C1 | 4 | 5V | 3.3V | 1.8V | -5.2V | - | 20µ | 6.5 | $1.81 (LTC2903CS6-C1#TRPBF) |
| 26 | LTC2903-B1 | 4 | 5V | 3.3V | 2.5V | 1.8 | - | 20µ | 6.5 | $1.71 (LTC2903CS6-B1#TRPBF) |
| 27 | LTC2903-A1 | 4 | 3V | 2.5V | 1.8V | Adj | - | 20µ | 6.5 | $1.71 (LTC2903CS6-A1#TRPBF) |
| 28 | LTC2902 | 4 | 3.3V, 5V | 2.5V, 3.3V, 3V | 1.5V, 1.8V, 2.5V, Adj | 1.5V, 1.8V, Adj, -Adj | - | 43µ | 7 | $2.35 (LTC2902-1CGN#PBF) |
| 29 | LTC2901 | 4 | 3.3V, 5V | 2.5V, 3.3V, 3V | 1.5V, 1.8V, 2.5V, Adj | 1.5V, 1.8V, Adj, -Adj | - | 43µ | 7 | $2.35 (LTC2901-1CGN#PBF) |
| 30 | LTC2900 | 4 | 3.3V, 5V | 2.5V, 3.3V, 3V | 1.5V, 1.8V, 2.5V, Adj | 1.5V, 1.8V, Adj, -Adj | - | 43µ | 7 | $1.85 (LTC2900-1CMS#PBF) |
