Features and Benefits
2 MSPS (wideband warp and warp mode)
1.5 MSPS (normal mode)
- INL: ±0.5 LSB typical, ±1.5 LSB maximum (±23 ppm of FSR)
- 16-bit resolution with no missing codes
- Dynamic range: 92.5 dB typical
- SINAD: 91 dB minimum @ 20 kHz (VREF = 2.5 V)
- THD: −115 dB typical @ 20 kHz (VREF = 2.5 V)
- 2.048 V internal reference: typical drift 8 ppm/°C; TEMP output
- Differential input range: ±VREF (VREF up to 2.5 V)
- No pipeline delay (SAR architecture)
- Parallel (16-, or 8-bit bus) and serial 5 V/3.3 V/2.5 V interface
- SPI®/QSPI™/MICROWIRE™/DSP compatible
- Single 2.5 V supply operation
The AD7622 is a 16-bit, 2 MSPS, charge redistribution SAR, fully differential, analog-to-digital converter (ADC) that operates from a single 2.5 V power supply. The part contains a high speed, 16-bit sampling ADC, an internal conversion clock, an internal reference (and buffer), error correction circuits, and both serial and parallel system interface ports. It features two very high sampling rate modes (wideband warp and warp) and a fast mode (normal) for asynchronous rate applications. The AD7622 is hardware factory calibrated and tested to ensure ac parameters, such as signal-to-noise ratio (SNR), in addition to the more traditional dc parameters of gain, offset, and linearity. The AD7622 is available in Pb-free only packages with operation specified from −40°C to +85°C.
- Medical instruments
- High speed data acquisition/high dynamic data acquisition
- Digital signal processing
- Spectrum analysis
Product Lifecycle Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
Evaluation Kits (1)
The EVAL-AD7622EDZ is a fully featured evaluation Kit for the AD7622. This board operates in stand alone mode or in conjunction with the Converter Evaluation and Development board, EVAL-CED1Z . When operated with the Converter Evaluation and Development board, software is provided enabling the user to perform detailed analysis of the ADC's performance. This software includes the technical note describing the operation and set up of the evaluation board in standalone operation or when operated with the Converter Evaluation and Development board.
Documentation & Resources
AD7622 Companion Parts
Recommended Driver Amplifiers
- For a fully differential attenuating precision amplifier: AD8475.
- For low noise, high gain bandwidth: AD8021, ADA4899-1, AD8022.
- For single-ended to differential driver applications: AD8139, ADA4930-1.
- For low noise, low distortion, low power: ADA4841-1.
Recommended External Voltage References
