Multipliers/Dividers

An analog multiplier/divider is a device that produces an output voltage or current that is proportional to the product of two or more independent input voltages or currents. In addition to multiplying and dividing, multipliers can perform squaring, square-rooting and modulation functions. Applications include radar, communications, and industrial controls where a real-time response is required. Analog Devices’ offers the widest selection of multipliers and dividers.

For more detailed design and applications information, please see our Multiplier Applications Guide.

PRODUCT SELECTION TABLES

All Design Tools

  • Filter Filter
  • Photodiode Photodiode
  • Amp Tools Amp Tools
  • Product Search Product Search
  • ADIsimADC ADIsimADC
  • ADIsimDAC ADIsimDAC
  • ADC/DAC Tools ADC/DAC Tools
  • Product Search Product Search
  • ADIsimRF ADIsimRF
  • ADIsimPLL ADIsimPLL
  • RF Tools RF Tools
  • Product Search Product Search
  • ADIsimPower ADIsimPower
  • ADIsimPE ADIsimPE
  • Power Tools Power Tools
  • Product Search Product Search

Multipliers/Dividers

Part# -3dB BandwidthSlew Rate (V/µsSettling TimeAccuracy (%FS)Vin max (V)Supply Voltage (V max)Supply CurrentTemp RangeUS Price 1000-4999Transfer Function
ADL53912GHz8.8KV/µs2.1ns1% FS2.5V5.5V135mA-40 to 85°C $4.95W= aXY/U+Z
AD835250MHz1KV/µs20ns2% FS1V5.5V25mA-40 to 85°C $10.11[(X1-X2)(Y1-Y2)/U] + Z2
AD6331MHz20V/µs2µs2% FS10V18V6mA-40 to 85°C $4.23(X1-X2)(Y1-Y2)/(10V)+Z2
AD734-450V/µs200ns--16.5V12mA-55 to 125°C $14.3[(X1-X2)(Y1-Y2)/U] + Z2
AD834500MHz--2% FS1V9V35mA-40 to 85°C $18.06(4mA)*XY/(1V^2)
AD538400KHz1.4V/µs-1% FS10V18V7mA-55 to 125°C $34.52Vy(Vz/Vx)^m
AD53925MHz--2.5% FS4.2V15V10.2mA-55 to 125°C $19.37-VxVy/Vu
AD6321MHz20V/µs2µs500m% FS12V22V6mA-55 to 125°C $13.87[(X1-X2)(Y1-Y2)/U] + Z2
AD5341MHz20V/µs2µs250m% FS10V22V6mA-55 to 125°C $21.98(X1-X2)(Y1-Y2)/(10V)+Z2
AD5321MHz45V/µs1µs1% FS10V22V6mA-55 to 125°C $30.45(X1-X2)(Y1-Y2)/(10V)
