Accelerometers

Analog Devices accelerometers and iSensor® MEMS accelerometer subsystems provide accurate detection while measuring acceleration, tilt, shock, and vibration in performance driven application. Our portfolio leads the industry in power, noise, bandwidth, and temperature specifications, and offers a range of MEMS sensor and signal conditioning integration on chip. Our MEMS-based Circuits from the Lab® reference designs have been built and tested by ADI experts to help you jumpstart your next system design.
Product Selection Table

Accelerometers

  Hold Shift Key for secondary sorting
SortOrderPart#Accelerometer RangeIsupply (typ)
(A)
Vsupply (min)
(V)
Noise Density (typ)
(g/rtHz)
0G Offset Tempco (typ)
(g/°C)
Operating Temp RangeBandwidth (typ)
(Hz)
Output TypeSensing AxisSpecial FeaturesUS Price 1000 to 4999
($ US)
1ADXL372 200 g 22µ 1.6- 35m -40 to 105°C 3.2k I²C, SPI X, Y, Z Concussion Sensing, Shock $6.33
2ADXL357 10 g, 20 g, 40 g 200µ 2.25 80µ 125µ -40 to 125°C 1k SPI X, Y, Z- $31.78
3ADXL356 10 g, 20 g, 40 g 150µ 2.25 80µ 125µ -40 to 125°C 1.5k Analog X, Y, Z- $28.60
4ADXL355 2 g, 4 g, 8 g 200µ 2.25 25µ 100µ -40 to 125°C 1k SPI X, Y, Z- $28.25
5ADXL354 2 g, 4 g, 8 g 150µ 2.25 20µ 100µ -40 to 125°C 1.5k Analog X, Y, Z- $25.43
6ADXL151 120 g, 240 g, 480 g 5m 4.5-- -40 to 125°C 400 PSI5 X Automotive Safety-
7ADXL316 16 g- 1.8-- -40 to 105°C- Analog X, Y, Z- $2.86
8ADXL700 14.2 5m 3.135-- -40 to 105°C- SPI X, Y, Z Automotive Safety, Inclinometer-
9ADXL363 2 g, 4 g, 8 g 1.8µ 1.6 550µ 500µ -40 to 85°C 200 SPI X, Y, Z Power Management, Vital Sign Monitor $4.57
10ADXL375 200 g 145µ 2 5m 10m -40 to 85°C 1.6k I²C, SPI X, Y, Z Concussion Sensing, Shock $4.52
11ADIS16229 18 g 20m 3 248µ- -40 to 85°C 840 wireless 862 to 928 MHz X, Y Vibration-
12ADIS16000- 20m 3-- -40 to 85°C- wireless 862 to 928 MHz- Vibration-
13ADXL313 1 g, 2 g, 4 g 170µ 2 150µ 500µ -40 to 105°C 1.6k I²C, SPI X, Y, Z Inclinometer $3.42
14ADXL295 120 g 7m 3.135-- -40 to 105°C 408 SPI X, Y Automotive Safety, Vibration $12.46
15ADXL288 120 g 7m 3.135-- -40 to 105°C 408 SPI X, Y Automotive Safety $9.63
16ADXL377 200 g 300µ 1.8 2.4m 12m -40 to 85°C 1.6k Analog X, Y, Z Concussion Sensing, Shock $4.38
17ADXL362Reference Circuit Available 2 g, 4 g, 8 g 1.8µ 1.6 175µ 500µ -40 to 85°C 200 SPI X, Y, Z Power Management, Vital Sign Monitor $3.97
18ADXL350 1 g, 2 g, 4 g, 8 g 166µ 2- 170µ -40 to 85°C 1.6k I²C, SPI X, Y, Z- $4.57
19ADXL344 16 g 23µ 1.7- 700µ -40 to 85°C 1.6k I²C, SPI X, Y, Z- $1.15
20ADXL343 16 g 23µ 2- 400µ -40 to 85°C 1.6k I²C, SPI X, Y, Z- $1.15
21ADXL195 120 g- 3.135-- -40 to 105°C 408 SPI X Automotive Safety, Vibration-
22ADXL189B 120 g, 240 g, 30 g, 480 g, 60 g 5m--- -40 to 125°C 398 PSI5 X Automotive Safety $3.76
23ADXL185B 120 g, 240 g, 30 g, 480 g, 60 g 5m--- -40 to 125°C 398 PSI5 Z Automotive Safety $3.95
24ADXL212 2 g 700µ 3 500µ 2m -40 to 85°C 500 PWM X, Y- $13.45
25ADIS16228 18 g 40m 3 248µ- -40 to 125°C 5k SPI X, Y, Z Vibration $159.00
26ADXL206 5 g 700µ 4.75 110µ- -40 to 175°C 400 Analog X, Y Inclinometer $569.00
27ADIS16210 1.7 g 18m 3 190µ- -40 to 85°C 50 SPI X, Y, Z Inclinometer $97.00
28ADXL312 1.5 g, 12 g, 3 g, 6 g 170µ 2 340µ 800µ -40 to 105°C 1.6k I²C, SPI X, Y, Z Inclinometer $3.33
29ADXL337 3 g 350µ 1.8 300µ 1.1m -40 to 85°C 1.6k Analog X, Y, Z- $1.57
30ADIS16227 70 g 43m 3.15 3.3m- -40 to 125°C 14.25k SPI X, Y, Z Vibration $174.00
31ADIS16223 70 g 43m 3.15 3.3m- -40 to 125°C 14.25k SPI X, Y, Z Vibration $145.00
32ADXL346 16 g, 2 g, 4 g, 8 g 140µ 1.7 420µ 700µ -40 to 85°C 1.6k I²C, SPI X, Y, Z- $3.13
33ADXL327 2 g 350µ 1.8 250µ 1m -40 to 85°C 1.6k Analog X, Y, Z- $2.50
34ADXL326 16 g 350µ 1.8 300µ 1m -40 to 85°C 1.6k Analog X, Y, Z- $2.50
35ADXL325 6 g 350µ 1.8 250µ 1m -40 to 85°C 1.6k Analog X, Y, Z- $2.50
36ADXL345Reference Circuit Available 16 g, 2 g, 4 g, 8 g 135µ 2 420µ 400µ -55 to 105°C 1.6k I²C, SPI X, Y, Z- $3.04
37ADIS16240 19 g 1m 2.4 480µ- -40 to 85°C 1.6k SPI X, Y, Z Shock $27.38
38ADXL001Reference Circuit Available 250 g, 500 g, 70 g 5m 3.135 4m- -40 to 125°C 22k Analog X Vibration $13.69
39ADXL335 3 g 350µ 1.8 300µ 1m -40 to 85°C 1.6k Analog X, Y, Z- $2.50
40ADIS16209 ±180°, ±90° 14m 3 190µ- -40 to 125°C 50 SPI X, Y, Z Inclinometer $35.85
41ADXL180 50 g 7.7m 5 4m- -40 to 125°C 400 2-wire HV or I X Automotive Safety-
42ADIS16203 ±180° 11m 3-- -40 to 125°C 2.25k SPI Z Inclinometer $24.76
43ADIS16201 1.7 g 11m 3 190µ- -40 to 125°C 2.25k SPI X, Y Inclinometer $24.76
44ADIS16006 5 g 1.4m 3 200µ- -40 to 125°C 2.25k SPI X, Y- $22.94
45ADIS16003 1.7 g 1.4m 3 110µ- -40 to 125°C 2.25k SPI X, Y- $18.50
46ADXL213 1.2 g 700µ 3 160µ 250µ -40 to 85°C 2.5k PWM X, Y- $13.45
47ADXL203Reference Circuit Available 1.7 g 700µ 3 110µ 100µ -40 to 125°C 2.5k Analog X, Y- $13.45
48ADXL103 1.7 g 700µ 3 110µ 100µ -40 to 125°C 2.5k Analog X- $11.19
49ADXL78 70 g 1.3m 4.75 1.8m- -40 to 105°C 400 Analog X- $5.75
50ADXL278 70 g 2.2m 4.75 1.8m 100m -40 to 105°C 400 Analog X, Y- $8.08
51ADXL193 250 g 1.5m 4.75 5m 100m -40 to 125°C 400 Analog X- $6.88
