ADXL380
Low Noise, Low Power, Wide Bandwidth, 3-Axis MEMS Accelerometer
Show More
Not the part you were looking for?
Ask a Question
Submit your question below and we will return the best answer from ADI’s knowledge database:
Other places you can find help
Support
Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.
Visit the ADI Support PageFeatures
- Ultralow noise density: 20 μg/√Hz (XY), 27 μg/√Hz (Z)
- Low power consumption
- High performance: 340 μA
- Ultra low power: 33 μA
- Wide bandwidth: 4 kHz
- Relative flatness with equalization: <0.5 dB
- Relative flatness without equalization: <2 dB
- Low latency: group delay <110 μs
- Digital features
- 16-bit ADC
- Multiprotocol serial interfaces: SPI or I2C
- Multiprotocol audio data output: I2S, TDM, and PDM
- Programmable LPF and HPF
- Data synchronous or asynchronous sampling
- Output FIFO: 320 word
- Built-in features for system-level power savings
- Single tap, double tap, and triple tap detection
- Activity and inactivity detection
- Configurable interrupt modes
- Integrated temperature sensor
- Voltage range options
- VS with internal regulators: 2.25 V to 3.6 V (or V1P8 at 1.8 V)
- VDDIO: 1.14 V to 3.6 V (1.62 V to 3.6 V for full temperaturerange)
- Electromechanical self test
- 10,000 g mechanical shock survival
- RoHS compliant
- Operating temperature range: −40°C to +85°C
- 14-terminal, 2.9 mm × 2.8 mm × 0.87 mm, LGA package
The ADXL380 is a low noise density, low power, 3-axis accelerometer with selectable measurement ranges. The ADXL380 supports the ±4 g, ±8 g, and ±16 g ranges.
The ADXL380 offers industry leading noise, enabling precision applications with minimal calibration. The low noise and low power ADXL380 enables accurate measurements of audio signals or heart sounds even in high vibration environments.
The ADXL380 multifunction pin names may be referenced only by their relevant function for either the serial peripheral interface (SPI) or inter-IC(I2C) interface, or these pin names can be referenced by their audio function (pulse density modulation (PDM), inter-IC sound (I2S), or time division multiplexing (TDM)).
In addition to its low power consumption, the ADXL380 has many features to enable true system level performance. These features include a built-in micropower temperature sensor, singletap, double tap, and triple tap detection, and a state machine to prevent false triggering. In addition, the ADXL380 has provisions for external control of the sampling time and/or an external clock.
The ADXL380 operates on a wide, 2.25 V to 3.6 V supply range (or 1.8 V supply) and can interface, if necessary, to a host operating on a separate supply voltage. The ADXL380 is available in a 14-terminal, 2.9 mm × 2.8 mm × 0.87 mm, LGA package.
APPLICATIONS
- Audio and active noise cancellation (ANC)
- Robotics
- Wearables and low power motion detection
- Seismic imaging
- Condition-based monitoring
Ask a Question
Submit your question below and we will return the best answer from ADI’s knowledge database:
Other places you can find help
Support
Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.
Visit the ADI Support Page{{modalTitle}}
{{modalDescription}}
{{dropdownTitle}}
- {{defaultSelectedText}} {{#each projectNames}}
- {{name}} {{/each}} {{#if newProjectText}}
- {{newProjectText}} {{/if}}
{{newProjectTitle}}
{{projectNameErrorText}}
ADXL380
Documentation
Filters
1 Applied
Data Sheet
1
User Guide
1
Documentation
Device Drivers 3
Webcast 1
Video
1
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.
Part Model | Pin/Package Drawing | Documentation | CAD Symbols, Footprints, and 3D Models |
---|---|---|---|
ADXL380-1BCCZ-RL | 14-Lead LGA (2.9 mm x 2.8 mm x 0.87 mm) |
|
|
ADXL380-1BCCZ-RL7 | 14-Lead LGA (2.9 mm x 2.8 mm x 0.87 mm) |
|
|
ADXL380-2BCCZ-RL | 14-Lead LGA (2.9 mm x 2.8 mm x 0.87 mm) |
|
|
ADXL380-2BCCZ-RL7 | 14-Lead LGA (2.9 mm x 2.8 mm x 0.87 mm) |
|
- ADXL380-1BCCZ-RL
- Pin/Package Drawing
- 14-Lead LGA (2.9 mm x 2.8 mm x 0.87 mm)
- Documentation
- HTML Material Declaration
- HTML Reliablity Data
- CAD Symbols, Footprints, and 3D Models
- Ultra Librarian
- SamacSys
- ADXL380-1BCCZ-RL7
- Pin/Package Drawing
- 14-Lead LGA (2.9 mm x 2.8 mm x 0.87 mm)
- Documentation
- HTML Material Declaration
- HTML Reliablity Data
- CAD Symbols, Footprints, and 3D Models
- Ultra Librarian
- SamacSys
- ADXL380-2BCCZ-RL
- Pin/Package Drawing
- 14-Lead LGA (2.9 mm x 2.8 mm x 0.87 mm)
- Documentation
- HTML Material Declaration
- HTML Reliablity Data
- CAD Symbols, Footprints, and 3D Models
- Ultra Librarian
- SamacSys
- ADXL380-2BCCZ-RL7
- Pin/Package Drawing
- 14-Lead LGA (2.9 mm x 2.8 mm x 0.87 mm)
- Documentation
- HTML Material Declaration
- HTML Reliablity Data
- CAD Symbols, Footprints, and 3D Models
- Ultra Librarian
- SamacSys
Software & Part Ecosystem
Device Drivers
Looking for Evaluation Software? You can find it here
Parts | Product Life Cycle | Description |
---|---|---|
RECOMMENDED FOR NEW DESIGNS |
Low-Noise, Low-Drift, Low-Power, 3-Axis MEMS Accelerometers |
|
RECOMMENDED FOR NEW DESIGNS |
Low Noise, Low Drift, Low Power, 3-Axis MEMS Accelerometers with Digital Output |
Can't find the software or driver you need?
Request a Driver/SoftwareEvaluation Kits 2
EVAL-ADIS-MCBZ
EVAL-ADIS-MCBZ User Guide
Product Detail
This user guide provides an overview of using the EVAL-ADISMCBZ, including instructions for the motion capture board (MCB) hardware setup and software functions. The EVAL-ADIS-MCBZ supports a wide array of Analog Devices, Inc., sensor families (ADXL, ADIS, and ADXRS). It easily communicates with sensors and captures data by connecting the hardware to a PC and running the evaluation software. The graphical user interface (UI) of the software allows plotting and storing sensor data for postcapture analysis.
Resources
EVAL-ADXL380
Evaluating the ADXL380 Low Noise, Low Power, Wide Bandwidth, 3-Axis MEMS Accelerometer
Product Detail
This user guide provides an overview of using the EVAL-ADXL380- BB-1Z (breakout board for the SPI variant of the ADXL380), EVALADXL380- BB-2Z (breakboard for the I2C variant of the ADXL380), EVAL-ADXL380-EB-1Z (evaluation board for the SPI variant of the ADXL380), and EVAL-ADXL380-EB-2Z (evaluation board for the I2C variant of the ADXL380) as a PC-based solution for evaluating the ADXL380 microelectromechanical systems (MEMS) accelerometer. These evaluation boards use the motion capture board (MCB) from the EVAL-ADIS-MCBZ platform for an easy communication and data collection using the graphical user interface (GUI). Go to the EVAL-ADIS-CBZ web page to download the software and its user guide, which details the installation process and the software features. This user guide gives an overview of using the ADXL380 evaluation boards available, detailing their functionality with provided examples where relevant.
Figure 1 shows the required hardware components for the ADXL380 evaluation system. The EVAL-ADIS-MCBZ is the controller board that provides a means of communication with the EVALADXL380- BB-1Z, EVAL-ADXL380-BB-2Z, EVAL-ADXL380-EB-1Z, or EVAL-ADXL380-EB-2Z evaluation board from the PC.
For full details on the ADXL380, see the ADXL380 data sheet, which should be consulted in conjunction with this user guide when using the EVAL-ADXL380-BB-1Z, EVAL-ADXL380-BB-2Z, EVALADXL380- EB-1Z, or EVAL-ADXL380-EB-2Z evaluation board.
