ADV7521NK
最終販売Low-Power HDMI®/DVI Transmitter with Consumer Electronic Control (CEC)
- 製品モデル
- 1
- 1Ku当たりの価格
- 価格は未定
製品の詳細
- General
Low-power HDMI™/DVI transmitter ideal for portable applications
CEC controller and buffer reduces system overhead
Compatible with HDMI v1.3
(supporting x.v.Color™), DVI v1.0
Single 1.8V power supply - Digital video
80 MHz operation supports all video resolutions from 480i to 1080i
Prog two-way CSC
Supports RGB, YCbCr, DDR
Supports ITU656 based embedded syncs
Auto input video format timing detection
(CEA-861D)
- Digital audio
Supports standard S/PDIF for stereo LPCM or compressed audio up to 192 kHz
2-channel uncompressed LPCM I2S audio up to 192 kHz - Special features for easy system design
On-chip MPU w/ I2C® master performs EDID reading operations
5 V tolerant I2C & HPD I/Os-no extra device needed
No audio master clock needed to support S/PDIF & I2S
The ADV7521NK is an 80 MHz, high definition multimedia interface (HDMI®) v.1.3 transmitter. It supports HDTV formats up to 1080i and 720p, and computer graphic resolutions up to XGA (1024 × 768 @ 75 Hz).
The ADV7521NK supports both S/PDIF and 2-channel I2S audio. Its high fidelity 2-channel I2S can transmit stereo at up to 192 kHz sampling rate. The S/PDIF can carry stereo LPCM audio or compressed audio including Dolby® Digital and DTS®.
The ADV7521NK helps to reduce system design complexity and cost by incorporating such features as an I2C master for EDID reading, a single 1.8V power supply and 5 V tolerance on I2C and hot plug detect pins.
Fabricated in an advanced CMOS process, the ADV7521NK is available in a space saving, 49-ball, WLCSP surface-mount package. This package is RoHS compliant and specified to operate from −25°C to +85°C.
APPLICATIONS
- Digital video cameras
- Digital still cameras
- Personal media players
- Cellular handsets
ドキュメント
アプリケーション・ノート 1
技術記事 1
ビデオ 1
| 製品モデル | ピン／パッケージ図 | 資料 | CADシンボル、フットプリント、および3Dモデル |
|---|---|---|---|
| ADV7521NKBCBZRL-80 | 49 ball WLCSP (3.45x3.45mm) |
| 製品モデル | 製品ライフサイクル | PCN |
|---|---|---|
|
8 9, 2024 - 24_0030 Obsolescence of ADV7521NKBCBZRL-80 |
||
| ADV7521NKBCBZRL-80 | 最終販売 | |
ハードウェア・エコシステム
評価用キット
ADV7521NK Evaluation Board
