Embedded PA Characterization in DPD Setup

Jul 5 2023

Witness non-linear PA characterization with ADI’s ADRV9040 transceiver. This includes S-parameters, CW, two-tones, and modulated signal power sweep tests to help customers extract and correlate the PA characteristics to DPD performance and measure the DPD metrics.

In this demo we’ll be using the New 600MHz Hybrid LDMOS/GaN PAM from NXP to also demonstrate our ADI’s ADRV9040 DPD capability to up to 400MHz+ iBW!
