MAX40018
Dual nanoPower Op Amps in Tiny WLP and TDFN Packages
Saves Power and Board Space in Mobile Devices — Op Amp Consumes Only 350nA per Amplifier
Top
Overview
Features and Benefits
- Ultra-Low Power Preserves Battery Life
- 400nA Typical Supply Current (Per Channel)
- Single 1.7V to 5.5V Supply Voltage Range
- The Device Can be Powered From the Same 1.8V/2.5V/3.3V/5V System Rails
- Tiny Packages Save Board Space
- 1.63mm x 0.91mm x 0.5mm WLP-8 with 0.4mm Bump Pitch
- 3mm x 3mm x 0.75mm TDFN-8 Package
- Precision Specifications for Buffer/Filter/Gain Stages
- Low 350μV Input Offset Voltage
- Rail-to-Rail Output Voltage
- 9kHz GBP
- Low 0.1pA Input Bias Current
- Unity-Gain Stable
- -40°C to +125°C Temperature Range
Product Details
The MAX40018 is a dual operational amplifier that consumes only 400nA supply current (per channel). At such low power consumption, the device is ideal for battery-powered applications such as portable medical equipment, portable instruments and wireless handsets.
The MAX40018 operates from a single 1.7V to 5.5V supply, allowing the device to be powered by the same 1.8V, 2.5V, or 3.3V nominal supply that powers the microcontroller. The MAX40018 features rail-to-rail outputs and is unity-gain stable with a 9kHz gain bandwidth product (GBP).
The ultra-low supply current, ultra-low input bias current, low operating voltage, and rail-to-rail output capabilities make this dual operational amplifier ideal for use with single lithium-ion (Li+), or two-cell NiCd or alkaline batteries.
The MAX40018 is available in a tiny, 8-bump, 1.63mm x 0.91mm wafer-level package (WLP), with a bump pitch of 0.4mm, as well as in an 8-pin 3mm x 3mm TDFN package. The device is specified over the -40°C to +125°C, automotive temperature range.
Applications
- Handheld Devices
- Notebook and Tablet Computers
- Portable Instrumentation
- Portable Medical Devices
- Wearable Devices
