LT3970 Series

Name: LT3970
Brand: Analog Devices
Price: 3.57 USD
Availability: InStock

RECOMMENDED FOR NEW DESIGNS

40V, 350mA Step-Down Regulator with 2.5μA Quiescent Current and Integrated Diodes

Data Sheet (Rev. D) Product Selection Table

Part Models: 50
1ku List Price: Starting From $3.57

Viewing:

Overview

Low Ripple Burst Mode^® Operation
- 2.5µA I_Q at 12V_IN to 3.3V_OUT
- Output Ripple < 5mV_P-P
Wide Input Voltage Range: 4.2V to 40V Operating
Adjustable Switching Frequency: 200kHz to 2.2MHz
Integrated Boost and Catch Diodes
350mA Output Current
Fixed Output Voltages:
- 3.3V, 3.42V, 5V
- 1.8μA I_Q at 12V_IN

Accurate 1V Enable Pin Threshold
Low Shutdown Current: I_Q = 0.7μA
Internal Sense Limits Catch Diode Current
Power Good Flag
Output Voltage: 1.21V to 25V
Internal Compensation
Small 10-Pin MSOP and (3mm × 2mm) DFN Packages
AEC-Q100 Qualified for Automotive Applications

Part Models: 50
1ku List Price: Starting From $3.57

Documentation

Data Sheet 1

LT3970: 40V, 350mA Step-Down Regulator with 2.5μA Quiescent Current and Integrated Diodes Data Sheet (Rev.D) 09/18/2013

User Guide 1

DC1566A - Demo Manual 10/06/2009

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
LT3970EDDB#TRMPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EDDB#TRPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EDDB-3.3#TRMPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EDDB-3.3#TRPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EDDB-3.42#TRMPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EDDB-3.42#TRPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EDDB-5#TRMPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EDDB-5#TRPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EMS#PBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EMS#TRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EMS#WPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EMS#WTRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EMS-3.3#PBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EMS-3.3#TRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EMS-3.3#WPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EMS-3.3#WTRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EMS-5#PBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EMS-5#TRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EMS-5#WPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970EMS-5#WTRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970HMS#PBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970HMS#TRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970HMS#WPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970HMS#WTRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970HMS-3.3#PBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970HMS-3.3#TRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970HMS-3.3#WPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970HMS-3.3#WTRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970HMS-5#PBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970HMS-5#TRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970HMS-5#WPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970HMS-5#WTRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IDDB#TRMPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IDDB#TRPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IDDB-3.3#TRMPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IDDB-3.3#TRPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IDDB-5#TRMPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IDDB-5#TRPBF	10-Lead DFN (3mm x 2mm w/ EP)	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IMS#PBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IMS#TRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IMS#WPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IMS#WTRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IMS-3.3#PBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IMS-3.3#TRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IMS-3.3#WPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IMS-3.3#WTRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IMS-5#PBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IMS-5#TRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IMS-5#WPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
LT3970IMS-5#WTRPBF	10-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Apr 17, 2025 - 25_0043 Change of Gold to Copper Wire and BOM (Automotive)
		PCN25_0043_Form Material_Report
LT3970EDDB#TRMPBF	PRODUCTION
LT3970EDDB#TRPBF	PRODUCTION
LT3970EDDB-3.3#TRMPBF	PRODUCTION
LT3970EDDB-3.3#TRPBF	PRODUCTION
LT3970EDDB-3.42#TRMPBF	PRODUCTION
LT3970EDDB-3.42#TRPBF	PRODUCTION
LT3970EDDB-5#TRMPBF	PRODUCTION
LT3970EDDB-5#TRPBF	PRODUCTION
LT3970IDDB-5#TRMPBF	PRODUCTION
LT3970IDDB-5#TRPBF	PRODUCTION
Jun 5, 2024 - 24_0003 Epoxy Change from Henkel 8290 to 8290A for MSOP Package (2)
		PCN24_0003_Form Material_Report
LT3970EMS#PBF	PRODUCTION
LT3970EMS#TRPBF	PRODUCTION
LT3970EMS#WPBF	PRODUCTION
LT3970EMS#WTRPBF	PRODUCTION
LT3970EMS-3.3#WPBF	PRODUCTION
LT3970EMS-3.3#WTRPBF	PRODUCTION
LT3970EMS-5#PBF	PRODUCTION
LT3970EMS-5#TRPBF	PRODUCTION
LT3970EMS-5#WPBF	PRODUCTION
LT3970EMS-5#WTRPBF	PRODUCTION
LT3970HMS#WPBF	PRODUCTION
LT3970HMS#WTRPBF	PRODUCTION
LT3970HMS-3.3#PBF	PRODUCTION
LT3970HMS-3.3#TRPBF	PRODUCTION
LT3970HMS-3.3#WPBF	PRODUCTION
LT3970HMS-3.3#WTRPBF	PRODUCTION
LT3970HMS-5#PBF	PRODUCTION
LT3970HMS-5#TRPBF	PRODUCTION
LT3970HMS-5#WPBF	PRODUCTION
LT3970HMS-5#WTRPBF	PRODUCTION
LT3970IMS#WPBF	PRODUCTION
LT3970IMS#WTRPBF	PRODUCTION
LT3970IMS-3.3#WPBF	PRODUCTION
LT3970IMS-3.3#WTRPBF	PRODUCTION
LT3970IMS-5#WPBF	PRODUCTION
LT3970IMS-5#WTRPBF	PRODUCTION
Feb 4, 2020 - 20_0130 Laser Top Mark Conversion for 10-Lead MSOP Packages Assembled in ADPG and UTAC
		PCN20_0130_Form Material_Report
LT3970EMS#PBF	PRODUCTION
LT3970EMS#TRPBF	PRODUCTION
LT3970EMS#WPBF	PRODUCTION
LT3970EMS#WTRPBF	PRODUCTION
LT3970EMS-3.3#PBF	PRODUCTION
LT3970EMS-3.3#TRPBF	PRODUCTION
LT3970EMS-3.3#WPBF	PRODUCTION
LT3970EMS-3.3#WTRPBF	PRODUCTION
LT3970EMS-5#PBF	PRODUCTION
LT3970EMS-5#TRPBF	PRODUCTION
LT3970EMS-5#WPBF	PRODUCTION
LT3970EMS-5#WTRPBF	PRODUCTION
LT3970HMS#PBF	PRODUCTION
LT3970HMS#TRPBF	PRODUCTION
LT3970HMS#WPBF	PRODUCTION
LT3970HMS#WTRPBF	PRODUCTION
LT3970HMS-3.3#PBF	PRODUCTION
LT3970HMS-3.3#TRPBF	PRODUCTION
LT3970HMS-3.3#WPBF	PRODUCTION
LT3970HMS-3.3#WTRPBF	PRODUCTION
LT3970HMS-5#PBF	PRODUCTION
LT3970HMS-5#TRPBF	PRODUCTION
LT3970HMS-5#WPBF	PRODUCTION
LT3970HMS-5#WTRPBF	PRODUCTION
LT3970IMS#PBF	PRODUCTION
LT3970IMS#TRPBF	PRODUCTION
LT3970IMS#WPBF	PRODUCTION
LT3970IMS#WTRPBF	PRODUCTION
LT3970IMS-3.3#PBF	PRODUCTION
LT3970IMS-3.3#TRPBF	PRODUCTION
LT3970IMS-3.3#WPBF	PRODUCTION
LT3970IMS-3.3#WTRPBF	PRODUCTION
LT3970IMS-5#PBF	PRODUCTION
LT3970IMS-5#TRPBF	PRODUCTION
LT3970IMS-5#WPBF	PRODUCTION
LT3970IMS-5#WTRPBF	PRODUCTION
Oct 11, 2022 - 22_0244 Epoxy Change from Henkel 8290 to 8290A for MSOP Package
		PCN22_0244_Form Material_Report
LT3970EMS#WPBF	PRODUCTION
LT3970EMS#WTRPBF	PRODUCTION
LT3970EMS-3.3#PBF	PRODUCTION
LT3970EMS-3.3#TRPBF	PRODUCTION
LT3970EMS-3.3#WPBF	PRODUCTION
LT3970EMS-3.3#WTRPBF	PRODUCTION
LT3970HMS#PBF	PRODUCTION
LT3970HMS#TRPBF	PRODUCTION
LT3970HMS#WPBF	PRODUCTION
LT3970HMS#WTRPBF	PRODUCTION
LT3970HMS-3.3#WPBF	PRODUCTION
LT3970HMS-3.3#WTRPBF	PRODUCTION
LT3970IMS#PBF	PRODUCTION
LT3970IMS#TRPBF	PRODUCTION
LT3970IMS#WPBF	PRODUCTION
LT3970IMS#WTRPBF	PRODUCTION
LT3970IMS-3.3#PBF	PRODUCTION
LT3970IMS-3.3#TRPBF	PRODUCTION
LT3970IMS-3.3#WPBF	PRODUCTION
LT3970IMS-3.3#WTRPBF	PRODUCTION
LT3970IMS-5#PBF	PRODUCTION
LT3970IMS-5#TRPBF	PRODUCTION
Apr 18, 2022 - 22_0050 UTAC Thai Limited (UTL) as Alternate Assembly Site for MSOP Packages / Devices
		PCN22_0050_Form Material_Report
LT3970EMS#WPBF	PRODUCTION
LT3970EMS#WTRPBF	PRODUCTION
LT3970EMS-3.3#PBF	PRODUCTION
LT3970EMS-3.3#TRPBF	PRODUCTION
LT3970EMS-3.3#WPBF	PRODUCTION
LT3970EMS-3.3#WTRPBF	PRODUCTION
LT3970EMS-5#WPBF	PRODUCTION
LT3970EMS-5#WTRPBF	PRODUCTION
LT3970HMS#PBF	PRODUCTION
LT3970HMS#TRPBF	PRODUCTION
LT3970HMS#WPBF	PRODUCTION
LT3970HMS#WTRPBF	PRODUCTION
LT3970HMS-3.3#WPBF	PRODUCTION
LT3970HMS-3.3#WTRPBF	PRODUCTION
LT3970HMS-5#WPBF	PRODUCTION
LT3970HMS-5#WTRPBF	PRODUCTION
LT3970IMS#PBF	PRODUCTION
LT3970IMS#TRPBF	PRODUCTION
LT3970IMS#WPBF	PRODUCTION
LT3970IMS#WTRPBF	PRODUCTION
LT3970IMS-3.3#PBF	PRODUCTION
LT3970IMS-3.3#TRPBF	PRODUCTION
LT3970IMS-3.3#WPBF	PRODUCTION
LT3970IMS-3.3#WTRPBF	PRODUCTION
LT3970IMS-5#PBF	PRODUCTION
LT3970IMS-5#TRPBF	PRODUCTION
LT3970IMS-5#WPBF	PRODUCTION
LT3970IMS-5#WTRPBF	PRODUCTION
Apr 17, 2025 - 25_0119 Bond Wire Change from Gold to Copper (Automotive)
		PCN25_0119_Form Material_Report
LT3970HMS-3.3#PBF	PRODUCTION
LT3970HMS-3.3#TRPBF	PRODUCTION
LT3970HMS-5#PBF	PRODUCTION
LT3970HMS-5#TRPBF	PRODUCTION

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Hardware Ecosystem

Parts	Product Life Cycle	Description
Circuit Monitors 1
LTC2960	RECOMMENDED FOR NEW DESIGNS	36V Nano-Current Two-Input Voltage Monitor
Ideal Diodes and PowerPath Controllers 1
LTC4359	RECOMMENDED FOR NEW DESIGNS	Ideal Diode Controller with Reverse Input Protection
Overvoltage & Overcurrent Protectors 1
LTC4365	RECOMMENDED FOR NEW DESIGNS	Overvoltage, Undervoltage and Reverse Supply Protection Controller
Power System Management (PSM) & Sequencers 1
LTC2974	RECOMMENDED FOR NEW DESIGNS	4-Channel PMBus Power System Manager Featuring Accurate Output Current Measurement

Tools & Simulations

LTspice 1

LT3970 Demo Circuit - 40V, 350mA Step-Down Regulator with 2.5µA Iq & Integrated Diodes (12V to 5V @ 0.35A)

Models for the following parts are available in LTspice:

LT3970
LT3970-3.3
LT3970-5

LTspice® is a powerful, fast and free simulation software, schematic capture and waveform viewer with enhancements and models for improving the simulation of analog circuits.

Evaluation Kits

LT3970EMS Demo Board | 40V, 350mA Step-Down Regulator with 2uA Quiescent Current and Integrated Diodes

Buy Now View Details

Product Details

Demonstration circuit 1566 is a monolithic stepdown DC/DC switching regulator featuring the LT3970. The switching frequency is adjustable up to 2MHz. The demo circuit is designed for 5V, 350mA output from a 6V to 40V input. The wide input range of the LT3970 allows a variety of input sources including automotive batteries and 24V industrial supplies. Low ripple Burst Mode increases the efficiency at the light load while keeping the output ripple below 15mV. The part is in shutdown when the EN pin is low and active when the pin is high. The threshold of the EN pin is accurate at 1V when Vin is above 4.2V. Adding a resistor divider from Vin to EN can program the LT3970 to regulate the
output only when Vin is above a desired voltage. The catch diode and boost diode are integrated to reduce the components count and solution size. The circuit consumes only 2μA of quiescent current. The current mode control scheme creates fast transient response and good loop stability. The catch diode current is limited to protect the part under short circuit and overvoltage conditions.
