Features and Benefits
- 2 Blackfin cores capable of 500 MHz/1000 MMACs (2000 MMACs total) for demanding signal processing applications.
- 552 K bytes of on-chip SRAM composed of 148kB of L1 SRAM per core with parity support and a shared L2 256kB SRAM with ECC support.
- Pipeline Vision Processor (PVP) with HD support.
- Pixel Compositor.
- Fully integrated DMA controller supporting DMA transfers to and from all on-chip and off-chip memories and peripherals.
- 3x Enhanced Parallel Peripheral Interfaces (ePPIs) supporting up to 24-bit data widths, ITU-R BT.656 modes, and direct connection to TFT LCD panels, parallel converters, video encoders and decoders, image sensors, and other general-purpose peripherals.
- USB 2.0 HS OTG.
- Removable Storage Interface (RSI).
- 2 10/100 Ethernet MACs with IEEE 1588 support.
- Controller Area Network (CAN) Interface.
- 4 Link Ports supporting 8-bit wide DMA enabled data transfer.
- 2 Watch Dog Timers and 8 Timer/Counters with PWM support.
- CRC engine.
- 2 SPI-compatible ports supporting master and slave modes.
- 2 UART and 2 Two-Wire Interfaces.
- 2 16-bit Pulse Width Modulation (PWM) channels.
- 19x19 mm CSP BGA package.
- Commercial, Industrial, and automotive temperature ranges available.
- See data sheet for additional features
The ADSP-BF609 Blackfin processor is optimized for embedded vision and video analytics applications using a dual-core fixed-point DSP processor with a unique pipelined vision processor (PVP). The PVP is a set of functional blocks next to the Blackfin cores designed to accelerate image processing algorithms and reduce overall bandwidth requirements.
Other features include a high performance enhanced infrastructure, large on-chip memory and a feature rich peripheral set with expanded connectivity options. In addition to these the ADSP-BF609 processor contains features for safety-critical applications, including a CRC for memory protection, Parity and ECC protection in the internal memory blocks and a Fault Management Unit.
The ADSP-BF609 processor is ideal for many embedded vision applications such as automotive advanced driver assistance systems (ADAS), machine vision and robotics for industrial manufacturing systems, security and surveillance system analytics and bar code scanners.
Markets and Technologies
Product Lifecycle Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
Evaluation Kits (2)
The Analog Devices ICE-1000 and ICE-2000 emulators facilitate the creation, test, and debug of advanced applications on Analog Devices Processors and DSPs. Working in tandem with the CrossCore® Embedded Studio development environment, these emulators provide state-of-the-art support for all JTAG-compliant Analog Devices processors.
New debug feature added for the ICE-1000/ICE-2000:
- Coresight Serial Wire Debug (SWD)
Features & Benefits
- JTAG/SWD support for Blackfin, Blackfin+, SHARC and multi-core SHARC+ with ARM
- Plug-n-Play, USB 2.0 compliant
- USB bus-powered device
- Windows® 8.1, Window 7 compatible
- Multiple processor I/O voltage support: 1.8V, 2.5V, and 3.3V
- Multiprocessor support
- JTAG/SWD clock operation of 5 MHz on the ICE-1000
- JTAG/SWD clock operation up to 46 MHZ on the ICE-2000
- Multi-colored LED for enhanced status indication
- Software controlled target reset to support remote debug
The ADSP-BF609 Evaluation Hardware provides a low cost hardware solution for users to evaluate the Analog Devices dual core Blackfin processor, 500 MHz/1000 MMACs each (2000 MMACs total) ADSP-BF60x Blackfin® processor family. This hardware comes in two configurations; ADSP-BF609 EZ-Board™ and ADSP-BF609 EZ-KIT Lite®.
ADSP-BF609 EZ-Board - The EZ-Board concept is the lowest cost entry point to evaluate the ADSP-BF60x processors family. This offering assumes that the customer already has an ICE -100B, USB-ICE and/or HPUSB-ICE JTAG Emulator(s). CrossCore® Embedded Studio software is also required.
ADSP-BF609 EZ-KIT Lite - The EZ-KIT Lite includes the complete ADSP-BF609 EZ-Board product plus SADA2 that eliminates the need to purchase a separate JTAG emulator for evaluation purposes.
Other emulators supported by the ADSP-BF60x Evaluation Hardware include the ICE -100B, USB-ICE and HPUSB-ICE
CROSSCORE® Tools Support:
Tel: 1-800-ANALOGD (262-5643)
Features & Benefits
- ADSP-BF609 Blackfin processor
- ADM708 voltage monitoring microprocessor supervisory circuit
- ADM3315 serial port transceiver
- ADP1864 constant frequency current-mode step-down dc-to-dc controller
- ADP1715 low-dropout cmos linear regulator with soft start
- ADP2119A synchronous step-down dc-to-dc regulator
- On-processor memory: 64Mx16 bit (1Gbit) DDR2 memory, 16M x 16-bit Burst flash memory, 32Mbit Quad SPI flash memory.
- Interfaces: 10/100 Ethernet PHY, UART, CAN, USB Debug Agent Interface, Expansion Interface III, Standalone Debug Agent 2 (SADA2).
- Accessories: 2GB SD CARD, Ethernet Cable, 5-in-1 USB Cable Set, Power Supply
Documentation & Resources
EE-360: Utilizing the Trigger Routing Unit for System Level Synchronization (Rev. 1)2/14/2015
EE-364: Implementing Second-Stage Loaders for ADSP-BF60x Blackfin® Processors (Rev. 1)11/18/2014
EE-362: ADSP-BF60x Blackfin® Processors System Optimization Techniques (Rev. 1)11/13/2013
EE-358: Interfacing Red/Clear Sensors to ADSP-BF609® Blackfin Processors (Rev. 1)5/27/2013
EE-354: UART Enhancements on ADSP-BF60x Blackfin® Processors (Rev. 1)8/20/2012
EE-335: Interfacing SD Cards with Blackfin Processors (Rev. 1)3/4/2010
EE-339: Using External Switching Regulators with Blackfin® Processors (Rev. 1)8/18/2009
EE-326: Blackfin® Processor and SDRAM Technology (Rev. 2)8/18/2009
EE-281: Hardware Design Checklist for the Blackfin® Processors (Rev. 2)7/7/2008
EE-185: Fast Floating-Point Arithmetic Emulation on Blackfin® Processors (Rev. 4)8/28/2007
EE-175: Emulator and Evaluation Hardware Troubleshooting Guide for VisualDSP++ Users (Rev. 14)5/21/2007
EE-269: A Beginner’s Guide to Ethernet 802.3 (Rev. 1)6/7/2005
EE-261: Understanding Jitter Requirements of PLL-Based Processors (Rev. 1)2/15/2005
EE-183: Rational Sample Rate Conversion with Blackfin® Processors (Rev. 5)10/30/2003
Probing EI3 Extender Board Manual (Rev. 1.0)9/11/2012
Video Decoder EI3 Extender Board Manual (Rev. 1.1)6/7/2012
Video Encoder EI3 Extender Board Manual (Rev. 1.1)5/30/2012
ADSP-BF609 EZ-KIT Lite® Evaluation System Manual (Rev. 1.1)3/24/2012
Blackfin®/SHARC® USB EZ-Extender® Manual (Rev. 1.1)5/7/2009
Bluetechnix BF609 System-on-Module and 3D Sensor Demo11/28/2018
Introducing the ADSP-BF609 Blackfin® Processor Series11/28/2018
Blackfin® ADSP-BF609 Embedded Vision System11/28/2018
Introducing the Blackfin ADSP-BF60x Processors11/28/2018
Blackfin Processors Optimized for Embedded Vision11/28/2018
FPGA-Based System Combines Two Video Streams to Provide 3D Video12/1/2013 Analog Dialogue
