ADSP-BF527C
Low Power Blackfin Processor with Advanced Peripherals and Embedded Stereo Audio CODEC
Show More
Not the part you were looking for?
3
223 kBB
IBIS Model
ADSP-BF523/BF525/BF527 Rev 0.2 1.8/2.5/3.3 V I/O Blackfin Processor IBIS Datafile 17x17 208-Ball CSP BGA Package (02/2009)
110 kBB
BSDL Model File
ADSP-BF523C/BF525C/BF527C Blackfin Processor BSDL File 289-Ball CSP BGA Package (05/2009)
18 kBB
Ask a Question
Submit your question below and we will return the best answer from ADI’s knowledge database:
Search
Other places you can find help
Support
Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.
Visit the ADI Support Page
Features
- Lockbox™ Secure Technology: Hardware-enabled security for code and content protection.
- Blackfin Processor Core with up to 600 MHz (1200 MMACS) performance
- 2 dual-channel, full-duplex synchronous serial ports supporting 8 stereo I2S channels
- 12 peripheral DMA channels supporting one- and two-dimensional data transfers
- NAND Flash Controller with 8-Bit interface for commands, addresses and data.
- Connectivity: HS USB OTG, Host DMA Port, UART’s, SPORT’s, SPI and TWI.
- Ethernet 10/100 MII interface
- Memory controller providing glue-less connection to multiple banks of external SDRAM, SRAM, Flash, or ROM
- 289-ball, 12x12 mm, 0.5 mm pitch mini-BGA (Commercial temperature range 0°C to +70°C)
- Supports an embedded low power stereo CODEC for space constrained audio applications
.svg?rev=fd385c90e2cf4716ae9a8c8d20e6b8e3&la=en&h=24&w=24&hash=A302DF48F94BAAA11877AF223F27157A){kind=icon}
The high performance 16/32-bit Blackfin embedded processor core, the flexible cache architecture, the enhanced DMA subsystem, and the dynamic power management (DPM) functionality allow system designers a flexible platform to address a wide range of portable applications, including consumer, communications and industrial/instrumentation.
With the combination of peripherals which enable glue-less connectivity to networked devices such as Ethernet or WiFi 802.11 a/b/g modules and power efficient signal processing, the ADSP-BF527C is well suited to IP connected applications such as VoIP Phone or IP Camera.
The VoIP challenge to the embedded-system designer is to choose a processing solution that is cost-effective, easy to deploy and scaleable in performance across market spaces. A “sweet spot” embedded-solution approach is to design with a platform that can implement a low channel count basic VoIP solution, yet retain sufficient capacity for value added capabilities and services – such as video, music, imaging and system control. Unlike traditional VoIP embedded solutions that utilize two processor cores to provide VoIP functionality, the ADSP-BF527C provides a convergent solution in a unified core architecture that allows voice and video signal processing concurrent with RISC MCU processing to handle network and user-interface demands. This unique ability to offer full VoIP functionality on a single convergent processor provides for a unified software development environment, faster system debugging and deployment, and lower overall system cost.
IP protection has become a necessary part of today’s embedded computing applications. The ADSP-BF527C provides a security scheme which balances flexibility and upgradeability with performance through the inclusion of a firmware-based solution including OTP (One Time Programmable) memory to enable users to implement private keys for secure access to program code.
For space constrained audio applications the ADSP-BF527C supports an embedded low power stereo audio CODEC.
3
223 kBB
IBIS Model
ADSP-BF523/BF525/BF527 Rev 0.2 1.8/2.5/3.3 V I/O Blackfin Processor IBIS Datafile 17x17 208-Ball CSP BGA Package (02/2009)
110 kBB
BSDL Model File
ADSP-BF523C/BF525C/BF527C Blackfin Processor BSDL File 289-Ball CSP BGA Package (05/2009)
18 kBB
Ask a Question
Submit your question below and we will return the best answer from ADI’s knowledge database:
Search
Other places you can find help
Support
Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.
Visit the ADI Support Page
{{modalTitle}}
{{modalDescription}}
{{dropdownTitle}}
- {{defaultSelectedText}} {{#each projectNames}}
- {{name}} {{/each}} {{#if newProjectText}}
-
{{newProjectText}}
{{/if}}
{{newProjectTitle}}
{{projectNameErrorText}}
ADSP-BF527C
Documentation
Filters
1 Applied
-
All
-
Application Note
-
Data Sheet
-
Integrated Circuit Anomaly
-
Processor Manual
-
Emulator Manual
-
Informational
-
Product Highlight
-
User Guide
-
Software Manual
-
Technical Articles
-
All
-
English
-
Chinese
-
Japanese
Data Sheet
2
ADSP-BF522C/ADSP-BF523C/ADSP-BF524C/ADSP-BF525C/ADSP-BF526C/ADSP-BF527C Blackfin Embedded Processor Data Sheet (Rev.A)
Application Note
65
306 kB
Integrated Circuit Anomaly
1
Processor Manual
3
HTML
Emulator Manual
6
Informational
2
HTML
HTML
Product Highlight
3
2098 kB
User Guide
4
Software Manual
11
Technical Articles
1
HTML
Documentation
Data Sheet 1
User Guide 2
Application Note 46
EE-257: A Boot Compression/Decompression Algorithm for Blackfin® Processors (Rev.1)
EE-269: A Beginner’s Guide to Ethernet 802.3 (Rev.1)
EE-110: A Quick Primer on ELF and DWARF File Formats
EE-271: Using Cache Memory on Blackfin® Processors (Rev.2)
EE-294: Energy-Aware Programming on Blackfin Processors (Rev.1)
EE-128: DSP in C++: Calling Assembly Class Member Functions From C++
EE-347: Formatted Print to a UART Terminal with Blackfin® Processors (Rev.3)
EE-185: Fast Floating-Point Arithmetic Emulation on Blackfin® Processors (Rev.4)
EE-175: Emulator and Evaluation Hardware Troubleshooting Guide for VisualDSP++ Users (Rev.14)
EE-281: Hardware Design Checklist for the Blackfin® Processors (Rev.2)
EE-311: VisualDSP++® Flash Programmer API for Blackfin® Processors (Rev.1)
EE-330: Windows Vista Compatibility in VisualDSP++ 5.0 Development Tools (Rev.1)
EE-344: Using the NAND Flash Controller on Blackfin Processors (Rev.1)
EE-301: Video Templates for Developing Multimedia Applications on Blackfin® Processors (Rev.1)
EE-334: Using Blackfin® Processor Hibernate State for Low Standby Power (Rev.1)
EE-261: Understanding Jitter Requirements of PLL-Based Processors (Rev.1)
EE-324: System Optimization Techniques for Blackfin® Processors (Rev.1)
EE-303: Using VisualDSP++® Thread-Safe Libraries with a Third-Party RTOS (Rev.1)
EE-192: Using C To Create Interrupt-Driven Systems On Blackfin® Processors
EE-149: Tuning C Source Code for the Blackfin® Processor Compiler
EE-276: Video Framework Considerations for Image Processing on Blackfin® Processors (Rev.1)
EE-304: Using the Blackfin® Processor SPORT to Emulate a SPI Interface (Rev.1)
EE-339: Using External Switching Regulators with Blackfin® Processors (Rev.1)
EE-309: Power Mode Transition Times of Blackfin® Processors (Rev.1)
EE-350: Seamlessly Interfacing MEMS Microphones with Blackfin Processors (Rev.1)
EE-104: Setting Up Streams with the VisualDSP Debugger
EE-236: Real-Time Solutions Using Mixed-Signal Front-End Devices with the Blackfin® Processor (Rev.1)
EE-183: Rational Sample Rate Conversion with Blackfin® Processors (Rev.5)
EE-306: PGO Linker - A Code Layout Tool for Blackfin Processors (Rev.1)
EE-234: Interfacing T1/E1 Transceivers/Framers to Blackfin® Processors via the Serial Port (Rev.1)
EE-337: Host DMA Port on ADSP-BF52x and ADSP-BF54x Blackfin® Processors (Rev.1)
EE-325: Interfacing Atmel Fingerprint Sensor AT77C104B with Blackfin® Processors (Rev.1)
EE-302: Interfacing ADSP-BF53x Blackfin® Processors to NAND FLASH Memory (Rev.1)
EE-323: Implementing Dynamically Loaded Software Modules (Rev.1)
EE-333: Interfacing Blackfin® Processors to Winbond W25X16 SPI Flash Devices (Rev.1)
EE-335: Interfacing SD Cards with Blackfin Processors (Rev.1)
EE-213: Host Communication via the Asynchronous Memory Interface for Blackfin® Processors (Rev.2)
EE-307: Blackfin® Processor Troubleshooting Tips Using VisualDSP++® Tools (Rev.1)
EE-235: An Introduction to Scripting in VisualDSP++® (Rev.1)
EE-197: ADSP-BF531/532/533 Blackfin® Processor Multi-cycle Instructions and Latencies
EE-68: Analog Devices JTAG Emulation Technical Reference (Rev.10)
EE-112: Class Implementation in Analog C++
EE-326: Blackfin® Processor and SDRAM Technology (Rev.2)
EE-312: Building Complex VDK/LwIP Applications Using Blackfin® Processors (Rev.2)
EE-204: Blackfin® Processor SCCB Software Interface for Configuring I2C® Slave Devices (Rev.2)
EE-340: Connecting SHARC® and Blackfin® Processors over SPI (Rev.1)
Technical Articles 1
Processor Manual 3
Product Highlight 2
Software Manual 11
VisualDSP++® 5.0 Users Guide (Rev.3.0)
VisualDSP++® 5.0 Quick Installation Reference Card (Rev.3.1)
VisualDSP++® 5.0 Licensing Guide (Rev.1.4)
VisualDSP++® 5.0 Device Drivers and System Services Manual for Blackfin Processors (Rev.4.3)
VisualDSP++® 5.0 C/C++ Compiler and Library Manual for Blackfin Processors (Rev.5.4)
VisualDSP++® 5.0 Loader and Utilities Manual (Rev.2.5)
VisualDSP++® 5.0 Product Release Bulletin (Rev.3.0)
VisualDSP++® 5.0 Assembler and Preprocessor Manual (Rev.3.4)
VisualDSP++® 5.0 Getting Started Guide (Rev.3.0)
VisualDSP++® 5.0 Kernel (VDK) Users Guide (Rev.3.5)
VisualDSP++® 5.0 Linker and Utilities Manual (Rev.3.5)
Emulator Manual 3
Integrated Circuit Anomaly 1
Informational 1
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.
| Part Model | Pin/Package Drawing | Documentation | CAD Symbols, Footprints, and 3D Models |
|---|---|---|---|
| ADSP-BF527KBCZ-5C2 |
289-Ball CSPBGA (12mm x 12mm x 1.26mm)
|
|
- ADSP-BF527KBCZ-5C2
- Pin/Package Drawing
-
289-Ball CSPBGA (12mm x 12mm x 1.26mm)
- Documentation
-
HTML
Material Declaration
-
HTML
Reliablity Data
- CAD Symbols, Footprints, and 3D Models
-
Ultra Librarian
-
SamacSys
Filter by Model
Part Models
Product Lifecycle
PCN
Jun 18, 2010
- 07_0093
Conversion to Laser Mark for all ADSPXXXX, ADSSTXXXX, and PC Audio Codecs Ink on Plastic Encapsulated Parts
ADSP-BF527KBCZ-5C2
PRODUCTION
Feb 17, 2010
- 09_0173
Power-Up Reset timing specification change applicable to select Blackfin Processors.
ADSP-BF527KBCZ-5C2
PRODUCTION
Dec 14, 2009
- 09_0259
Datasheet Specification Change for ADSP-BF523/523C/525/525C/527/527C Blackfin Processors
ADSP-BF527KBCZ-5C2
PRODUCTION
Filter by Model
Part Models
Product Lifecycle
PCN
Jun 18, 2010
- 07_0093
Conversion to Laser Mark for all ADSPXXXX, ADSSTXXXX, and PC Audio Codecs Ink on Plastic Encapsulated Parts
Feb 17, 2010
- 09_0173
Power-Up Reset timing specification change applicable to select Blackfin Processors.
Dec 14, 2009
- 09_0259
Datasheet Specification Change for ADSP-BF523/523C/525/525C/527/527C Blackfin Processors
Software & Part Ecosystem
Software & Tools Anomaly
Middleware
Lightweight TCP/IP (lwIP) Stack
Software Development Tools
CrossCore® Embedded Studio
Looking for Evaluation Software? You can find it here
Evaluation Kits 3
EMULATOR-ADSP
Low Cost ICE-1000 and High Performance ICE-2000 USB-based JTAG Emulators
Features and Benefits
- JTAG/SWD support for Blackfin, Blackfin+, SHARC and multi-core SHARC+ with ARM
- Plug-n-Play, USB 2.0 compliant
- USB bus-powered device
- Windows® 8.1, Window 7 compatible
- Multiple processor I/O voltage support: 1.8V, 2.5V, and 3.3V
- Multiprocessor support
- JTAG/SWD clock operation of 5 MHz on the ICE-1000
- JTAG/SWD clock operation up to 46 MHZ on the ICE-2000
- Multi-colored LED for enhanced status indication
- Software controlled target reset to support remote debug
Product Detail
New debug feature added for the ICE-1000/ICE-2000:
- Coresight Serial Wire Debug (SWD)
EMULATOR-USB & HP USB ICE
USB-Based Emulator and High Performance USB-Based Emulator
Features and Benefits
- Full speed USB 1.1 interface enabling download speeds of up to 150 KB/Sec (ADZS-USB-ICE) or High speed USB 2.0 interface enabling download speeds of up to 1.5MB/sec (ADZS-HPUSB-ICE)
- Background Telemetry Channel (BTC) support enabling non-intrusive data exchange at up to 2.0 MB/sec (ADZS-HPUSB-ICE only)
- 1.8V, 2.5V, and 3.3V compliant and tolerant
- Support for all ADI JTAG processors and DSPs
- 5V tolerant and 3.3V compliant for 5V processors and DSPs
- Multiprocessor support
- 14-pin JTAG connector
- 3-meter USB cable for difficult-to-reach targets
- CE-certified
Product Detail
The plug-and-play architecture of USB allows the emulators to be automatically detected and configured by the host operating system. It can also be connected to and disconnected from the host without opening the PC or turning off the power to the PC. A 3-meter cable is included to connect the emulators to the host PC, thus providing abundant accessibility to hard to reach targets.
The HP USB-based emulator also supports the Background
Telemetry Channel (BTC), a non-intrusive method
for exchanging data between the host and target
application without affecting the target system's
real-time characteristics.
Part Number:
USB-Based Emulator
Part Number: ADZS-USB-ICE
High Performance USB-Based Emulator
Part Number: ADZS-HPUSB-ICE
Tools Support:
Tel: 1-800-ANALOGD (262-5643)
Contact Support
For additional information, contact your local Analog Devices Sales Office or Distributor.
Resources
EVAL-BF527-EZLITE
The ADSP-BF527F EZ-Kit Lite evaluation hardware provides a low-cost hardware solution for evaluating the ADSP-BF52x Blackfin processor family.
Features and Benefits
- ADSP-BF527 Processor: 289 Ball mBGA, 600MHz; LFBGA-SS2, 12mmX12mm/0.5 pitch, 4L, (A02)
- SDRAM: 64 MB, 32M x 16; Micron MT48LC32M16A2 3.3V
- FLASH: 4 MB (2M x 16 ); Numonyx M29W320EB70ZE6E 3.3V
- NAND FLASH: 4 Gb Numonyx NAND04; NAND04GW3B2B 3.3V
- SPI FLASH: 16 Mb Numonyx M25P16-VMW6G 3.3V
- Thumbwheel: CTS Corp, Rotary Encoder, 2 Bit Binary, CT2999-ND
- Keypad: ACT-07-30008-000-R
- UART: ADM3202 RS-232 line driver/receiver; DB9 female connector
- RTC Battery: 3.0 Volt Li-ION
- LCD Display: Varitronix - Landscape QVGA, 5 in, 320x240, Touch Screen
- Selectable Boot Mode
- Audio I/O: Mic in, Line In, Headphone Out, Line Out
Product Detail
The EZ-KIT Lite includes an ADSP-BF527 Blackfin Processor desktop evaluation board along with an evaluation suite of the VisualDSP++® development and debugging environment, including the C/C++ compiler, assembler, and linker. The evaluation suite of VisualDSP++ is designed to be used with the EZ-KIT Lite only.
