ADF5000: 4 GHz to 18 GHz Divide-by-2 Prescaler Data Sheet (Rev. A)5/6/2010160 kB
Features and Benefits
- Divide-by-2 prescaler
- High frequency operation: 4 GHz to 18 GHz
- Integrated RF decoupling capacitors
- Active mode: 30 mA
- Power-down mode: 17 mA
- Low phase noise: -147 dBc/Hz
- Single dc supply: 3.3 V compatible with ADF4xxx PLLs
- Temperature range: -40°C to +105°C
- Small package: 3 mm × 3 mm LFCSP
The ADF5000 prescaler is a low noise, low power, fixed RF divider block that can be used to divide down frequencies as high as 18 GHz to a lower frequency suitable for input to a PLL IC, such as the ADF4156 or the ADF4106. The ADF5000 provides a divide-by-2 function. The ADF5000 operates from a 3.3 V supply and has differential 100 Ω RF outputs to allow direct interface to the differential RF inputs of PLLs such as the ADF4156 and ADF4106.
- PLL frequency range extender
- Point-to-point radios
- VSAT radios
- Communications test equipment
Product Lifecycle Recommended for New Designs
This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
Evaluation Kits (1)
This page contains ordering information for the evaluation board used to evaluate the ADF5000 4 GHz to 18 GHz Divide-by-2 Prescaler.
Documentation & Resources
RF, Microwave, and Millimeter Wave Product Selection Guide7/13/20189M
Tools & Simulations
ADIsimPLL enables the rapid and reliable evaluation of new high performance PLL products from ADI. It is the most comprehensive PLL Synthesizer design and simulation tool available today. Simulations performed include all key non-linear effects that are significant in affecting PLL performance. ADIsimPLL removes at least one iteration from the design process, thereby speeding the design- to-market.
ADIsimRF is an easy-to-use RF signal chain calculator. Cascaded gain, noise, distortion and power consumption can be calculated, plotted and exported for signal chains with up to 50 stages. ADIsimRF also includes an extensive data base of device models for ADI’s RF and mixed signal components.
ADF5000 Companion Parts
Recommended Linear Regulators
- For ultralow noise, 3.3V applications, 200 mA output: ADP151.
- For ultralow noise, 3.3V applications,150 mA output: ADP150.
Recommended PLL Active Filter
- For an ultralow noise, rail-to-rail amplifier: OP184.
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal.View our quality and reliability program and certifications for more information.
|Part Number||Material Declaration||Reliability Data||Pin/Package Drawing||CAD Symbols, Footprints & 3D Models|
|ADF5000BCPZ||Material Declaration||Reliability Data||16-Lead LFCSP (3mm x 3mm x 0.85mm w/ EP)|
|ADF5000BCPZ-RL7||Material Declaration||Reliability Data||16-Lead LFCSP (3mm x 3mm x 0.85mm w/ EP)|
