Features and Benefits
- 18-bit resolution with no missing codes
- 2.5 V internal low drift reference
2 MSPS (Warp mode)
1.5 MSPS (Normal mode)
- Differential input range: ± VREF (VREF up to 2.5 V)
- INL: ±2 LSB typical
- No pipeline delay (SAR architecture)
- Parallel (18-, 16-, or 8-bit bus)
- Serial 5 V/3.3 V/2.5 V interface
- SPI®/QSPI™/MICROWIRE™/DSP compatible
- On-board low drift reference with buffer and temperature sensor
- See datasheet for additional features
The AD7641 is a 18-bit, 2 MSPS, charge redistribution SAR, fully differential analog-to-digital converter that operates from a single 2.5 V power supply. The part contains a high-speed 18-bit sampling ADC, an internal conversion clock, an internal reference buffer, error correction circuits, and both serial and parallel system interface ports. It features a very high sampling rate mode (Warp) and a fast mode (Normal) for asynchronous conversion rate applications.
The AD7641 is hardware factory calibrated and comprehensively tested to ensure ac parameters such as signal-to-noise ratio (SNR) and total harmonic distortion (THD) in addition to the more traditional dc parameters of gain, offset and linearity.
Operation is specified from −40°C to +85°C.
- Fast Throughput.
The AD7641 is a 2 MSPS, charge redistribution, 18-bit SAR ADC.
- Superior Linearity.
The AD7641 has no missing 18-bit code.
- Internal Reference.
The AD7641 has a 2.048 V internal reference with a typical drift of ±10 ppm/°C and an on-chip TEMP sensor.
- Single-Supply Operation.
The AD7641 operates from a 2.5 V single supply.
- Serial or Parallel Interface.
Versatile parallel (16- or 8-bit bus) or 2-wire serial interface arrangement compatible with 2.5 V, 3.3 V, or 5 V logic.
- Medical instruments
- High dynamic data acquisition
- Spectrum analysis
Product Lifecycle Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
Evaluation Kits (1)
The EVAL-AD7641EDZ is a fully featured evaluation Kit for the AD7641. This board operates in stand alone mode or in conjunction with the Converter Evaluation and Development board, EVAL-CED1Z . When operated with the Converter Evaluation and Development board, software is provided enabling the user to perform detailed analysis of the ADC's performance. This software includes the technical note describing the operation and set up of the evaluation board in standalone operation or when operated with the Converter Evaluation and Development board.
Documentation & Resources
Designing Power Supplies for High Speed ADC2/1/2012
Which ADC Architecture Is Right for Your Application?6/1/2005 Analog Dialogue
AD7641 Companion Parts
Recommended Driver Amplifiers
- For a fully differential attenuating precision amplifier: AD8475.
- For single-ended to differential driver applications: AD8139, ADA4930-1.
- For low noise, low distortion, low power: ADA4841-1.
- For low noise, high gain bandwidth: AD8021, ADA4899-1, AD8022.
Recommended External Voltage References
