Overview

Features and Benefits

Absolute Maximum Ratings
  • Supply Voltage:  ±20V
  • Differential Input Current (Note 1): ±10mA
  • Input Voltage (Note 2): ±20V
  • Output Short-Circuit Duration: Indefinite
  • Operating Temperature Range: –55°C to 125°C
  • Storage Temperature Range: – 65°C to 150°C
  • Lead Temperature (Soldering, 10 sec): 300°C

Product Details

The RH118 is a precision, high speed operational amplifier which offers wide bandwidth and high slew rate. Unlike many wideband amplifiers, the RH118 is unity-gain stable and has a slew rate of 50V/µs.

The wafer lots are processed to Analog Devices’ in-house Class S flow to yield circuits usable in stringent military applications.

Product Lifecycle icon-recommended Production

At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.

Design Resources

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well.  "Zero defects" for shipped products is always our goal.
