MAX40006

RECOMMENDED FOR NEW DESIGNS

Micropower, Rail-to-Rail, 300kHz Op Amp with Shutdown in a Tiny, 6-Bump WLP

Save Power and Board Space—Op Amp Consumes Only 4.5µA and Offers 300kHz BW in 0.73mm x 1.07mm WLP and SOT-23

Data Sheet (Rev. 1) Product Selection Table
Part Models
4
1ku List Price
Starting From $0.80
Viewing:

Part Details

  • 300kHz GBW
  • Ultra-Low 4.5µA Supply Current
  • Single 1.7V to 5.5V Supply Voltage Range
  • Ultra-Low 1pA Input Bias Current
  • Rail-to-Rail Input and Output Voltage Ranges
  • Low ±200µV Input Offset Voltage
  • Low 0.1µA Shutdown Current
  • High-Impedance Output During Shutdown
  • Unity-Gain Stable
  • Available in Tiny, 0.73mm x 1.07mm, 6-Bump WLP and SOT-23 Packages
  • -40°C to +125°C Temperature Range
MAX40006
Micropower, Rail-to-Rail, 300kHz Op Amp with Shutdown in a Tiny, 6-Bump WLP
MAX40006: Functional Block Diagram
