MAX31827

Low-Power Temperature Switch with I2C Interface

Show More showmore-icon

Smallest, Lowest Power Temperature Switch on the Market

Info : RECOMMENDED FOR NEW DESIGNS tooltip
Info : RECOMMENDED FOR NEW DESIGNS tooltip
Part Details
Part Models 2
1ku List Price Starting From $0.55
Features
  • Stand-alone Temperature Switch with Preconfigured Alarm Thresholds and Hysterisis
  • Active High/Active Low/Open Drain ALARM Output
  • Excellent Temperature Accuracy
    • Maximum ±1.75°C from -45°C to +145°C
    • Maximum ±1°C from -40°C to +125°C (12 bits)
  • External Resistor Selects Address for Location Identification
  • Temperature Resolution is Selectable from 8 to 12 Bits
  • Selectable Timeout Prevents Bus Lockup (Default Enabled)
  • I2C and SMBus Support
  • User-Defined Alarm Settings
  • ​Selectable PEC for Reliable Communications
  • Up to 1MHz Bus Speed
  • +1.6V to +3.6V Power Supply Voltage
Additional Details
show more Icon

The MAX31827 is a ±1°C accuracy from -40°C to +125°C (12 bits) local temperature switch and sensor with I2C/SMBus interface. The combination of small 6-bump wafer-level package (WLP) and high accuracy makes this temperature sensor/switch ideal for a wide range of applications. It can be used as a temperature switch with preconfigured thresholds and/or as a temperature sensor with I2C interface. When the part operates as an independent temperature switch, the I2C interface doesn't have to be used. This enables use of the part in systems that require thermal protection implemented in hardware, without the need for reconfiguration or use of software/firmware during normal operation.


One-time programmable (OTP) ALARM functionality enables use of the part as a safety mechanism in systems where power dissipation is a challenge.

The I2C/SMBus-compatible serial interface accepts standard write and read commands to read the temperature data and configure the behavior of the sensor. Bus timeout resets the interface if the clock is low for more than 30ms (nominal). Packet error checking (PEC) helps prevent communication errors when used with a master that supports this feature.

The MAX31827 is available in a 6-bump WLP and operates over the -45°C to +145°C temperature range.

Applications

  • Battery-Powered Equipment
  • Data Communications Equipment
  • Handheld Electronics
  • Industrial Equipment
  • Servers
Part Models 2
1ku List Price Starting From $0.55

close icon
Documentation

Documentation

Video

Part Model Pin/Package Drawing Documentation CAD Symbols, Footprints, and 3D Models
MAX31827ANTABRPF+
  • HTML
  • HTML
MAX31827ANTABRPF+T
  • HTML
  • HTML
Software & Part Ecosystem

Software & Part Ecosystem

Can't find the software or driver you need?

Request a Driver/Software
Evaluation Kit

Evaluation Kits 2

reference details image

MAX31827EVKIT

Evaluation System for the MAX31827/MAX31828/MAX31829

zoom

MAX31827EVKIT

Evaluation System for the MAX31827/MAX31828/MAX31829

Evaluation System for the MAX31827/MAX31828/MAX31829

Features and Benefits

  • Proven PCB Layout
  • Fully Assembled and Tested
  • Windows XP, Windows 7/8/8.1/10-Compatible Software

Product Detail

The MAX31827 evaluation system (EV system) demonstrates the MAX31827 I2C temperature switch and sensor with hardware-selectable address and alarm. The EV system includes the MAX31827 evaluation kit (EV kit) and the USB2PMB2 module. Windows® 7/8/8.1/10-compatible software provides a user-friendly interface that demonstrates the features of the MAX31827/8/9. The MAX31827 EV kit comes with the 6-pin WLP MAX31827ANTABRPF+ installed.

Applications

  • Battery-Powered Equipment
  • Data Communications Equipment
  • Handheld Electronics
  • Industrial Equipment
  • Servers
reference details image

MAX31827EVSYS1

Evaluation System for the MAX31827/MAX31828/MAX31829

zoom

MAX31827EVSYS1

Evaluation System for the MAX31827/MAX31828/MAX31829

Evaluation System for the MAX31827/MAX31828/MAX31829

Features and Benefits

  • Proven PCB Layout
  • Fully Assembled and Tested
  • Windows XP, Windows 7/8/8.1/10-Compatible Software

Product Detail

The MAX31827 evaluation system (EV system) demonstrates the MAX31827 I2C temperature switch and sensor with hardware-selectable address and alarm. The EV system includes the MAX31827 evaluation kit (EV kit) and the USB2PMB2 module. Windows® 7/8/8.1/10-compatible software provides a user-friendly interface that demonstrates the features of the MAX31827/8/9. The MAX31827 EV kit comes with the 6-pin WLP MAX31827ANTABRPF+ installed.

Applications

  • Battery-Powered Equipment
  • Data Communications Equipment
  • Handheld Electronics
  • Industrial Equipment
  • Servers
