MAX1735

200mA, Negative-Output, Low-Dropout Linear Regulator in SOT23

Show More showmore-icon

Ultra-Small, 200mA Negative Output LDO in SOT23

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Viewing: Part Details
arrow-icon

Not the part you were looking for?

viewall Go to Product Selection Table
file View Data Sheet (Rev.1)
Documentation View All Documentation
Part Models 6
1ku List Price Starting From $1.32
Features
  • Guaranteed 200mA Output Current
  • Low 80mV Dropout Voltage at 200mA
  • Low 85µA Quiescent Supply Current
  • Low 1nA Current Shutdown Mode
  • Stable with 1µF COUT
  • PSRR > 60dB at 100Hz
  • Thermal Overload Protection
  • Short-Circuit Protection
  • -5.0V, -3.0V, or -2.5V Output Voltage or Adjustable (-1.25V to -5.5V)
  • Tiny SOT23-5 Package
Additional Details
show more Icon

The MAX1735 negative-output, low-dropout linear regulator operates from a -2.5V to -6.5V input and delivers a guaranteed 200mA with a low 80mV dropout. The high-accuracy (±1%) output voltage is preset or can be adjusted from -1.25V to -5.5V with an external resistive voltage-divider.

An internal N-channel MOSFET allows for a low 85µA quiescent current virtually independent of the load, making this device ideal for battery-powered portable equipment, such as PDAs, mobile phones, cordless phones, and wireless data modems.

The device is available in several preset output voltage versions: -5.0V, -3.0V, and -2.5V. All versions offer a 1nA low-power shutdown mode, short-circuit protection, and thermal overload protection. The device is offered in a tiny 5-pin SOT23 package.

Applications

  • Access Products
  • Cell Phones
  • Cordless Phones
  • Digital Cameras and Camcorders
  • Glucose Meters
  • Handhelds (GPS, POS Terminal)
  • HDD and RAID
  • PC Add-In Cards
  • Power Supplies
Show More Arrow image
file View Data Sheet (Rev.1)
Documentation View All Documentation
Part Models 6
1ku List Price Starting From $1.32
