LT3690
36V, 4A, 1.5MHz Synchronous Step-Down Switching Regulator with 70μA Quiescent Current
Top
Overview
Features and Benefits
- Wide Input Range:
- Operation from 3.9V to 36V
- Overvoltage Lockout Protects Circuits Through 60V Transients
- 4A Maximum Output Current
- Integrated 30mΩ N-Channel Synchronous Switch
- Low Ripple (<15mVP-P) Burst Mode® Operation: IQ = 70µA at 12VIN to 3.3VOUT
- Programmable Input Undervoltage Lockout
- 0.8V Feedback Reference Voltage
- Output Voltage: 0.8V to 20V
- Programmable and Synchronizable Oscillator (170kHz to 1.5MHz)
- Soft-Startup and Output Voltage Tracking
- Short-Circuit Robust
- Power Good Flag
- Small Thermally Enhanced 4mm × 6mm QFN Package
Product Details
The LT®3690 is an adjustable frequency monolithic buck switching regulator that accepts input voltages up to 36V. A high efficiency 90mΩ switch is included on the device along with the boost diode and the necessary oscillator, control, and logic circuitry. The internal synchronous power switch of 30mΩ increases efficiency and eliminates the need for an external Schottky catch diode. Current mode topology is used for fast transient response and good loop stability. Shutdown reduces input supply current to less than 1µA. The low ripple Burst Mode maintains high efficiency at low output currents while keeping output ripple below 15mV in typical applications.
The LT3690 features robust operation and is easily configurable. Using a resistor divider on the UVLO pin provides a programmable undervoltage lockout. A power good flag signals when VOUT reaches 90% of the programmed output voltage. Protection circuitry senses the current in the power switches to protect the LT3690 against short-circuit conditions. Frequency foldback and thermal shutdown provide additional protection. The LT3690 is available in a 4mm × 6mm QFN package with exposed pads for low thermal resistance.
Applications
- Automotive Systems
- Industrial Supplies
- Distributed Supply Regulation
Product Categories
Product Lifecycle
Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
Evaluation Kits (1)
Documentation & Resources
-
R530 Reliability Data3/26/2018
-
DC1520A - Demo Manual3/23/2011
-
36V, 4A Sync Buck6/27/2011
-
Switching Regulator Power Loss10/15/2018
Tools & Simulations
LTspice
LTspice® is a powerful, fast and free simulation software, schematic capture and waveform viewer with enhancements and models for improving the simulation of analog circuits.
To launch ready-to-run LTspice demonstration circuits for this part:
Step 1: Download and install LTspice on your computer.
Step 2: Click on the link in the section below to download a demonstration circuit.
Step 3: If LTspice does not automatically open after clicking the link below, you can instead run the simulation by right clicking on the link and selecting “Save Target As.” After saving the file to your computer, start LTspice and open the demonstration circuit by selecting ‘Open’ from the ‘File’ menu.
Models for the following parts are available in LTspice:
LT3690
3-D Design Model
ZIP
LT3690 3D Design Model
0.02 K
Product Recommendations
LT3690 Companion Parts
Design Resources
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal.View our quality and reliability program and certifications for more information.
| Part Number | Material Declaration | Reliability Data | Pin/Package Drawing | CAD Symbols, Footprints & 3D Models |
|---|---|---|---|---|
| LT3690EUFE#PBF | Material Declaration | Reliability Data | 26-Lead QFN (6mm x 4mm x 0.75mm w/ EP) | |
| LT3690EUFE#TRPBF | Material Declaration | Reliability Data | 26-Lead QFN (6mm x 4mm x 0.75mm w/ EP) | |
| LT3690HUFE#PBF | Material Declaration | Reliability Data | 26-Lead QFN (6mm x 4mm x 0.75mm w/ EP) | |
| LT3690HUFE#TRPBF | Material Declaration | Reliability Data | 26-Lead QFN (6mm x 4mm x 0.75mm w/ EP) | |
| LT3690IUFE#PBF | Material Declaration | Reliability Data | 26-Lead QFN (6mm x 4mm x 0.75mm w/ EP) | |
| LT3690IUFE#TRPBF | Material Declaration | Reliability Data | 26-Lead QFN (6mm x 4mm x 0.75mm w/ EP) | |
| LT3690MPUFE#PBF | Material Declaration | Reliability Data | 26-Lead QFN (6mm x 4mm x 0.75mm w/ EP) | |
| LT3690MPUFE#TRPBF | Material Declaration | Reliability Data | 26-Lead QFN (6mm x 4mm x 0.75mm w/ EP) | |
