LT1028/LT1128: Ultralow Noise Precision High Speed Op Amps Data Sheet10/2/2017PDF712K
Overview
Features and Benefits
- Voltage Noise
- 1.1nV/√Hz Max. at 1kHz
- 0.85nV/√Hz Typ. at 1kHz
- 1.0nV/√Hz Typ. at 10Hz
- 35nVP-P Typ., 0.1Hz to 10Hz
- Gain-Bandwidth Product
- LT1028: 50MHz Min.
- LT1128: 13MHz Min.
- Slew Rate
- LT1028: 11V/µs Min.
- LT1128: 5V/µs Min.
- Offset Voltage: 40µV Max.
- Drift with Temperature: 0.8µV/°C Max.
- Voltage Gain: 7 Million Min.
- Voltage and Current Noise 100% Tested
- Available in 8-Pin SO Package
Product Details
The LT1028 (gain of –1 stable)/LT1128(gain of +1 stable) achieve a new standard of excellence in noise performance with 0.85nV/√Hz 1kHz noise, 1.0nV/√Hz 10Hz noise. This ultralow noise is combined with excellent high speed specifications (gain-bandwidth product is 75MHz for LT1028, 20MHz for LT1128), distortion-free output, and true precision parameters (0.1µV/°C drift, 10µV offset voltage, 30 million voltage gain). Although the LT1028/LT1128 input stage operates at nearly 1mA of collector current to achieve low voltage noise, input bias current is only 25nA.
The LT1028/LT1128’s voltage noise is less than the noise of a 50Ω resistor. Therefore, even in very low source impedance transducer or audio amplifier applications, the LT1028/LT1128’s contribution to total system noise will be negligible.
Applications
- Low Noise Frequency Synthesizers
- High Quality Audio
- Infrared Detectors
- Accelerometer and Gyro Amplifiers
- 350 ohms Bridge Signal Conditioning
- Magnetic Search Coil Amplifiers
- Hydrophone Amplifiers
Product Lifecycle
Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
