HMC8118

RECOMMENDED FOR NEW DESIGNS

71 GHz to 76 GHz, E-Band I/Q Upconverter

Data Sheet (Rev. A) Product Selection Table

Part Models: 2
1ku List Price: price unavailable

Viewing:

Overview

Conversion loss: 11 dB typical
Sideband rejection: 33 dBc typical Input power for 1 dB compression (P1dB): 14 dBm typical
Input third-order intercept (IP3): 22 dBm typical
Input second-order intercept (IP2): −5 dBm typical
6× local oscillator (LO) leakage at RFOUT: −27 dBm typical
RF return loss: 6 dB typical
LO return loss: 18 dB typical
Die size: 3.601 mm × 1.609 mm × 0.05 mm

The HMC8118 is an integrated E-band gallium arsenide (GaAs) monolithic microwave integrated circuit (MMIC) in-phase/ quadrature (I/Q) upconverter chip that operates from 71 GHz to 76 GHz. The HMC8118 provides a small signal conversion loss of 11 dB with 33 dBc of sideband rejection across the frequency band. The device uses an image rejection mixer that is driven by a 6× LO multiplier. Differential I and Q mixer inputs are provided. The inputs can be driven with differential I and Q baseband waveforms for direct conversion applications. Alternatively, the inputs can be driven using an external 90° hybrid and two external 180° hybrids for single sideband applications. All data includes the effect of a 1 mil gold wire wedge bond on the intermediate frequency (IF) port.

Applications

E-band communication systems
High capacity wireless backhaul
Test and measurement

Part Models: 2
1ku List Price: price unavailable

Documentation

Data Sheet 1

HMC8118: 71 GHz to 76 GHz, E-Band I/Q Upconverter Data Sheet (Rev.A) 02/25/2016

Technical Articles 1

E-Band Wireless Radio Links Deliver High Capacity Backhaul Solutions for 5G Networks—Part 1 10/23/2023
