HMC1049LP5E

GaAs pHEMT MMIC Low Noise Amplifier, 0.3 - 20 GHz

Show More showmore-icon

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Viewing: Part Details
arrow-icon

Not the part you were looking for?

viewall Go to Product Selection Table
file View Data Sheet (Rev.B)
Documentation View All Documentation
S-Parameter HMC1049LP5E S-Parameters Download 16.8 KB
Part Models 3
1ku List Price
price unavailable
Features
  • Low noise figure: 1.8 dB
  • P1dB output power: 14.5 dBm
  • PSAT output power: 17.5 dBm
  • High gain: 15 dB
  • Output IP3: 29 dBm
  • Supply voltage: VDD = 7 V at 70 mA
  • 50 Ω matched input/output (I/O)
  • 32-lead, 5 mm × 5 mm LFCSP package: 25 mm2
HMC1049SCPZ-EP Supports Defense and Aerospace Applications (AQEC standard)
Additional Details
show more Icon

The HMC1049LP5E is a GaAs MMIC low noise amplifier (LNA) that operates between 0.3 GHz and 20 GHz. This LNA provides 15 dB of small signal gain, 1.8 dB noise figure, and an IP3 output of 29 dBm, yet requires only 70 mA from a 7 V supply. The P1dB output power of 14.5 dBm enables the LNA to function as a local oscillator (LO) driver for balanced, I/Q, or image rejection mixers. VDD can also be applied to Pin 21, although Pin 21 requires a bias tee with VDD = 4 V. The HMC1049LP5E amplifier I/Os are internally matched to 50 Ω, and the device is supplied in a compact, leadless 5 mm × 5 mm LFCSP package.

Applications

  • Test instrumentation
  • High linearity microwave radios
  • VSAT and SATCOM
  • Military and space
