ADUC847
MicroConverter® Multichannel24-/16-Bit ADCs with Embedded 62 kB Flash and Single-Cycle MCU
Show More
Not the part you were looking for?
Ask a Question
Submit your question below and we will return the best answer from ADI’s knowledge database:
Search
Other places you can find help
Support
Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.
Visit the ADI Support Page
Features
- High resolution Σ-Δ ADCs
- Single 24-bit ADC
- Up to 10 ADC input channels on all devices
- 24-bit no missing codes
- 22-bit rms (19.5 bit p-p) effective resolution
- Offset drift 10 nV/°C, gain drift 0.5 ppm/°C chop enabled
- Memory
- 62-kbyte on-chip Flash/EE program memory
- 4-kbyte on-chip Flash/EE data memory
- Flash/EE, 100-year retention, 100 kcycle endurance
- 3 levels of Flash/EE program memory security
- In-circuit serial download (no external hardware)
- High speed user download (5 sec)
- 2304 bytes on-chip data RAM
- See data sheet for additional features
.svg?rev=fd385c90e2cf4716ae9a8c8d20e6b8e3&la=en&h=24&w=24&hash=A302DF48F94BAAA11877AF223F27157A){kind=icon}
The ADuC845, ADuC847, and ADuC848 are single-cycle, 12.58 MIPs, 8052 core upgrades to the ADuC834 and ADuC836. They include additional analog inputs for applications requiring more ADC channels.
The ADuC845, ADuC847, and ADuC848 are complete smart transducer front ends. The family integrates high resolution Σ-Δ ADCs with flexible, up to 10-channel, input multiplexing, a fast 8-bit MCU, and program and data Flash/EE memory on a single chip.
The ADuC845 includes two (primary and auxiliary) 24-bit Σ-Δ ADCs with internal buffering and PGA on the primary ADC. The ADuC847 includes the same primary ADC as the ADuC845 (auxiliary ADC removed). The ADuC848 is a 16-bit ADC version of the ADuC847.
The ADCs incorporate flexible input multiplexing, a temperature sensor (ADuC845 only), and a PGA (primary ADC only) allowing direct measurement of low-level signals. The ADCs include on-chip digital filtering and programmable output data rates that are intended for measuring wide dynamic range and low frequency signals, such as those in weigh scale, strain gage, pressure transducer, or temperature measurement applications.
The devices operate from a 32 kHz crystal with an on-chip PLL generating a high frequency clock of 12.58 MHz. This clock is routed through a programmable clock divider from which the MCU core clock operating frequency is generated. The microcontroller core is an optimized single-cycle 8052 offering up to 12.58 MIPs performance while maintaining 8051 instruction set compatibility.
The available nonvolatile Flash/EE program memory options are 62 kbytes, 32 kbytes, and 8 kbytes. 4 kbytes of nonvolatile Flash/EE data memory and 2304 bytes of data RAM are also provided on-chip. The program memory can be configured as data memory to give up to 60 kbytes of NV data memory in data logging applications.
On-chip factory firmware supports in-circuit serial download and debug modes (via UART), as well as single-pin emulation mode via the EA pin. The ADuC845, ADuC847, and ADuC848 are supported by the QuickStart™ development system featuring low cost software and hardware development tools.
Applications
- Multichannel sensor monitoring
- Industrial/environmental instrumentation
- Weigh scales, pressure sensors, temperature monitoring
- Portable instrumentation, battery-powered systems
- Data logging, precision system monitoring
Ask a Question
Submit your question below and we will return the best answer from ADI’s knowledge database:
Search
Other places you can find help
Support
Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.
Visit the ADI Support Page
{{modalTitle}}
{{modalDescription}}
{{dropdownTitle}}
- {{defaultSelectedText}} {{#each projectNames}}
- {{name}} {{/each}} {{#if newProjectText}}
-
{{newProjectText}}
{{/if}}
{{newProjectTitle}}
{{projectNameErrorText}}
ADUC847
Documentation
Filters
1 Applied
-
All
-
Application Note
-
Data Sheet
-
User Guide
-
Technical Articles
-
All
-
English
-
Chinese
-
Japanese
Data Sheet
1
ADuC845/ADuC847/ADuC848: MicroConverter® Multi-Channel 24-/16-Bit ADCs with Embedded 62 kB FLASH and Single-Cycle MCU Data Sheet (Rev.D)
Application Note
13
1559 kB
1606 kB
HTML
HTML
User Guide
3
679 kB
Technical Articles
1
URL
Documentation
Data Sheet 1
User Guide 2
Application Note 8
UC-009: Addressing 16MB of External Data Memory
UC-006: A 4-wire UART-to-PC Interface
AN-759: Expanding the Number of DAC Outputs on the ADuC8xx and ADuC702x Families (uC012) (Rev.0)
AN-660: XY-Matrix Keypad Interface to MicroConverter® (Rev.0)
AN-709: RTD Interfacing and Linearization Using an ADuC8xx MicroConverter® (Rev.0)
AN-282: Fundamentals of Sampled Data Systems
AN-1074: Understanding the Serial Download Protocol (Formerly uC004)
AN-1139: Understanding the Parallel Programming Protocol
Technical Articles 1
Analog Dialogue 1
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.
| Part Model | Pin/Package Drawing | Documentation | CAD Symbols, Footprints, and 3D Models |
|---|---|---|---|
| ADUC847BCPZ62-3 |
56-Lead LFCSP (8mm x 8mm w/ EP)
|
|
|
| ADUC847BCPZ62-5 |
56-Lead LFCSP (8mm x 8mm w/ EP)
|
|
|
| ADUC847BCPZ8-3 |
56-Lead LFCSP (8mm x 8mm w/ EP)
|
|
|
| ADUC847BCPZ8-5 |
56-Lead LFCSP (8mm x 8mm w/ EP)
|
|
|
| ADUC847BSZ32-3 |
52-Lead MQFP (10mm x 10mm)
|
|
|
| ADUC847BSZ32-5 |
52-Lead MQFP (10mm x 10mm)
|
|
|
| ADUC847BSZ62-3 |
52-Lead MQFP (10mm x 10mm)
|
|
|
| ADUC847BSZ62-5 |
52-Lead MQFP (10mm x 10mm)
|
|
|
| ADUC847BSZ8-5 |
52-Lead MQFP (10mm x 10mm)
|
|
